- Page 1 MUIP-2213 13.3” LCD User Interface User Guide ENABLING BRIGHT OUTCOMES...
- Page 2 Barco NV Beneluxpark 21, 8500 Kortrijk, Belgium www.barco.com/en/support www.barco.com Registered office: Barco NV President Kennedypark 35, 8500 Kortrijk, Belgium www.barco.com/en/support www.barco.com...
-
Page 3: Table Of Contents
Safety information ........................... 18 Cybersecurity ..........................21 Environmental information ....................... 21 Biological hazard and returns – Decommissioning ................23 Regulatory information ........................24 EMC notice ............................24 Explanation of symbols........................27 Legal disclaimer..........................30 Technical specifications ........................31 K5902132 (451920612535) /04 MUIP-2213... - Page 4 K5902132 (451920612535) /04 MUIP-2213...
-
Page 5: Welcome
WARNING: Describes hazards or dangers that might result in personal injury or death. CAUTION: Describes hazards that could damage the product. Gives additional information about the described subject. Gives extra advice about the described subject. K5902132 (451920612535) /04 MUIP-2213... -
Page 6: What's In The Box
Welcome! 1.1 What's in the box Overview • MUIP-2213 13.3” Computing Touchscreen Module • Power cord provided according to final country destination; not provided for the configuration without power supply. • 1x printed User Guide (English) Keep your original packaging. It is designed for this display and is the ideal protection during transport and storage. - Page 8 1 x USB 3.0 port Type A connector Gigabit Ethernet Connector (LAN1) Gigabit Ethernet Connector (LAN2) Power jack input connector VESA 75 mm mounting screw holes (4x), it’s applicable for desk, not wall using. K5902132 (451920612535) /04 MUIP-2213...
-
Page 9: Installation
CAUTION: When the display is assembled in the medical system, take care of the fixation of all cables, to avoid unwanted detachment. CAUTION: The equipment is not intended to be sterilized. K5902132 (451920612535) /04 MUIP-2213... -
Page 10: Cable Connections
2.1 Cable connections Opening and closing the rear cover Remove the two rubber-caps which cover the fixation screws. Remove the two fixation screws and remove the rear cover from the MUIP-2213. Image 2–1 “Cable routing”, page To properly close the rear cover, first route the cables as described in 11. -
Page 11: Cable Routing
Image 2–4 2.2 Cable routing Open rear cover version The cables can be routed in two different ways: Route the cables straight downwards (as shown below). Image 2–5 Route the cables behind the pin (as shown below). K5902132 (451920612535) /04 MUIP-2213... -
Page 12: Desktop Support Installation (Optional)
2.3 Desktop support installation (optional) Orientation A desktop support may be included in the MUIP-2213 package. This support can be installed in two different orientations, allowing to achieve a different angle of the display. K5902132 (451920612535) /04 MUIP-2213... - Page 13 Installation Image 2–8 Installation Place the desktop support in the desired orientation. Install the MUIP-2213 on the desktop support in landscape orientation. Install and tighten the four VESA 75 mm mounting screws. Image 2–9 K5902132 (451920612535) /04 MUIP-2213...
- Page 14 Installation Image 2–10 K5902132 (451920612535) /04 MUIP-2213...
-
Page 15: Maintenance
Maintenance K5902132 (451920612535) /04 MUIP-2213... -
Page 16: Scheduled Maintenance
Maintenance 3.1 Scheduled maintenance About The MUIP-2213 does not require any scheduled maintenance or calibration activities. In case of inconsistencies, please contact Barco Healthcare. 3.2 Cleaning WARNING: Unplug the power cable from the mains power input before cleaning the display. -
Page 17: Important Information
Important information K5902132 (451920612535) /04 MUIP-2213... -
Page 18: Safety Information
Important information 4.1 Safety information General recommendations Read the safety and operating instructions before operating the device. Retain safety and operating instructions for future reference. Adhere to all warnings on the device and in the operating instructions manual. Follow all instructions for operation and use. Electrical Shock or Fire Hazard To prevent electric shock or fire hazard, do not remove cover. - Page 19 Important information Power connection (the configuration without power supply) • Power requirements: The equipment must be powered using medical approved AC/DC power supply . • The medical approved AC/DC power supply must be powered by the AC mains voltage. • The power supply is specified as a part of the ME equipment or combination is specified as an ME system.
- Page 20 Important information Transient over-voltage To fully disengage the power from the device, please disconnect the power cord from the AC inlet. Connections Any external connection with other peripherals must follow the requirements of clause 16 of IEC60601-1 3.2rd. Ed. or Table BBB.201 of IEC 60601-1-1 for the medical electrical systems. To maintain compliance with EMC Regulation, use only shielded interface cables for the connection to peripheral devices.
- Page 21 • Lithium Ion battery pack (Mod. RRC2130), normal voltage: 7.2V. normal capacity: 4.17Ah. • Both batteries are not user-replaceable. Do not attempt to replace them, contact Barco authorized repair facilities. • Batteries used with this equipment have been tested for compatibility and should only be replaced with approved parts.
-
Page 22: Cybersecurity
4.2 Cybersecurity Hospital IT security To prevent unauthorized access to the device, the organization incorporating the MUIP-2213 in their IT network shall have the necessary state-of-the-art policies, processes, standards and other security measures in place to incorporate, support and protect the device into the IT network. This shall include the application of risk management (e.g. -
Page 23: Environmental Information
For more information about recycling of this product, please contact your local city office or your municipal waste disposal service. For details, please visit the Barco website at: http://www.barco. com/AboutBarco/weee Turkey RoHS compliance Türkiye Cumhuriyeti: AEEE Yönetmeliğine Uygundur. - Page 24 Chinese Mainland, marked with the Environmental Friendly Use Period (EFUP) logo. The number inside the EFUP logo that Barco uses (please refer to the photo) is based on the “General guidelines of environment-friendly use period of...
-
Page 25: Biological Hazard And Returns - Decommissioning
Important information 中国RoHS自我声明符合性标志/ China RoHS – SDoC mark 本产品符合《电器电子产品有害物质限制使用管理办法》和《电器电子产品有害物质限制使用达标管理目录》 的要求。 This product meets the requirements of the “Management Rule on the Use Restriction of Hazardous Substances in Electrical and Electronic Products” and the “Management Catalogue for the Use Restriction of Hazardous Substances in Electrical and Electronic Products”. -
Page 26: Regulatory Information
4.5 Regulatory information Intended Purpose MUIP-2213 is a general hardware platform for use in the hospital environment. It can be used for third party software applications that provide a user interface for medical systems. The equipment can be used in CathLab Examination Rooms &... - Page 27 Ce dispositif a été évalué pour et démontré conforme à la Taux IC d'absorption spécifique ("SAR") des limites lorsqu'il est utilisé dans des conditions d'exposition portatifs. FCC responsible: Barco Inc., 3059 Premiere Parkway Suite 400, 30097 Duluth GA, United States, Tel: +1 678 475 8000...
-
Page 28: Emc Notice
Electromagnetic immunity The MUIP-2213 is tested to be used in the electromagnetic environment specified below. The customer or the user of the MUIP-2213 should assure that it is not used in an environment that exceeds the listed test levels and limits. - Page 29 Important information Active power for MUIP-2213 is less than 75 W Electromagnetic Immunity test Compliance level IEC 60601 test levels environment – guidance Electrostatic discharge ± 8 kV contact ± 8 kV contact Floors should be wood, (ESD) concrete or ceramic tile. If ±...
- Page 30 Important information Proximity magnetic fields 8 A/m 8 A/m 30 kHz 30 kHz IEC 61000-4-39 65 A/m 65 A/m 134.2 kHz 134.2 kHz 2.1 kHz Pulse modulation 2.1 kHz Pulse modulation 7.5 A/m 7.5 A/m 13.56 MHz 13.56 MHz 50 kHz Pulse modulation 50 kHz Pulse modulation Immunity to RF wireless communications equipment Test...
-
Page 31: Explanation Of Symbols
Important information 4.7 Explanation of symbols Symbols on the device On the device or power supply, you may find the following symbols (nonrestrictive list): Indicates the device meets the requirements of the applicable EC directives/ regulations. Indicates compliance with Part 15 of the FCC rules (Class A or Class B) Indicates the device is approved according to the UL Recognition regulations Indicates the device is approved according to the UL Demko regulations Indicates the device is approved according to the CCC regulations... - Page 32 Important information Indicates the device is approved according to the VCCI regulations Indicates the device is approved according to the KC regulations Indicates the device is approved according to the BSMI regulations Indicates the device is approved according to the PSE regulations Indicates the device is approved according to the RCM regulations Indicates the device is approved according to the EAC regulations Indicates the device is approved according to the BIS regulations...
- Page 33 Important information Indicates the entity importing the device into the locale. Indicates 10 °C to 35 °C for units provided with battery pack to safely operate within specs. Indicates 10 °C to 40 °C for units provided without battery pack to safely operate within Indicates the device serial number Indicates the device part number or catalogue number...
-
Page 34: Legal Disclaimer
Important information Symbols on the box On the box of the device, you may find the following symbols (nonrestrictive list): Indicates a device that can be broken or damaged if not handled carefully when being stored. Indicates a device that needs to be protected from moisture when being stored. Indicates the storage direction of the box. -
Page 35: Technical Specifications
Barco software products are the property of Barco. They are distributed under copyright by Barco NV or Barco Inc., for use only under the specific terms of a software license agreement between Barco NV or Barco Inc. and the licensee. No other use, duplication, or disclosure of a Barco software product, in any form, is authorized. - Page 36 Important information Protection against electrical Class II shocks Power supply external AC-DC power supply Operating temperature (for 10 °C to 35 °C for units provided with battery pack safety) Operating temperature (for 10 °C to 35 °C performance) Operating humidity 20% to 80% for performance / 10% to 90% for safety (non-condensing) Storage temperature -20 °C to 50 °C...
- Page 37 Important information Overview Description MUIP-2213 STxW wwww Configuration for Processor (SoC) Intel ® Pentium® N6415, Quad Core @1.2GHz, 1.5 MB L2 Cache. BIOS INSYDE Operating System Microsoft Windows 10 Iot LTSC / 11 Iot LTSC Networking Built-in Gigabit Ethernet LAN interfaces (2 ports)
- Page 38 FCC part 15 Class B ICES-003 Level B GB17625.1-2012; GB4943.1-2011; GB/T9254-2008 Identification label position The product identification label is located at the back of the MUIP-2213 as illustrated below. Image 4–1 Code number (12NC or K code) : (Model No.) Serial, number: 72yyww000000 •...
- Page 39 Important information K5902132 (451920612535) /04 | 2022-03-10 www.barco.com...
