Apollo

Quick Start Manual

Getting Started
See the Important Safety and Product Information guide in the product box for
product warnings and other important information.
The MS-WB670 hideaway stereo is a stereo that you control using a Fusion
remote control, Garmin chartplotter, or other Fusion stereo on the same network.
®
To help you understand how the MS-WB670 hideaway stereo works, this manual
contains instructions for using the stereo with a ERX400 remote control. If you
are controlling this stereo using Garmin chartplotter or other Fusion stereo, see
the chartplotter or stereo owner's manual for more information.
Getting the Owner's Manual
You can get the latest owner's manual and translations of manuals from the web.
1 Go to www.fusionentertainment.com/manuals/ms-wb670.
2 Select a manual.
Stereo Buttons and Status LEDs
Because this device is designed to be installed in a location that may not be
easily accessible, almost all playback and device interaction is done through a
network-connected remote control, stereo, or chartplotter. In some instances, you
may need to watch the LEDs or press the buttons on the device itself.
2
MS-WB670
™
WARNING
Stereo Buttons
Press to turn on the stereo.
Press and hold for two seconds to turn off the stereo.
Press to make the stereo discoverable to BLUETOOTH
and Press and hold both buttons together for ten seconds to reset the stereo to
factory settings.
Status LEDs
Icon LED Activity LED Status
®
Solid The stereo is receiving power.
Blinking The stereo is turning on.
Solid The stereo is on and operating normally.
Off The stereo is off.
Blinking The stereo is communicating using Ethernet.
Blinking The stereo is discoverable to BLUETOOTH devices.
Solid The stereo is connected to a BLUETOOTH device.
Controls
NOTE: These stereo controls are available when you use a connected remote
control, such as a Fusion ERX400. If you control the stereo using a chartplotter
or another stereo on the network, you should see the owner's manual for that
device for more information.
devices.
®
