Summary of Contents for AGFEO Business-Line AS 33

  • Page 1 Business-Line: AS 33 AS 34 - Installation...

  • Page 2: Safety Notes

    S0 bus that you are also al- lowed to operate directly on the ISDN The telephone system has a general connec- network. Two digital AGFEO system tel- tion permit (Germany: AAE). Safety notes ¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢ - The telephone system conforms...

  • Page 3: Installation

    - 1 ISDN connecting cable (IAE-single TK-Set, TK-LCR, TK-Bill, TK-Phone and TK- wires) Timer. - 1 PC connecting cable On our homepage "www.agfeo.de", you may find the operating manuals for download. Choosing a location ¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢ - The telephone system must only be in-...
  • Page 4 Opening the housing ¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢ Caution: mortal danger ! Press with a screwdriver onto the tabs in the slits on the connection side of the housing. Before removing the inner cover, pull out The cover is released and you can detach it. the 230 V mains plug to switch off the telephone system.
  • Page 5 Safety notes ¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢ Pay attention to the safety notes telephone system, the network termi- - before installing or removing a nator (NT) or the S0 bus. module, 3. Briefly touch the metal shield of the - before connecting or disconnecting PC/printer socket of the telephone a connecting lead system with your finger.
  • Page 6 Drawing 2a: Pin assignments of the bottom PC board AS 34...
  • Page 7 Drawing 2b: Pin assignments of the top PC board AS 34...
  • Page 8 Drawing 3a: Pin assignments of the bottom PC board AS 33...
  • Page 9 Drawing 3b: Pin assignments of the top PC board AS 33...
  • Page 10 External fixed S0 port (Western socket) ¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢ Point-to-point connection Terminators for the external S0 port You can only connect one ISDN telephone S0 port 1 - switches S100 and S101, system to an ISDN point-to-point connec- drawing 2a (3a) tion. You cannot connect any further ISDN S0 port 2 - switches S200 and S201, terminals.
  • Page 11 "External S0 port (Western socket)". telephone system. ISDN terminals: Connect the four single wires of the in- - AGFEO system telephones digital cluded ISDN cable (Western plug - single - ISDN telephones wires) to the screw terminal: - ISDN cards...
  • Page 12 - internal - internal Wire pair 1 b1 black Wire pair 2 a2 white Wire pair 1: a1, b1 b2 yellow Wire pair 2: a2, b2 Max. distance 130 m S -bus 1a 1b 2a 2b 2 3 4 5 6 7 8 1a 1b 2a 2b 2 3 4 5 6 7 8 1a 1b 2a 2b...
  • Page 13 Connecting a door hands free unit (TFE) ¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢ The telephone system features two inter- TFE 2 - interface conforming to the 2-wire faces for connecting door hands free units: door hands free unit (CE interface) specifica- TFE 1 - interface conforming to the 4-wire tion.
  • Page 14 Switching relays ¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢ You can put the relays to diverse use as indi- whether it is to operate as a pulse relay (3 vidual switching relays R1 and R2 with po- seconds on) or as an On/Off relay. tential-free contacts R11, R12 and R21, R22 for other functions.
  • Page 15 Connecting a printer for printing connection charges ¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢ To print out connection records, the printer You can connect any printer to the tel- must be on all the time and must be con- ephone system’s RS 232C interface to print nected to the telephone system.
  • Page 16 Commissioning You have installed the telephone system. - Once the telephone system has been Now, only a few operations are necessary switched on, you can immediately make before you are able to make telephone calls. internal and external telephone calls. When an external subscriber calls, all con- - Connect terminals.
  • Page 17 As-delivered state The followings settings are active in the as- - Automatic dialling: off delivered state: - Connection record printing: off for - The switches S100 /S101, S201/S202 (ter- all users mination for the external S0 access) are - Dialled phone number printing: none closed and the 100 Ohm terminators are - Cost limit: no entry - Switchable S0 access: the switches S302/...

  • Page 18: Technical Data

    Technical data Housing dimensions 32 x 25 x 8.5 cm (width x height x depth) Ambient temperature - Operation 5 ºC to 40 ºC - Storage -25 ºC to +70 ºC Mains connection 230 V AC, +6%/-10%, 50 Hz - Power consumption 30 VA (full load) External fixed S0 accesses Point-to-point or point-to-multipoint connection,...
  • Page 19 This documentation was elaborated with great care and attention and is revised on a You can only use the numerous ISDN features of your AGFEO-ISDN telephone system if your network operator has provided you with these features. Technical Hotline ¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢...
  • Page 20 Telecommunications equipment 73/23/EWG Low-voltage devices 89/336/EWG Electromagnetic compatibility This is why your telephone system bears the CE mark. Ident. No. 529 354 AGFEO GmbH & Co. KG Modifications and errors reserved. Gaswerkstr. 8 Printed in Germany D-33647 Bielefeld 1992 Internet: http://www.agfeo.de...
