Summary of Contents for Bolens HUSKY 1476
-
Page 2: General Safety Precautions
GENERAL SAFETY PRECAUTIONS Study your manual. Know your tractor before Preventing accidents is the responsibility of every operating it. Take time to operate the unit in the safest equipment operator. The following general safety manner. precautions must be fully understood and followed by every operator of this tractor and its attachments. -
Page 3: Table Of Contents
This is an operational and general maintenance manual only and does not cover major repair. All major repair work must be performed by an authorized BOLENS DEALER or the factory warranty is void. Bolens equipment is carefully engineered to give good performance if properly operated and maintained. -
Page 4: Serial Number
Transmission oil capacity ......10 quarts Air cleaner ..........Dry type To ensure prompt service when repairs or adjust- Drive ........Hydrostatic transmission ments are required, your Bolens Dealer must have Speed. Infinitely the following information. variable ......Forward: approx. 0-8 mph Reverse: approx. -
Page 5: Controls
Location of tractor model and serial number ....Top left side of heat shield Location of engine model and serial number ......Front of engine cowling 5. Throttle. Pull throttle knob out one-half way for starting. More or less throttle may be required due to grade of fuel and temperature variations. -
Page 6: Pre-Operational Checks
Keep this manual available at all times, read it mounting screws “B” and generator adjusting screw “A”. carefully; if you have any questions that are not answered Pivot generator outward from engine until proper tension in the manual, consult your Bolens dealer. is obtained. 6 ... -
Page 7: Stopping The Engine
OPERATION BEFORE DRIVING THE HUSKY, THE OPERATOR SHOULD BE FAMILIAR WITH THE LOCATION AND ... -
Page 8: Wiring Diagram
Engine will not turn over Starts only after repeated tries Stalls in a few seconds Stalls when hot Idles rough Engine overheats Cannot put transmission control in neutral or park * See Engine Manual or your Bolens Dealer. WIRING DIAGRAM 15 ... -
Page 9: Optional Equipment
OPTIONAL EQUIPMENT REAR TIRES LAWN & GARDEN TERRA TIRE KIT TERRA TIRE KIT (26 X 12.0-12) (26 X 12.00-12) MODEL NO. 18017-01 MODEL NO. 18016-01 Figure 27 Figure 28 STANDARD AGRICULTURAL TIRE STANDARD LAWN & GARDEN TIRE KIT (27 X 8.50-15) KIT (27 X 8.50-15) DUAL WHEEL KIT (27 X 8.50-15) -
Page 10: Power Take-Off (P.t.o.)
WHEEL WEIGHT KIT POWER TAKE‐OFF (P.T.O.) Drive shaft delivers power directly from power take-off (P.T.O.) to attachment – front, rear and center-mounted. Switching powered attachments requires only a short time. Slide universal joint over end of splined power take-off shaft liberally greasing shaft, align holes in joint and shaft, and secure with special cotter pin. -
Page 11: Maintenance Guide
MAINTENANCE GUIDE EVERY 10 HOURS EVERY 25 HOURS EVERY 50 HOURS OF OPERATION OF OPERATION OF OPERATION If tractor is stored, battery charge should be Check battery checked every 60 days and recharged if necessary. Check air in tires ( 8 to 12 lbs.) Check engine crankcase oil See Engine Manufacturer’s Manual Drain engine crankcase oil (left side of engine) -
Page 12: Storing Your Husky Tractor
Bolens approval of use attachments manufactured by other manufacturers is limited to assurance that such use will not void Bolens warranty on the Bolens equipment to which the outside manufactured attachments are adapted. The responsibility for the design, performance, durability, safety and operation, service repair availability, and warranty obligation remain with the outside manufacturer.
Need help?
Do you have a question about the HUSKY 1476 and is the answer not in the manual?
Questions and answers
The hydraulic pressure has failed on my Bolens 1476 Husky. How do I check and add fluid to the hydraulic system? Is the hydrostatic transmission fluid mixed with the hydraulic system, sharing the same reservoir? Thx
For the Bolens 1476 Husky:
- The manual specifies using ATF or Dexron fluid for the hydraulic system.
- The fluid used for the hydraulic system and the hydrostatic transmission is the same.
- Check the fluid level using the dipstick marked for ATF.
- To add fluid, locate the fill plug or dipstick tube and pour in ATF as needed to reach the correct level.
The hydraulic fluid and transmission fluid are not separate; they share the same system.
