Operating and assembly manual: electric tankless water heater
for central heating systems (Electric heating boiler)
Basic series:
Uhlan (AsPC-S)
Corporal
(AsP)
Sergeant
(AsBN)
Major
(AsZN)
Ensign
(AsC)
Mobil
(AsMB)
Industrial series:
Hussar
(AsHZ)
Battalion
(AsB III)
Please see video prior installation
Elterm M.M.Kaszuba Sp.J., ul. Przemysłowa 5, 86-200 Chełmno
1
www.elterm.pl
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Elterm Uhlan AsPC-S
Summary of Contents for Elterm Uhlan AsPC-S
- Page 1 (Electric heating boiler) Basic series: Uhlan (AsPC-S) Corporal (AsP) Sergeant (AsBN) Major (AsZN) Ensign (AsC) Mobil (AsMB) Industrial series: Hussar (AsHZ) Battalion (AsB III) Please see video prior installation Elterm M.M.Kaszuba Sp.J., ul. Przemysłowa 5, 86-200 Chełmno www.elterm.pl...
- Page 2 Elterm boilers technical data Uhlan (AsPC-S) Corporal Sergeant (AsP) (AsBN) Major Ensign (AsZN) (AsC) Hussar Battalion Mobil (AsHZ) (AsB III) (AsMB) Elterm M.M.Kaszuba Sp.J., ul. Przemysłowa 5, 86-200 Chełmno www.elterm.pl...
- Page 3 Colonel, Sergeant, Major, Hussar Colonel, Sergeant, Major, Hussar Uhlan power 4-12kW power 15-24kW power 4-12kW Ensign Battalion Mobil power 4-12kW (CH) / 12-21kW (DHW) power 30-48kW power 4-24kW Elterm M.M.Kaszuba Sp.J., ul. Przemysłowa 5, 86-200 Chełmno www.elterm.pl...
- Page 4 5 x 25 5 x 50 5 x 70 5 x 120 * The exact cross-section of the power cord is selected by an electrician based on an analysis of local conditions. Elterm M.M.Kaszuba Sp.J., ul. Przemysłowa 5, 86-200 Chełmno www.elterm.pl...
-
Page 5: Hydraulic Assembly
Heating installation should be flushed prior use and filled with water or anti-freeze fluid (1,5 bar). CONNECTION OF DHW SET (option) Before connecting DHW set please familiarize yourself with separate electrovalve manual. Elterm M.M.Kaszuba Sp.J., ul. Przemysłowa 5, 86-200 Chełmno www.elterm.pl... -
Page 6: Electrical Assembly
Terminal B – use to connect temperature sensor 1 to boiler’s body – central heating function (CH) Terminal C - use to connect temperature sensor 2 to hot water tank equipped with coil – hot utility water (HUW) Elterm M.M.Kaszuba Sp.J., ul. Przemysłowa 5, 86-200 Chełmno www.elterm.pl... - Page 7 300 seconds should be sufficient for bleeding boiler and installation, if it isn’t - please turn the boiler off and on again to repeat activity. Elterm M.M.Kaszuba Sp.J., ul. Przemysłowa 5, 86-200 Chełmno www.elterm.pl...
- Page 8 P05 – Maximum boiler operating temperature – DHW (with DHW set only) Shows set operating temperature, increase temperature up to 65°C, decrease temperature down to 5°C, ↑ ↓ confirm setting (50 is recommended), go to P06 function. → Elterm M.M.Kaszuba Sp.J., ul. Przemysłowa 5, 86-200 Chełmno www.elterm.pl...
- Page 9 6 – HUW temperature 50°C (for HUW set only), go to P10 function. → Note: upon selecting P09 function, boiler automatically enters bleeding mode – please wait 300 seconds for it to start operating properly. Elterm M.M.Kaszuba Sp.J., ul. Przemysłowa 5, 86-200 Chełmno www.elterm.pl...
- Page 10 – during this time only central heating pump is activated, heaters remain idle. 300 seconds should be sufficient for bleeding boiler and installation, if it isn’t - please turn the boiler off and on again to repeat activity. Elterm M.M.Kaszuba Sp.J., ul. Przemysłowa 5, 86-200 Chełmno www.elterm.pl...
- Page 11 4 or 5 and to 1 or 2 if the increase is too fast. Elterm boilers are equipped in AntiStop function. Automatics turns the pump on for one minute once every 14 days, what prevents it's rotor from seizing. AntiStop operates independently from on/off mode. It is...
-
Page 12: Troubleshooting
9. Boiler’s main fuse is activated Insufficient fuses amperage Replace with appropriate fuse size Disconnect some of the heaters Possible heater short circuit Locate defective heater and disconnect it Replace it in case of insufficient power Elterm M.M.Kaszuba Sp.J., ul. Przemysłowa 5, 86-200 Chełmno www.elterm.pl... - Page 13 42kW, 45kW, 48kW and boiler cascades 1,5MW (each boiler up to 48kW) Models: AsPC-S, AsP, AsBN, AsZN, AsD, AsC, AsBI, AsBN-W, AsZN-W, AsD-W, AsC-W, AsDC-W, AsBII, AsHZ, AsHN, AsBIII, AsBIV, AsMB , manufactured at the Elterm production plant, are in conformity with the applicable provisions of the following EC Directives:...
-
