- Page 1 User Guide DynamicCourtesyBox Technology Serving Desing Danish craftmanship Mediterranean soul...
-
Page 3: Table Of Contents
TABLE OF CONTENTS EC REGULATIONS AND SECURITY SAFETY INSTRUCTIONS SYSTEM DESCRIPTION CONTROLS INPUT CONNECTORS AHLINK AHNET PROTOCOLS INFORMATION ON DISPOSAL WARRANTY TERMS AND CONDITIONS... - Page 4 WELCOME Thank you for purchasing an ARTHUR HOLM product. Our product range has been designed for a seamless integration and for a maximum reliability. Please, read this installation and operating instructions carefully and keep them in a safe place for future reference.
- Page 5 ABOUT US The Company Arthur Holm has its origins in the Danish furniture designer Jorgen Alex Jensen, who was active during the sixties and the seventies. His design inspiration and his concept of ergonomics have been continued by his family, who is the design force behind Arthur Holm product range. The...
-
Page 6: Ec Regulations And Security
EC REGULATIONS AND SECURITY ATTENTION: Do not disassemble or modify the device in any way. This symbol warns of the presence of dangerous un-insulated voltages inside some of the components, of sufficient magnitude to expose people to risk of electronic shock. This symbol draws attention to important use and maintenance instructions in the manual that accompanies the unit. - Page 7 SAFETY INSTRUCTIONS Wiring connected to hazardous voltage requires installation by qualified personnel or the use of ready-made flexible cables. For your security, your equipment must be connected to an elec- trical outlet with grounding connection protection. Since the plug is used to disconnect the device, the operating electrical outlet must be in an easily accessible place.
-
Page 8: System Description
R422 and the open/ close button can be disabled or locked. The CourtesyBox can also be daisy chained with all the rest of Arthur Holm motorised products using CAT6 cables for control. The Courtesy Box is created to be installed in horizontal surfaces of furniture. -
Page 9: Controls
CONTROLS OPEN/CLOSE button: Press this button to open or to close the connection box. Make sure that no objects or body parts can obstruct the movements. INPUT CONNECTORS AHnet: RJ45 CAT5 connector for addressable RS422 control. There is a loop through connector to use as signal RS422 output. You can connect up to 30 monitors on the same RS422 bus Termination: Active (ON) the termination ONLY on the last monitor of the RS422 bus... -
Page 10: Ahlink
AHLINK AHlink is used to control and set-up the unit. By default, the AHlink signal on the unit is deactivated. To activate the AHlink signal, press during 5 seconds the Up and Down button located on the cover plate. The unit will automatically deactivate the AHlink signal if there is no device (mobile or tablet) connected during more than 2 minutes. - Page 11 AHLINK If the device does not appear window, AHlink signal is not active. To activate it, press during 5 seconds the Up and Down button located on cover plate. If your unit still does not appear, power cycle the unit and press again during 5 seconds the Up and Down button.
- Page 12 AHLINK The first line shows the model name of the device. SERIAL Serial number of the unit Firmware version Controls the Up and Down screen movements COMMAND: Information of the last AHnet command received from RS422 port SENSORS: Indicates sensor status. S1: indicates the screen is completely closed S2: indicates the screen is completely opened...
-
Page 13: Ahnet Protocols
AHNET PROTOCOL Communications protocol Speed and configuration BAUD RATE 38400 COMMUNICATION RS422 DATA BITS CONNECTION RJ45 PARITY NONE WIRING CAT-5 STOP BITS Wiring Diagram 1. Data TX + 2. Data TX – 3. Data RX + 4. NC 5. NC 6 .Data RX RJ-45 7. - Page 14 AHNET PROTOCOL Commands COMMAND DESCRIPTION RESPONSE GO UP FB XX 08 01 00 FA XX 01 01 00 GO DOWN FB XX 08 00 00 FA XX 01 00 00 BUTTON LOCK FB XX 08 05 00 FA XX 04 01 00 BUTTON UNLOCK FB XX 08 04 00 FA XX 04 00 00...
-
Page 15: Information On Disposal
INFORMATION ON DISPOSAL FOR USERS OF WASTE ELECTRICAL & ELECTRONIC EQUIPMENT This symbol on the products and/or accompanying documents means that used electrical and electronic products should not be mixed with general household waste. For proper treatment, recovery and recycling, please take these products to the designated collection points, where they will be accepted on a free of charge basis. -
Page 16: Warranty Terms And Conditions
WARRANTY TERMS AND CONDITIONS Albiral Display Solutions warrants this product against manufacturing defects and workmanship for a period of two (2) years from the date of purchase, subject to the conditions below. Electrical, electronic boards, engine, mechanical parts, accessories and power supply are warranted against manufacturing defects and workmanship for a period of two (2) years from the date ot purchase. - Page 17 If you have any doubts concerning the terms of this warranty, please contact: business@albiral.com +34 938 502 376 Copyright © Dec. 2020. All rights reserved Albiral Display Solutions SL. Registered trademarks: Albiral, Arthur Holm, Pixtron Broadcast...
- Page 20 Patents P27178ITEP P27178RUPC MU17180ES00 P27178USPC MU17301ES00 P27284DEEP MU17322ES00 P27284EPPC MU17413ES00 P27284ESEP MU17445ES00 P27284GBEP MU17854ES00 P27284RUPC MU17868DEPC P27284USPC MU17868RUPC P27715ESEP P24821DEEP P28089DEEP P24821ESEP P28089ESEP P24821GBEP Fàtima 25, Sant Hipòlit de Voltregà P28089ITEP P24821USPC 08512 Barcelona – Spain P28089USPC P27178DEEP tel: +34 93 850 23 76 / 23 83 P28090EP00 P27178EPDV01 fax: +34 93 850 25 50 / 23 72...
