  • Page 1 Installation, operating and maintenance ECOLEAN - EAC/EAR Providing indoor climate comfort MIL76E-1003 12-2006...

  • Page 2: Table Of Contents

    All the technical and technological information contained in this manual, including any drawing and technical descriptions provided by us, remain the property of Lennox and must not be utilised (except in the operation of this product), reproduced, issued to or made available to third parties without the prior written agreement of Lennox.

  • Page 3: Preface

    Please the chiller, maintenance information has been included. consult Lennox on the options available in this field. It is important that this manual be stored in a permanent Please do not hesitate to contact one of our employees location in the vicinity of the EcoLean™...

  • Page 4: Data Page For Unit Commissioning

    DATA PAGE FOR UNIT COMMISSIONING UNIT: SERIAL No.: CONTROL PANEL IDENTIFICATION CODE INSTALLATION ADDRESS: INSTALLER: INSTALLER TEL.: INSTALLER ADDRESS: DATE OF COMMISSIONING: CHECKS: SUPPLY VOLTAGE: RATED VOLTAGE OF THE UNIT: UNIT ON RUBBER ANTIVIBRATION MOUNTS GENERAL POWER SUPPLY CONNECTION CONTROL PANEL CONNECTION (OPTION) COMPRESSOR OIL LEVEL INDICATOR HYDRAULIC CONNECTION PURGED OF THE INSTALLATION...

  • Page 5: Technical Data

    1.- GENERAL CHARACTERISTICS 1.1.- TECHNICAL DATA EA C 035 1 S K HY FP TYPE OF UNIT EcoLean High static pressure models: WATER COOLER FP: Version models 0091 to 0211 FP1: Version models 0251 to 1303 C: COOLING ONLY UNITS FP2: Version models 0251 to 1303 R: HEAT PUMP UNITS --- : Standard version...
  • Page 6 1.- GENERAL CHARACTERISTICS 1.1.- TECHNICAL DATA STANDARD AXIAL FAN UNITS • • • • • mode MODELS 0091S 0111S 0151S 0191S 0211S 0251S 0291S 0351S 0431S 0472S 0552S 0672S 0812S Fan type Axial - Direct coupling 900 rpm 1N~230V Fan number m 3 /h 3500 Air flow rate...

  • Page 7: Electrical Data

    1.- GENERAL CHARACTERISTICS • • • • • mode • • • • • • • mode • • • mode • • • • • mode on off 1.2.- STANDARD UNIT ELECTRICAL DATA 0291S 0351S 0431S 0091S 0111S 0151S 0191S 0211S 0251S...
  • Page 8 1.- GENERAL CHARACTERISTICS 1.2.- HIGH STATIC PRESSURE UNIT ELECTRICAL DATA FP VERSION EAC / EAR MODELS 0091S 0111S 0151S 0191S 0211S 1N~230V Voltage V/f (50 Hz) 3~230V - 3N~400V 4,05 4,70 5,78 7,60 8,62 Compressor • • • • • mode Maximum 0,90...
  • Page 9 1.- GENERAL CHARACTERISTICS 1.2.- HIGH STATIC PRESSURE UNIT ELECTRICAL DATA • • • • • mode FP2 VERSION • • mode • • • on off EAC / EAR MODELS 0251S 0291S 0351S 0431S 0472S 0552S 0672S 0812S 1003S 1103S 1203S 1303S Voltage V/f (50 Hz)

  • Page 10: Component

    1.- GENERAL CHARACTERISTICS 1.3.- COMPONENT The EcoLean system comprises a water cooler or air/water pump combined with a series of hydraulic accessories obtaining the Hydraulic or Hydronic version. COMPONENTS: 1.- Detachable water filter 7.- Water pump 2.- Water tank 8.- Air purge valve HYDRONIC VERSION: 3.- Water tank heater 9.- Plate exchanger...

  • Page 11: Operation Limits

    1.- GENERAL CHARACTERISTICS 1.4.- OPERATION LIMITS STANDARD AXIAL FAN UNITS WITHOUT AIR DUCTS COOLING MODE MODELS 0091 TO 0431S 0472 TO 0812S 1003 TO 1303S EAC / EAR Outlet chilled Minimum : +5°C Minimum : +5°C Minimum : +5ºC water temperature Maximum : +12°C Maximum : +12°C Maximum : +12ºC...
  • Page 12 1.- GENERAL CHARACTERISTICS 1.4.- OPERATION LIMITS HIGH STATIC PRESSURE UNITS COOLING MODE AVAILABLE PRESSURE UP TO 200 Pa 0091 to 0211S-FP MODEL UNITS FP VERSION Available static pressure Pa Maximum ambient temperature ºC 0ºC (1) Minimum ambient temperature ºC AVAILABLE PRESSURE UP TO 120 Pa 0251 to 1003S-FP1 MODEL UNITS 1103 to 1303S-FP1 MODEL UNITS FP1 VERSION...

  • Page 13: Pressure Drop In The Water System

    1.- GENERAL CHARACTERISTICS 1.5.- PRESSURE DROP IN THE WATER SYSTEM INSTALLATION ADVISE The units MUST be fitted with a water filter at the inlet to the unit (trapping any particles with a diameter greater than 1 mm.) MODELS EAC / EAR 0091 TO 0431 PRESSURE DROP WITHOUT FILTER EAR/C 0431 EAR/C 0351...
  • Page 14 1.- GENERAL CHARACTERISTICS 1.5.- PRESSURE DROP IN THE WATER SYSTEM INSTALLATION ADVISE The units MUST be fitted with a water filter at the inlet to the unit (trapping any particles with a diameter greater than 1 mm.) MODELS 0472 TO 1303 COOLING ONLY (EAC) PRESSURE DROP WITHOUT FILTER PRESSURE DROP + WATER FILTER (*)

  • Page 15: Hydraulic System Data

    1.- GENERAL CHARACTERISTICS 1.6.- HYDRAULIC SYSTEM DATA WATER FLOW AND AVAILABLE STATIC PRESSURE (Factory supplied; standard water pump and filter). EAC / EAR 0091S MODEL EAC / EAR 0111S EAC / EAR 0151S 0,34 0,38 0,42 0,47 0,53 0,42 0,48 0,53 0,59 0,66...

  • Page 16: Safety Devices

    1.- GENERAL CHARACTERISTICS 1.7.- SAFETY DEVICES It is strictly forbidden to change or remove any safety device. When a safety device is activated, qualified personnel must investigate the unit and rectify the problem. Note: Before resetting a safety device, the cause of the problem must be found and rectified before the unit can be restarted.
  • Page 17 1.- GENERAL CHARACTERISTICS 1.7.- SAFETY DEVICES WATER SYSTEM SAFETY DEVICES (included in units with Hydraulic or Hydronic module) These units contain various safety devices, to protect against system damage. 1.- Flow switch (option for standard unit) Stop the unit if water flow is under limits. Operating with water flow under limits is completely forbidden. 2.- Water filter (supply loose for standard unit) The water filter protects the unit against particles getting inside the circuit.

  • Page 18: Piping Drawings

    1.- GENERAL CHARACTERISTICS 1.8.- PIPING DRAWINGS COOLING ONLY UNITS EAC 0091S TO 0431S Coil Water inlet Water Scroll compressor Fan motor outlet Plate exchanger Hot gas injection valve (option) Filter Expansion drier valve (By-pass valve. Pressure gauge Low ambient temperature -15ºC (option)) Flow switch (option in standard version) Water inlet probe (water inlet regulation)
  • Page 19 1.- GENERAL CHARACTERISTICS 1.8.- PIPING DRAWINGS COOLING ONLY UNITS EAC 1003S TO 1303S Scroll compressor Coil HPR11 HPR12 Fan motor Scroll compressor Hot gas injection valve (option) Expansion Filter Water valve drier inlet Water (By-pass valve. outlet Low ambient temperature -15ºC Plate exchanger (option)) Coil...
  • Page 20 1.- GENERAL CHARACTERISTICS HEAT PUMP UNITS EAR 0091S TO 0431S 1.8.- PIPING DRAWINGS 4 - way valve Coil Water inlet SVR (solenoid valve) Water Scroll compressor Fan motor outlet Plate exchanger HGBP (Hot gas by-pass heating mode. Hot gas injection valve (option) Low ambient cooling mode temperature -15ºC (option))
  • Page 21 1.- GENERAL CHARACTERISTICS 1.8.- PIPING DRAWINGS HEAT PUMP UNITS EAR 1003S TO 1303S Scroll compressor 4-way LP11 LP12 HPR11 HPR12 HPD1 valve Coil HGBP SVR 1 (solenoid valve) Scroll compressor Fan motor SV 1 Expansion (Hot gas by-pass Hot gas injection valve (option) valve heating mode.

  • Page 22: Dimensions

    1.- GENERAL CHARACTERISTICS 1.9.- DIMENSIONS COMPONENT DISPOSITION EAC/EAR STANDARD UNIT 0091S WATER EXCHANGER MAIN SWITCH DISPLAY (OPTION) CONTROL ELECTRICAL BOX COIL • • • • • mode WATER INLET 1375 POWER SUPPLY CABLE ENTRY WATER OUTLET 1195 1 1 9 COMPRESSOR ELECTRICAL BOX EAC/EAR...
  • Page 23 1.- GENERAL CHARACTERISTICS 1.9.- DIMENSIONS COMPONENT DISPOSITION STANDARD UNIT ELECTRICAL BOX WATER EXCHANGER EAC/EAR 0251S-0291S-0351S-0431S COIL DISPLAY MAIN SWITCH CONTROL (OPTION) COMPRESSOR 1375 WATER INLET • • • mode • • on off COMPONENT DISPOSITION POWER SUPPLY WATER OUTLET CABLE ENTRY STANDARD UNIT WITH HYDRAULIC MODULE COIL...
  • Page 24 1.- GENERAL CHARACTERISTICS COMPONENT DISPOSITION 1.9.- DIMENSIONS STANDARD UNIT WATER COILS EXCHANGER EAC/EAR 0472S-0552S-0672S-0812S 1195 MAIN SWITCH (OPTION) DISPLAY CONTROL ELECTRICAL BOX • • • • • mode POWER SUPPLY 1960 CABLE ENTRY 1375 ELECTRICAL BOX COMPRESSORS WATER INLET COMPONENT DISPOSITION STANDARD UNIT WITH HYDRAULIC MODULE WATER OUTLET...
  • Page 25 1.- GENERAL CHARACTERISTICS COMPONENT DISPOSITION 1.9.- DIMENSIONS STANDARD UNIT COILS WATER EXCHANGER EAC/EAR 1003S-1103S-1203S-1303S MAIN SWITCH (OPTION) DISPLAY CONTROL ELECTRICAL • • • • • mode 2250 WATER INLET ELECTRICAL BOX COMPRESSORS COMPONENT DISPOSITION STANDARD UNIT WITH HYDRAULIC MODULE WATER OUTLET COILS WATER EXCHANGER POWER SUPPLY...

  • Page 26: Options

    1.- GENERAL CHARACTERISTICS 1.10.- OPTIONS Standard version unit Hydraulic version unit Hydronic (1) version unit Main ON/OFF switch included included Flow switch included included Water filter Evaporator anti freeze protection Condenser protection guards Thermostatic hot gas injection Three phase protection (Three phase units) HP and LP refrigerant gauges Epoxy coated Al fin coils treated Remote display...
  • Page 27 1.- GENERAL CHARACTERISTICS 1.10.- OPTIONS COMPRESSOR NOISE INSULATION JACKET Each compressor is fitted with a compressor acoustic jacket this provides attenuation of the compressor noise that radiates from the unit when in operation. SOFT STARTER (for 3N~400V units only) It is an electronic element, which reduces the peak compressor starting current up to 40%. INLET PLENUM (models from 0251 to 1303 only) It is a accessory for adapting the condenser air intake to accept a duct.

  • Page 28: Site And Shipping Guidance

    When the unit is received, it should be checked to assure that there are no bumps or other damage, following the instructions on the packaging. If there is damage, the unit may be rejected by notifying the LENNOX Distribution Department and reporting why the machine is unacceptable on the transport agent’s delivery notice. Any later complaint or claim made to the LENNOX Distribution Department, for this type of anomaly, cannot be considered under the Guarantee.

  • Page 29: Antivibration Mounting

    2.- INSTALLATION 2.3.- ANTIVIBRATION MOUNTING Unit Flexible connection Rubber mounting 1.- Mounting on a low sensibility zone Unit Flexible connection with loop Damping spring Metallic structure Support Rubber mounting 2.- Mounting on a medium sensibility zone Unit Flexible connection with loop Metallic and concrete structure Support...

  • Page 30: Installation Clearances

    2.- INSTALLATION 2.4.- INSTALLATION CLEARANCES (*) Clearance around the unit, for all unit versions. Failure to install the units as shown will impact performance and reliability. DETAILING AVM POSITIONS INSTALLATION CLEARANCES EAC/EAR 0091S-0111S-0151S-0191S-0211S 1195 3 meters ( *) 1145 • • •...

  • Page 31: Unit Installation

    2.- INSTALLATION 2.5.- UNIT INSTALLATION 1.- The EcoLean units could be installed outside or inside. 2.- See the minimum clearance diagrams for access - air supply to the batteries in the heating section of the unit. (see page 29) 3.- Assemble the unit on a resistant base, preferably concrete. To prevent vibrations, the concrete base should not come into contact with the building’s foundations.
  • Page 32 2.- INSTALLATION 2.5.- UNIT INSTALLATION 11.- For cooling or heat pump units the hydraulic system must contain the following components pump, buffer tank, expansion device, safety valve, water filter, flow switch. 12.- To obtain the total water system pressure drop add the unit pressure drop + water pipework + fittings and terminal unit pressure drops the water pump can be selected to provide the correct water flow across the heat exchanger.

  • Page 33: Electrical Connections

    2.- INSTALLATION 2.6.- ELECTRICAL CONNECTIONS - BEFORE MAKING ANY ELECTRICAL CONNECTIONS, BE SURE THAT ALL CIRCUIT BREAKERS ARE OPEN AND SUPPLY IS OFF. - IN ORDER TO CARRY OUT THE ELECTRICAL CONNECTIONS, FOLLOW THE ELECTRICAL DIAGRAM SUPPLIED WITH THE UNIT 230V SINGLE PHASE 230V THREE-PHASE 400V THREE-...

  • Page 34: Commissioning And Operation Page

    3.- COMMISSIONING AND OPERATION 3.1.- STEPS TO FOLLOW FOR COMMISSIONING THE UNITS PRE-START Before commissioning the unit check the following: 1.- Check that the voltage is the same as the rated voltage on the specification plate. 2.- Check that the supply to the control system is connected in accordance with the electrical diagram (if incorporates).

  • Page 35: Checking The Water Flow Rate

    3.- COMMISSIONING AND OPERATION 3.2.- CHECKING THE WATER FLOW RATE It is very important that the unit operates at the correct water flow rate. It is dangerous to leave the unit operating at a low flow rate as this could result in serious damage to components as well as the water exchanger. If the unit operates at too high a flow rate, this will also hinder optimum performance.

  • Page 36: Corrosion Resistance Of Copper And Stainless Steel Of Plates Exchanger

    3.- COMMISSIONING AND OPERATION 3.3.- CORROSION RESISTANCE OF COPPER AND STAINLESS STEEL OF PLATES EXCHANGER (WATER EXCHANGER) GUIDE TO MEASURE A ANALYSIS OF THE WATER IN THE CIRCUIT. The resistance guide below is an attempt of give a picture of the corrosion resistance of the stainless steel of the type AISI 316 and pure copper in the water, to a number of important chemical factors.

  • Page 37: Preventive Maintenance

    4.1.- PREVENTIVE MAINTENANCE PREVENTIVE MAINTENANCE PREVENTS COSTLY REPAIRS. We recommend regular and thorough servicing of the LENNOX unit. It is therefore advisable to ask your dealer about maintenance contracts. Check maintenance of the following points (depending on the operating conditions maintenance every 6 months may be necessary).

  • Page 38: Corrective Maintenance

    4.- MAINTENANCE 4.2.- CORRECTIVE MAINTENANCE IMPORTANT MAKE SURE THAT THE UNIT IS COMPLETELY DISCONNECTED FROM THE POWER SUPPLY WHEN CARRYING OUT ANY TYPE OF WORK ON THE MACHINE If some component in the cooling circuit must be replaced, follow these recommendations: - Always use original replacement parts.

  • Page 39: Failure Diagnosis

    4.- MAINTENANCE 4.3.- FAILURE DIAGNOSIS PROBLEM CAUSE ACTION * Disconnected supply. * Check electrical supply. * Main switch set to STOP. * Connect main switch. * No water flow. * Start water pump (and check air in The unit does not start after * Fuses are broken.
  • Page 40 BELGIQUE, LUXEMBOURG RUSSIE Conformément à l’engagement permanent de www.lennoxbelgium.com www.lennoxrussia.com Lennox en faveur de la qualité, les caractéristiques, les valeurs nominales et les dimensions sont susceptibles de modification sans préavis, ceci REPUBLIQUE TCHEQUE SLOVAQUIE n’engageant pas la responsabilité de Lennox www.lennoxczech.com...
