RSW28
Rider Vacuum Sweeper
Operating & Maintenance Manual
Thank you for purchasing a Pacific Floorcare product. Carefully inspect all components for freight damage. If
such damage is discovered, file a "CONCEALED DAMAGE REPORT" immediately with the delivering carrier.
Read this manual carefully and keep it near the machine, protected from liquids and other damaging
substances. Failure to follow the instructions may result in injury or damage to equipment and property.
The contents of this manual are based on the latest product information available at the time of publication.
Pacific Floorcare reserves the right to make changes or improvements without being obliged to apply changes
to the machines previously sold.
New manuals can be downloaded from:
https://pacificfloorcare.com/parts-manuals/
Rev A 121820
Advertisement
Table of Contents
Related Manuals for Pacific Floorcare RSW28
Summary of Contents for Pacific Floorcare RSW28
- Page 1 Rider Vacuum Sweeper Operating & Maintenance Manual Thank you for purchasing a Pacific Floorcare product. Carefully inspect all components for freight damage. If such damage is discovered, file a “CONCEALED DAMAGE REPORT” immediately with the delivering carrier. Read this manual carefully and keep it near the machine, protected from liquids and other damaging substances.
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. GENERAL INFORMATION Page 1.1. Symbols ……………………………………………………………………………… 1.2. Notes …………………………………………………………………………………. 1.3. Manual references ………………………………………………………………….. 1.4. Warranty ……………………………………………………………………………... FEATURES AND SPECIFICATIONS 2.1. Identification …………………………………………………………………………. 2.2. Description and components ………………………………………………………. 2.3. Specifications ……………………………………………………………………….. SAFETY 3.1. Correct use ……………………………………............. 3.2. Misuse ……………………………………………………………………………….. 3.3. -
Page 3: General Information
This manual was delivered with the RSW28, of which it constitutes an integral part. This manual shall remain with the equipment in the event of an ownership transfer. Please keep in a safe place. Purchaser is responsible to forward this manual to any responsible parties. - Page 4 Pacific Floorcare machine whether defective or not. This warranty is in lieu of all other expressed or implied warranties and is extended to the original purchaser/user only.
- Page 5 In case of defective electronic goods, please return them separately from other materials, in order to help us properly handle dangerous waste goods and recycle. Returned components recognized under warranty become the property of Pacific Floorcare. Missing information may result in denial of warranty.
-
Page 6: Features And Specifications
DESCRIPTION AND COMPONENTS The RSW28 rider vacuum sweeper is designed for the care of flat surfaces through the process of brushing and collection of dirt and debris into an onboard waste hopper. The system of power is supplied by a series of batteries, which power all the motors and the electrical controls. -
Page 7: Specifications
2.3. SPECIFICATIONS RSW28 SWEEPING WIDTH 28.7 in / 728 mm 39,180 ft²/h / 3640 m²/h CLEANING CAPACITY UP TO RUN TIME 4 hrs 2,448 cu in. - 10.6 gal / 40 ltr WASTE HOPPER CAPACITY FILTERING SURFACE 32.3 ft² / 3 m²... -
Page 8: Safety
3. SAFETY 3.1. CORRECT USE The RSW28 has an intended use to clean flat floors or floors with maximum slope of 8%. 3.2. MISUSE Read all machine labels and do not cover, alter or remove labels. Pacific Floorcare will not be held responsible for improper use of the machine. -
Page 9: Operator Qualification
We recommend properly training operators before machine use. We recommend operators read and understand information and procedures outlined within this manual. Pacific Floorcare is not responsible for any possible damage to people and/or things caused by the non-observance of the instructions dealt within this manual. -
Page 10: Safety Devices
Figure 3.6 3.6. SAFETY DIAGNOSTIC ALERTS The RSW28 Rider Vacuum Sweeper is equipped with a system that flashes error codes on the battery charge indicator. The flash series will give the operator an indication of the error and the table below presents a solution to correct the error. - Page 11 Not used. Check the connections of the motor, its Motor not connected or false contact on the motor functionality and integrity. Check the motor brushes and replace if necessary. circuit. Fault inside the controller. Check the regulator. Check the wiring of the potentiometer Faulty potentiometer.
-
Page 12: Dangers
All maintenance operations must be performed with the machine turned off. PACIFIC FLOORCARE realizes – starting from the design of the machine - all the dangers that can occur while the machine is operating in order to prevent or at least low the operator’s accidents. -
Page 13: Safety Signals
3.8. SAFETY SIGNALS Safety signals include: Signals are triangular shaped with black colored DANGERS in yellow field pictograms Signals are circular shaped with black colored in PROHIBITED white field red-crossed pictograms What is it? NEVER remove covers in which components are still moving. In phase of installation/maintenance the machine must be turned off and the ignition key removed from the control board. - Page 14 Explosion danger What is it? Only charge batteries in a well ventilated area and keep away from heat What to do and corrosive substances. What is it? Risk of crushing or pinching due to overturning of the recovery tank. What to do Take extreme caution while working in the limited area of the battery compartment.
-
Page 15: Instructions For Starting And Use
4.1. TRANSPORT AND HANDLING The RSW28 is shipped in specially designed packaging to ensure safe delivery. Figure 4.1 shows the center position indicated with a black arrow. Forklift tines must be placed in such a way as the black arrow is at the center of them. -
Page 16: Storage
When handling the machine, ensure the load is balanced and secure. Avoid handling on uneven surfaces. Machine dimensions and mass are explained in section 2.3. We strongly recommend authorized personnel for handling operations. LOADING SYSTEM Figure 4.2 4.2. STORAGE In case the machine is not immediately installed, it has to be kept in a dry and secure. Humidity must be lesser than 80 % and storage temperature between 37°... -
Page 17: Installation
4.5. INSTALLATION The installation must be done by authorized personnel. 4.5.1 BATTERY INSTALLATION Please follow the instructions below to install the batteries: The battery compartment is under the seat Lift the seat cover to expose the battery compartment (Figure 4.5.1 detail 1) ... -
Page 18: Control Devices
4.6. CONTROL DEVICES 4.6.1. Control Panel The control panel controls the main functions of the machine. (Figure 4.6). Figure 4.6 POS. IMAGE FUNCTION SAFETY DIAGNOSTIC ON/OFF KEY SWITCH FORWARD-REVERSE BATTERY CHARGER INDICATOR FILTER SHAKER HORN... -
Page 19: Control Panel
Forward / Reverse switch and slowly squeeze the accelerator using the right hand. The accelerator lever starts the vacuum motor and brushes of the RSW28. Side brush control lever (picture 4.7 detail 1): push the lever down and the side brush will lower to the floor. - Page 20 4.7.2 MAIN BRUSH REPLACEMENT Remove the key from the ignition key switch. Remove the plastic protection guard on the left side of the machine. Remove the panel protection in order to reach the main brush. Remove the brush support. ...
-
Page 21: Main Brush Replacement
4.7.3 SIDE BRUSH REPLACEMENT Remove the key from the ignition key switch. Raise the side brush with the brush control lever as described in section 4.7.1. Remove all the screws that secure the side brush from the top of the center hub (picture 4.7.3 detail 1). ... -
Page 22: Vacuum Motor Maintenance
4.7.5 VACUUM MOTOR MAINTENANCE Regularly check the operation and efficiency of the vacuum motor. Accessing the vacuum motor: Remove the key from the ignition key switch. Lift the seat cover to expose the battery compartment and vacuum motor (figure 4.7.5 detail 1). ... -
Page 23: Maintenance
MAINTENANCE TABLE It is essential to perform scheduled routine maintenance. Use the table below as a reference. Service and maintenance should be performed by authorized personnel only. For assistance and spare parts contact Pacific Floorcare. OPERATION INTERVENTION HOW OFTEN... -
Page 24: Battery Water Levels
5.2.1 BATTERY WATER LEVELS In order to check the batteries water levels follow the steps below: By means of a hydrometer draw a small quantity of electrolyte so that the floater reaches the surface Make sure that the float inside the hydrometer is not blocked ... -
Page 25: Checking The Electrical System
CHECKING THE ELECTRICAL SYSTEM The electrical system must be checked every two years. Immediately replace any defecting, worn or damaged components. Do not continue to use the machine unit the repairs are completed by authorized personnel. All maintenance and repairs must be done by authorized personnel. 5.4 TESTING SCHEDULE Check Frequency... -
Page 26: Maintenance Log
5.5 MAINTENANCE LOG DATE NAME NOTES INITIALS... - Page 27 Short description of defect: Detective mechanical component Incorrect functioning Electrical system failure Motor failure Missing component Excessive noise Water leakage Other Customer’s notes : Suggestions on Pacific Floorcare’s products and / or services.
- Page 28 Serial no. Date of installation...
