Billion BiPAC 7402X Specifications

Compatible 3G USB modems * 3
Brand Model
Huawei E220
Huawei E270
Bandluxe C100
BandRich
This list will be continuously updated at http://www.billion.com/compatible-3G.html.
Benefits
Communication Flexibility via 3G/HSDPA using the USB port
The BiPAC 7402X series allows you to connect a 3G/HSDPA USB modem to its built-in USB port,
enabling you to use a 3G/HSDPA, UMTS, EDGE, GPRS, or GSM Internet connection, makes
*
downstream rates of up to 14.4Mbps 3 possible. With the increasing popularity of the 3G standard,
communication via the BiPAC 7402X series is becoming more convenient and widely available -
allowing you to watch movies, download music on the road, or access e-mail no matter where you are.
You can even share your Internet connection with others, no matter if you're in a meeting, or speeding
across the country on a train.
Always Online
The BiPAC 7402X series is compliant with worldwide ADSL standards, and supports download rates of
up to 12/24Mbps using ADSL2/2+, 8Mbps using ADSL and an upload rate of up to 1Mbps. Using this
technology you'll be able to enjoy high-speed ADSL and broadband multimedia applications such as
interactive gaming, video streaming and real-time audio. The integrated Annex M standard supports
ADSL2/2+ for higher upload speeds by doubling the upload data rate. Planned support for auto-failover
means that you'll be assured of a constant Internet connection – in case your ADSL line fails, the BiPAC
7402X series will connect via 3G to deliver uninterrupted connectivity.
Double-layer Protection
An integrated 802.11g Wireless Access Point offers quick yet easy access with data encryption for
added security. Wireless Protected Access (WPA-PSK/WPA2-PSK) and Wireless Encryption Protocol
(WEP) support ensures high-level data protection and WLAN access control. In addition, rich firewall
security features such as SPI, DoS attack prevention and URL content filtering are integrated to provide
unparalleled protection for Internet access. Enjoy the benefits of added security by simply pressing the
Wi-Fi Protected Setup button to quickly and easily set up secure wireless communication. If your
network requires wider coverage, the built-in Wireless Distribution System (WDS) repeater function
allows you to expand the wireless network without the need for using any wires.
Secure VPN connections
The BiPAC 7402X series supports embedded IPSec VPN (Virtual Private Network) protocols, allowing
users to establish encrypted private connections of up to 16 simultaneous tunnels over the Internet.
With a built-in DES/3DES VPN accelerator, the router enhances IPSec VPN performance significantly
and ensures that data is transmitted securely between two or more sites.
Features & Specifications
ADSL Compliance ATM and PPP Protocols
• Compliant with ADSL Standard • ATM Adaptation Layer Type 5 (AAL5)
- Full-rate ANSI T1.413 Issue 2 • Multiple protocols over AAL5 (RFC 2684, formerly RFC 1483)
- G.dmt (ITU G.992.1) • Bridged or routed Ethernet encapsulation
- G.lite (ITU G.992.2) • VC and LLC based multiplexing
- G.hs (ITU G.994.1) • PPP over Ethernet (PPPoE)
- ADSL over ISDN/U-R2 • PPP over ATM (RFC 2364)
• Compliant with ADSL2 Standard • Classical IP over ATM (RFC 1577)
- G.dmt.bis (ITU G.992.3) • MAC Encapsulated Routing (RFC 1483 MER)
• OAM F4/F5
- ADSL2 Annex M (ITU G.992.3 Annex M)
(Available on BiPAC 7402X series -A)
Operating Environment
• Compliant with ADSL2+ Standard
- G.dmt.bisplus (ITU G.992.5)
• Operating temperature: 0 - 40°C
- ADSL2+ Annex M (ITU G.992.5 Annex M)
• Storage temperature: -20 - 70°C
(Available on BiPAC 7402X series -A) • Humidity: 20 - 95% non-condensing
Network Protocols and Features
Quality of Service Control
• NAT, static routing and RIP-1/2
• Supports DiffServ approach
• Universal Plug-and-Play (UPnP) Compliant
• Traffic prioritization and bandwidth management based-on IP protocol,
• Dynamic Domain Name System (DDNS)
port number and address
• Virtual Server and DMZ
• SNTP, DNS relay, IGMP Proxy Firewall
• POP3 (email account checking)
• Built-in NAT firewall
• IGMP Snooping for video services
• Stateful Packet Inspection (SPI)
Virtual Private Network (VPN)
• Prevent DoS attacks including IP Spoofing, Land Attack,Smurf Attack,
Ping of Death, TCP SYN Flooding, etc.
• 16 IPSec VPN Tunnels • Packet Filtering – port, source IP address, destination IP address, MAC
8 L2TP VPN Tunnels (Dial-in: 4, Dial-out: 4)
address
8 PPTP VPN Tunnels (Dial-in: 4, Dial-out: 4) • URL Content Filtering – string or domain name detection in URL string
• Embedded IPSec, L2TP & PPTP client/server
Hardware Specifications
• IKE key management
• DES, 3DES and AES encryption for IPSec
Physical Interface
• Embedded powerful 3DES accelerator
• WLAN: one 2 dBi detachable antenna
• MPPE Encryption for PPTP
• DSL: ADSL Port
• L2TP over IPSec
• Ethernet: 4-port 10/100Mbps auto MDI/MDI-X Switch
• L2TP/PPTP/IPSec pass-through
• USB 2.0 supports 3G/HSDPA modem backup
Management • Console: the Ethernet Port # 4 can be also connected to console
• WPS button: for WPS Push Button Configuration
• Quick Installation Wizard and Auto ADSL settings • Factory default reset button
• Web-based GUI for remote and local management • Power jack
• Firmware upgrade and configuration data upload and download via • Power switch
web-based GUI Physical Specifications
• Embedded Telnet server for remote and local management
• Dimensions: 7.28" x 4.86" x 1.42"
• Available Syslog monitoring (185mm x 123.5mm x 36mm)
• SNMP v3, MIB-I and MIB-II support
Power Requirements
• Supports DHCP server/client/relay • Input:12V DC, 1.2A
• Supports Remote Management* 1
• Car power cable available
• TR-069* 1
Models & Standards Supported
Wireless 802.11g
Product Models
• Compliant with IEEE 802.11g and 802.11b standards
• BiPAC 7402X 3G/ADSL2+ VPN Firewall Router
• 2.4GHz - 2.484GHz frequency range
• BiPAC 7402XL 3G/ADSL2+ Firewall Router
• Up to 54Mbps wireless operation rate
• BiPAC 7402GX 3G/ADSL2+ Wireless VPN Firewall Router
• 64-/128-bit WEP supported for encryption
• BiPAC 7402GXL 3G/ADSL2+ Wireless Firewall Router
• Wireless Security with WPA-PSK/WPA2-PSK support
Standards
• Wireless Distribution System (WDS) repeater function support
• BiPAC 7402X series -A: Annex A & Annex M
• Wi-Fi Protected Setup
• BiPAC 7402X series -U: Annex B & U-R2
IPTV Application * 4 • Annex A and Annex M: ADSL over POTS
• Annex B and Annex U-R2: ADSL over ISDN
• IGMP Snooping
• Virtual LAN (VLAN)
• Quality of Service (QoS)
*Notes:
1. On request for Telco/ISP projects
2. The router may require firmware modification for certain ADSL2/2+/ Annex M DSLAMs.
3. The 3G/HSDPA data rate is dependent on your local service provider and your 3G/HSDPA modem.
4. IPTV applications may require subscribing to IPTV services from a Telco/ISP.
5. Specifications in this datasheet are subject to change without prior notice.
6. The car power cable can be made available as an optional accessory upon request.
Billion Electric Co., Ltd. TEL : +886-2-2914-5665
FAX : +866-2-2918-6731,+886-2-2918-2895
8F , No.192, Sec.2, Chung Hsing Road,
E-mail : sales@billion.com
Hsin Tien City, Taipei County, Taiwan
Copyright © Billion Electric Co., Ltd. All rights reserved.
Stay Connected & Secure on-the-go
Anytime connection
On public transport
In a meeting
At an event
At the desk
VPN Security
6
separately*
V.070208
BiPAC 7402X series
www.billion.com
3G/ADSL2+ (802.11g)
VPN Firewall Router with USB 2.0 port
- 3G/ADSL for true always-on connectivity
- Mobility assured by 3G support
- Automatically switch between ADSL and
3G as needed
- VPN security
