P R O D U C T S P E C I F I C A T I O N S

MODEL NUMBER IDENTIFICATION

Product Tier
EL = Elite
Series
®
Nominal SEER
16 = 16 SEER
Refrigerant Type
C = Air Conditioner (Condenser)
1 = Single Stage Compressor
Cooling Capacity - 17,800 to 60,000 Btuh
EL 16 X C 1 - 036 - 230 A 01
X = R-410A
Unit Type
Cooling Stages
Regional Standards
– (dash) = All Regions
A I R C O N D I T I O N E R S
SEER up to 17.90
Revision Level
Ratings Revision Level
Voltage
230 = 208/230V-1 phase-60hz
Nominal Cooling Capacity
018 = 1.5 tons
024 = 2 tons
030 = 2.5 tons
036 = 3 tons
041 = 3.5 tons
042 = 3.5 tons
047 = 4 tons
048 = 4 tons
060 = 5 tons
EL16XC1
ELITE
Series
®
R-410A
Bulletin No. 210758
July 2016
Supersedes May 2016
1.5 to 5 Tons
