Summary of Contents for Barco MUIP-2112
- Page 1 MUIP-2112 12.5” LCD User Interface User Guide ENABLING BRIGHT OUTCOMES...
- Page 2 Barco NV Beneluxpark 21, 8500 Kortrijk, Belgium www.barco.com/en/support www.barco.com Registered office: Barco NV President Kennedypark 35, 8500 Kortrijk, Belgium www.barco.com/en/support www.barco.com...
-
Page 3: Table Of Contents
Cable routing ..................................... 11 Desktop support installation (optional)..........................12 3 Maintenance.......................................15 Scheduled maintenance ................................16 Cleaning .......................................16 4 Important information..................................17 Safety information...................................18 Environmental information.................................21 Biological hazard and returns ..............................23 Regulatory information.................................23 EMC notice ......................................24 Explanation of symbols................................27 Legal disclaimer....................................29 Technical specifications................................30 K5902132 (451920612534) /03 MUIP-2112... - Page 4 K5902132 (451920612534) /03 MUIP-2112...
-
Page 5: Welcome
The MUIP-2112 is not intended to be a portable device. The internal battery (if present) is foreseen mainly to prevent the operative-system from crashing in case of momentary drop of the mains power. The internal battery capacity could maintain the unit to work for a time of about one hour, maximum. -
Page 6: What's In The Box
Welcome! 1.1 What's in the box Overview • MUIP-2112 12.5” Computing Touchscreen Module • Power supply 19V 65W AC-DC external unit (depending on model) • Two mains power cords (EU and US versions) (depending on model) • 1 x user guide Keep your original packaging. - Page 7 9. Gigabit Ethernet Connector (LAN1) 10. Gigabit Ethernet Connector (LAN2) 11. Power jack input connector (range 12–24Vdc, nominal 19Vdc) 12. VESA 75 mm mounting screw holes (4x) 13. Strain-relief cable (depending on model – designed according to customer specifications) K5902132 (451920612534) /03 MUIP-2112...
- Page 8 Welcome! K5902132 (451920612534) /03 MUIP-2112...
-
Page 9: Installation
CAUTION: When the display is assembled in the medical system, take care of the fixation of all cables, to avoid unwanted detachment. CAUTION: The equipment is not intended to be sterilized. K5902132 (451920612534) /03 MUIP-2112... -
Page 10: Cable Connections
Opening and closing the rear cover Remove the two rubber-caps which cover the fixation screws. Remove the two fixation screws and remove the rear cover from the MUIP-2112. Image 2–1 To properly close the rear cover, first route the cables as described in “Cable routing”, page 11. Install the rear cover and follow the above steps in reverse order. -
Page 11: Cable Routing
Image 2–4 2.2 Cable routing Open rear cover version The cables can be routed in two different ways: Route the cables straight downwards (as shown below). Image 2–5 Route the cables behind the pin (as shown below). K5902132 (451920612534) /03 MUIP-2112... -
Page 12: Desktop Support Installation (Optional)
Image 2–7 2.3 Desktop support installation (optional) Orientation A desktop support may be included in the MUIP-2112 W00 package. This support can be installed in two different orientations, allowing to achieve a different angle of the display. K5902132 (451920612534) /03... - Page 13 Installation Image 2–8 Installation Place the desktop support in the desired orientation. Install the MUIP-2112 on the desktop support in landscape orientation. Install and tighten the four VESA 75 mm mounting screws. Image 2–9 K5902132 (451920612534) /03 MUIP-2112...
- Page 14 Installation Image 2–10 K5902132 (451920612534) /03 MUIP-2112...
-
Page 15: Maintenance
Maintenance K5902132 (451920612534) /03 MUIP-2112... -
Page 16: Scheduled Maintenance
Maintenance 3.1 Scheduled maintenance About The MUIP-2112 does not require any scheduled maintenance or calibration activities. In case of inconsistencies, please contact Barco Healthcare. 3.2 Cleaning WARNING: Unplug the power cable from the mains power input before cleaning the display. -
Page 17: Important Information
Important information K5902132 (451920612534) /03 MUIP-2112... -
Page 18: Safety Information
If a different power supply is used, further investigation for Safety and EMC requirements have to be performed at system level. • Do not use the supplied AC adapter for powering other devices. K5902132 (451920612534) /03 MUIP-2112... - Page 19 Provide full attention to safety during installation, periodic maintenance and examination of this equipment. • Sufficient expertise is required for installing this equipment, especially to determine the strength of the wall, arm or ceiling suspension for withstanding the display’s weight. Be sure to entrust the attachment of this K5902132 (451920612534) /03 MUIP-2112...
- Page 20 Batteries • This device uses an RTC battery (Mod. CR-2032) and a Lithium Ion battery pack (Mod. BN2012350- 001LPA-01). Both batteries are not user-replaceable. Do not attempt to replace them, contact Barco authorized repair facilities. • Batteries used with this equipment have been tested for compatibility and should only be replaced with approved parts.
-
Page 21: Environmental Information
CAUTION: If the MUIP-2112 is integrated as component in a medical-equipment providing life- support, the user-integrator shall provide the necessary precautions to avoid possible damage, injury or harm to the patients. The MUIP-2112 has no essential performances and the provided Windows OS is not a class-A software. - Page 22 Mainland, marked with the Environmental Friendly Use Period (EFUP) logo. The number inside the EFUP logo that Barco uses (please refer to the photo) is based on the “General guidelines of environment-friendly use period of electronic information products” of Chinese Mainland.
-
Page 23: Biological Hazard And Returns
4.4 Regulatory information Intended Purpose MUIP-2112 is a general hardware platform for use in the hospital environment. It can be used for third party software applications that provide a user interface for medical systems. The equipment can be used in CathLab Examination Rooms &... -
Page 24: Emc Notice
Important information Importers contact information To find your local importer, contact one of Barco’s regional offices via the contact information provided on our website (www.barco.com). FCC class B This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 25 Electromagnetic immunity The MUIP-2112 is tested to be used in the electromagnetic environment specified below. The customer or the user of the MUIP-2112 should assure that it is not used in an environment that exceeds the listed test levels and limits.
- Page 26 GSM 1900, 217 Hz DECT, LTE 1970 Band 1/3/4/ 25, UMTS 2450 2400 – 2570 Bluetooth, Pulse WLAN, modulation 802.11 b/g/n, 217 Hz RFID 2450, LTE Band 7 MUIP-2112 doesn’t contain susceptible components to magnetic fields K5902132 (451920612534) /03 MUIP-2112...
-
Page 27: Explanation Of Symbols
Indicates the device is approved according to the CCC regulations. Indicates the device is approved according to the VCCI regulations. Indicates the device is approved according to the KC regulations. Indicates the device is approved according to the BSMI regulations. K5902132 (451920612534) /03 MUIP-2112... - Page 28 Indicates this device must not be thrown in the trash but must be recycled, according to the European WEEE (Waste Electrical and Electronic Equipment) directive. Indicates Direct Current (DC). Indicates Alternating Current (AC). Stand-by Values for xx and yy can be found in the technical specifications paragraph. K5902132 (451920612534) /03 MUIP-2112...
-
Page 29: Legal Disclaimer
Our goal is to provide you with the most accurate and usable documentation possible; if you discover errors, please let us know. Values for xx and yy can be found in the technical specifications paragraph. K5902132 (451920612534) /03 MUIP-2112... -
Page 30: Technical Specifications
Barco software products are the property of Barco. They are distributed under copyright by Barco NV or Barco Inc., for use only under the specific terms of a software license agreement between Barco NV or Barco Inc. and the licensee. No other use, duplication, or disclosure of a Barco software product, in any form, is authorized. - Page 31 EN 60601-1-2: 2015 EN 55011 / CISPR11 (Class B) FCC CFR 47 Part 15 Subpart B (Class B) GB17625.1-2012; GB4943.1-2011; GB/T9254-2008 Overview Description Configuration for MUIP-2112 W03 Processor (SoC) Intel ® Celeron® N2930, Quad Core @1.83GHz, 2MB Cache. BIOS INSYDE Operating System...
- Page 32 EN 55011 / CISPR11 (Class B) FCC CFR 47 Part 15 Subpart B (Class B) GB17625.1-2012; GB4943.1-2011; GB/T9254-2008 Identification label position The product identification label is located at the back of the MUIP-2112 as illustrated below. K5902132 (451920612534) /03 MUIP-2112...
- Page 33 Code number (12NC or K code) : (Model No.) Serial, number: 72yyww000000 • 72 = Original code (FIMI) • yy = Year • ww = Week (01 to 52) Manufacturer-Date • 000000 = 6-digits progressive number K5902132 (451920612534) /03 MUIP-2112...
- Page 34 Important information K5902132 (451920612534) /03 MUIP-2112...
- Page 36 K5902132 (451920612534) /03 | 2020-11-18 Barco NV | Beneluxpark 21, 8500 Kortrijk, Belgium Registered office: Barco NV | President Kennedypark 35, 8500 Kortrijk, Belgium www.barco.com...
