- Page 1 H e a d R e c e i v e r M o d u l a t o r S T R 3 1 2...
-
Page 2: Table Of Contents
Installation and Safety Precautions 10 cm POWER STORE/CLEAR EDIT/COPY TUNING DSR/FM POWER POWER POWER POWER STORE/CLEAR EDIT/COPY TUNING DSR/FM STORE/CLEAR TUNING DSR/FM STORE/CLEAR TUNING DSR/FM STORE/CLEAR TUNING DSR/FM EDIT/COPY EDIT/COPY EDIT/COPY Make absolutely sure that your receiver is not exposed to drip- Even when switched off, the unit may be damamged by light- ping or splashing water. -
Page 3: Remote Control And Illustrations
WEGENER COMMUNICATIONS. INC. N O I S E R E D U C T I O N STEREO TIMER P 1 9 9 PROGRAM RADIO POWER STR 312 STEREO MODE RADIO VIDEO MEMORY AUDIO REM. CONTR. VCR 0/12V MAGN. POLARIZER... -
Page 4: Connection Examples
Connection Examples Remote control (Timer) Decoder Radio STR 312 Decoder terr. HF-Signal EURO-AV-Sockets for 1 VCR, 1 Decoder and TV 1) TV-reception terr./VCR recording SAT 2) TV-reception SAT/VCR recording terr. HiFi-Amplifer 3) TV-reception terr./VCR recording terr./-HiFi-reception SAT-radio 4) With VCR-playback, the signal path is automatically relayed to the television set through the receiver (also in stand by). - Page 5 Connection Examples Decoder Decoder Radio STR 312 Decoder terr. HF-Signal EURO-AV-Sockets for 2 Decoder and TV The VCR scart socket can also be used as a second deco- HiFi-Amplifer der socket for Pal scrambling (automatic switching deco- der 1/ decoder 2) Eutelsat 10°...
-
Page 6: Remote Control Buttons
Remote Control Buttons Important operating functions and basic settings can be car- ried out with the rc sat remote control. Please insert the battery included observing correct polarity. The marking for this is on the compartment bottom. Close the cover. If a battery is exhausted, "bA A tt"... -
Page 7: Receiver Buttons And Connections
Receiver buttons and connections Unit Front ßT ßU ´? Note Except for buttons and Radio , all buttons are locked in order to prevent unintentio- nal activation. Clear a blocked button by keeping it depressed (longer than 3 seconds). Button ßQ block is reactivated when you switch the receiver off with the POWER button or to stand-by... - Page 8 ´R É Terrestrial aerial input (VHF/UHF). ´T Modulator aerial output (VHF/UHF). ´Z REM. Connection to remote control via GRUNDIG videorecorder CONTR. (see chapter "Timer/Videorecorder and Datalink"). ß? Commands via the socket are indicated by the flashing timer LED ´U AUDIO NF stereo output.
-
Page 9: Important Information
The display shows the current programme position again. Should disturbances in the form of spikes appear (short black or white lines) these can be eliminated by pressing the P/F Congratulations for selecting your new STR 312 stereo satel- button and corrected with the button. -
Page 10: Receiver Buttons And Functions
Receiver Buttons and Functions ßQ Because the receiver only allows 4-place entries, the first After switching on with the power button, the receiver place is neither entered nor displayed. automatically reselects the most previous programme Example: position (Last Station Memory). ARD transmission frequency on Astra: 11494 MHz Select the programme position with the remote control button... -
Page 11: Adjusting Video Range
Receiver Buttons and Functions Adjusting video range Audio Frequency modulated satellite signals are transmitted at Press the AUDIO button to display the current audio mode; various shift values. The reciever must be appropriately for example: adjusted for correct picture quality. Press the VIDEO button;... -
Page 12: Mode-Direct Selection
N O I S E R E D U C T I O N STEREO TIMER P 1 9 9 PROGRAM RADIO POWER STR 312 STEREO MODE AUDIO RADIO VIDEO MEMORY First press Preselection - and then MODE MODE "COPY"... -
Page 13: Mode-Functions
MODE Functions selecting individually The MODE button is used to select the various functions. You – Special function use the buttons or the numeric buttons on the remote control to change the settings in the mode you have selected. S S F F (special function ) is shown in the display. Using the buttons, you can select an external switching COPY... -
Page 14: If Band Width
MODE Functions selecting individually " I I I I /I I I I " – IF band width nor 1 / nor 2 / nor 3 – norm " I I I I " (wide) or " I I I I " (narrow) is shown in the display. The preset mode point is shown in the display. -
Page 15: Ats - Automatic Tuning System
MODE Functions selecting individually CodE – Child lock – Automatic Tuning System You can protect your receiver against unauthorized use (child The automatic tuning system (ATS) is especially suited if you lock). use LNC´s with oscillator frequencies other than 9.75 or Using the numeric buttons on the remote control, enter your 10 GHz. -
Page 16: Remote Control Functions
Remote Control Functions “ button Direct programme selection “ Call up the Timer menu by pressing the button. You can directly select programmes by pressing the corre- “ Exit the Timer menu by pressing the button again. “ “ sponding buttons Pressing the respective button 1... -
Page 17: Osd Timer Menu
– Select the desired line with the buttons. by means of a prepared GRUNDIG video recorder. – Activate the timer menu with the button. The requisite remote control cable is availabe in the GRUNDIG “ – Exit the menu by pressing the button. accessory programme. - Page 18 OSD Timer Menu on the screen Entering programme position, date, and time Timer programming is very simple. It is even possible, for example, to preprogramme the timer for another programme during a TV transmission. “ “ With the buttons on the remote control, select the appropriate lines in the timer menu and enter the programme position, date and time with the numeric buttons;...
-
Page 19: Technical Data
Technical Data Reception range: intern: 910 ... 2050 MHz, two signal inputs (A, B) Receivable transmission signals: 9.75 GHz LNC: 10700 ... 11800 MHz 10.00 GHz LNC: 10910 ... 12050 MHz LNC oscillator frequency: settable: 9.75/10 GHz Tuning system: Frequency synthesizer with direct frequency input. Forward in 10 MHz increments Reverse in 3 MHz increments Single increments in 0.5 MHz increments, corresponds to fine tuning... -
Page 20: Euro-Av Pin Assignment
EURO-AV pin assignment If you want to connect auxiliary units (for example, a video recorder or decoder), your dealer can make a standard connection by means of the following connection table: Signal Decoder VCR = Audio output, right = Audio input, right = Audio output, left = Audio earth = Blau earth... - Page 21 ✁ É 21106-941.11 GRUNDIG AG • D - 90762 FÜRTH Printed in Germany . 3/28 Mü 3 4 5 6 7 8 9...
