- Page 1 VERSAPOUR VALVES Installation, Operation & Service Manual www.lancerbeverage.com...
-
Page 2: Table Of Contents
5.6. Label Size ........................... 11 Trouble Shooting ......................11 Certificate of Warranty ....................13 www.lancerbeverage.com Page 2 of 13 Hoshizaki Lancer reserve the right to change specifications without notice. Images are for illustration purposes only as product may vary. No 066 30 October 2017... -
Page 3: Specifications And Features
SODA/WATER BUTTON: Optional kit that can be retrofitted in field www.lancerbeverage.com Page 3 of 13 Hoshizaki Lancer reserve the right to change specifications without notice. Images are for illustration purposes only as product may vary. No 066 30 October 2017... -
Page 4: Safety Information
• Turn on carbonator water supply and syrup supply to dispenser. www.lancerbeverage.com Page 4 of 13 Hoshizaki Lancer reserve the right to change specifications without notice. Images are for illustration purposes only as product may vary. No 066 30 October 2017... -
Page 5: Adjust Water Flow
• To obtain desired water flow rate, use a screwdriver to adjust water flow control. www.lancerbeverage.com Page 5 of 13 Hoshizaki Lancer reserve the right to change specifications without notice. Images are for illustration purposes only as product may vary. No 066 30 October 2017... -
Page 6: Adjust Water To Syrup Ratio
VersaPour Manual 3.4. Adjust Water to Syrup Ratio • Hold LANCER ratio cup under the syrup separator and activate valve. Check ratio. • To obtain desired ratio, use screwdriver to adjust syrup flow control, (See previous page). • Remove syrup separator. -
Page 7: Cleaning And Sanitizing
Page 7 of 13 Hoshizaki Lancer reserve the right to change specifications without notice. Images are for illustration purposes only as product may vary. No 066... -
Page 8: Assembly Diagrams & Parts List
5.1. VersaPour Assembly (Model 100 SSL, PB, PC 3.0 oz/sec) www.lancerbeverage.com Page 8 of 13 Hoshizaki Lancer reserve the right to change specifications without notice. Images are for illustration purposes only as product may vary. No 066 30 October 2017... -
Page 9: Versapour Assembly Parts List
Versa Pour SSL, short lever www.lancerbeverage.com Page 9 of 13 Hoshizaki Lancer reserve the right to change specifications without notice. Images are for illustration purposes only as product may vary. No 066 30 October 2017... -
Page 10: Mounting Block
SEPARATOR LEV 4.5OZ VERSAPOUR 52-1950 22521950 FLOW CONTROL EXTRACTOR TOOL www.lancerbeverage.com Page 10 of 13 Hoshizaki Lancer reserve the right to change specifications without notice. Images are for illustration purposes only as product may vary. No 066 30 October 2017... -
Page 11: Additional Valve Kits
Page 11 of 13 Hoshizaki Lancer reserve the right to change specifications without notice. Images are for illustration purposes only as product may vary. No 066 30 October 2017... - Page 12 • Faulty wiring and/or pressure • Repair or replace. switch in product line. www.lancerbeverage.com Page 12 of 13 Hoshizaki Lancer reserve the right to change specifications without notice. Images are for illustration purposes only as product may vary. No 066 30 October 2017...
-
Page 13: Certificate Of Warranty
Warranty shall not apply: • If in the opinion of Lancer, the equipment has been used in a situation the equipment has not been designed for; •...
