The Elite Nexus
Installation Guide
Freestanding & Adhesive Mount instructions
1
Unlock case with keys provided
and remove faceplate.
4
Wipe base of stand and your
mounting surface with alcohol
wipes provided and let dry.
Optional Position Lock
o
Rotate stand 45
degrees so cable hole is on the left,
and then screw in lock screw as shown. This will lock the
rotation for a fixed option.
2
Feed cable through the stand and
plug in your tablet while placing it
into the case.
5
Stick 3M adhesive to the base of
stand and firmly place down on
your mounting surface.
Optional Cable Through Channel
Unscrew existing closed cable cutout and install the
open cable cutout included with stand.
w ww.b o sstab.com
3
Place faceplate back on and lock.
Follow steps 4-6 for adhesive
mount instructions
6
Let the stand sit for 24 hours
before use.
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Bosstab Elite Nexus
Summary of Contents for Bosstab Elite Nexus
- Page 1 The Elite Nexus Installation Guide Freestanding & Adhesive Mount instructions Unlock case with keys provided Feed cable through the stand and Place faceplate back on and lock. and remove faceplate. plug in your tablet while placing it Follow steps 4-6 for adhesive into the case.
- Page 2 The Elite Nexus Installation Guide Screw Mount instructions Screw base holes Cable feed hole Remove screws from case and lift Follow the above locations to line We recommend drilling pilot holes the case off the stand. up your surface mounting and to assist with screw base mounting.
