Summary of Contents for Clarke CLK4

  • Page 1 VARIABLE SPEED JIG SAW ABLE SAW LEG KIT TABLE SAW LEG KIT Part No. 6460200 MODEL No. CLK4 Part No. 6500715 ASSEMBLY INSTRUCTIONS 1106...
  • Page 2 Please note that the details and specifications contained herein, are correct at the time of going to print. However, CLARKE International reserve the right to change specifications at any time without prior notice.
  • Page 3 PARTS LIST s l i s l i FIXING ORDER 1. Pass the coach bolt (6) through the two parts being joined. 2. Slide a washer (7) on to the the coach bolt. 3. Then slide a spring washer (8) on to the coach bolt.
  • Page 4 ASSEMBLY 1. Attach the 490mm lower ( 5 ) cross member (3) to a leg (5). 2. Secure into place using the assembly fixings (11). ( 3 ) ( 11 ) 1. Attach the free end of the 490mm lower cross member ( 5 ) (3) to another leg (5) as shown...
  • Page 5 ASSEMBLY 1. Attach the 500mm lower cross member (4) and another leg (5) as shown. ( 3 ) ( 4 ) 2. Secure into place using the assembly fixings (11). ( 11) ( 5 ) 1. Attach the remaining ( 3 ) lower cross members (3 + ( 4 ) 4) to another leg (5) as...
  • Page 6 ASSEMBLY 1. Fit the top side rails (1) as shown (above the 490mm ( 11 ) lower cross member). 2. Secure into place using 8 assembly fixings (11). ( 1 ) ( 11) 1. Fit the front / rear top rails ( 11 ) (2) as shown.
  • Page 7 GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase. This guarantee is invalid if the product is found to have been abused or tampered with in any way, or not used for the purpose for which it was intended.
