STEREO TALKING MACHINE
Congratulations on your purchase of the Electro-Harmonix Stereo Talking Machine, a
highly customizable envelope-controlled digital vowel filter. The Stereo Talking
Machine (STM) utilizes multiple moving filters to turn your guitar in a growling,
gurgling, snarling monster.
- Special Features of the Stereo Talking Machine -
•
Nine selectable voices: Seven human vowel filter combinations, a classic wah-wah filter,
and the legendary dual band filter of the EHX Bassballs
•
Ability to reverse the sweep of each voice, doubling your sound options
•
Attack/Decay knobs to separately control the rise and fall speeds of the filter sweep
•
Sensitivity control to adapt the effect's response to your playing style
•
Stereo Outputs for true stereo imaging and panning
•
Expression Pedal option to manually control filter sweep
•
Programmable distortion to make your guitar really growl
•
Programmable internal LFO for automatic filter modulation
•
Effects Loop side-chain
•
9 fully programmable presets
WARNING: Your Stereo Talking Machine comes equipped with an Electro-
Harmonix 9.6DC-200 power supply (same as used by Boss
DC 200mA / Center Negative). The Stereo Talking Machine requires 185mA at
9VDC with a center negative plug. The STM does not take batteries. Using the
wrong adapter may damage your unit and void the warranty.
Each voice option in the STM sweeps between two distinct filter settings, mimicking
the way a human mouth moves to form particular vowel sounds. The direction of the
filter sweep can be reversed using the SENSITIVITY knob.
The WAH and BB voice options simulate a classic wah-wah pedal filter and the EHX
Bassballs filter respectively.
Vocal Formant Filter
– VOICE DESCRIPTIONS –
Sensitivity +
EE
EE-ER
AH-I
AH-OO
Factual
I-A
Height
AH
OW-EE
Sensitivity -
Feed
Hurry
Glide
Bayonet
Era
Feud
& Ibanez
®
®
Cereal
Peer
Papaya
Now
Far
Chewy
: 9.6 Volts
1
Advertisement
Related Manuals for Electro-Harmonix Stereo Talking Machine
Summary of Contents for Electro-Harmonix Stereo Talking Machine
- Page 1 : 9.6 Volts ® ® DC 200mA / Center Negative). The Stereo Talking Machine requires 185mA at 9VDC with a center negative plug. The STM does not take batteries. Using the wrong adapter may damage your unit and void the warranty.
- Page 2 – QUICK START GUIDE – This Quick Start Guide will help you get started using your Stereo Talking Machine immediately. For detailed information on all of the Stereo Talking Machine's features and functions, please refer to the rest of this owner’s manual. Setup 1.
- Page 3 – PRIMARY KNOB FUNCTIONS – BLEND – Controls the wet/dry balance of the effect outputs. Turning the BLEND knob to its minimum counter-clockwise position will yield 100% dry signal with no wet. Turning the BLEND knob to its maximum clockwise position will give 100% wet signal with no dry.
- Page 4 – PRIMARY SWITCH FUNCTIONS – PRESETS Encoder – This white knob has three functions: Turn this knob clockwise or counter-clockwise to scroll through the presets, though it will not load the preset. To load the selected preset, press and release the PRESET footswitch.* Press and hold the PRESET knob for 3 seconds to save a preset.* Press and release the PRESET knob (without holding it down) to toggle the Auxiliary functions on and off (the leftmost orange LED will light when...
- Page 5 – AUXILIARY SWITCH FUNCTIONS – In addition to the primary knob functions, the STM has a set of auxiliary knob functions. When enabled, these add options for Fuzz, LFO Filter Modulation and Volume Control. These auxiliary functions can be used independently or in combination with each other and are saved in presets along with the primary function settings.
- Page 6 – AUXILIARY KNOB FUNCTIONS – (BLEND knob) VOLUME – Adjusts the overall output volume of the STM. As you turn the knob clockwise, the volume will increase. (VOICE knob) FUZZ TONE – Increases the treble or high frequency response of the fuzz as the knob is turned clockwise.
-
Page 7: Technical Specifications
– I/O CONNECTIONS – INPUT – Connect the output of your instrument or another effects pedal to this jack. SEND / RETURN – An optional effects loop can be used to add additional effects pedals between the STM’s preamp and filter sections without any alteration to the instrument’s original dynamics. - Page 8 – PRESETS – The STM has nine fully programmable presets. Saving a preset will capture the setting of each of the five black knobs and the auxiliary function settings. Once a preset is saved, the STM will remember its settings after power has been disconnected.
-
Page 9: Warranty Information
Please register online at http://www.ehx.com/product-registration or complete and return the enclosed warranty card within 10 days of purchase. Electro-Harmonix will repair or replace, at its discretion, a product that fails to operate due to defects in materials or workmanship for a period of one year from date of purchase. -
Page 10: Fcc Compliance
- FCC COMPLIANCE - This equipment has been tested and found to comply with the limits for a Note: Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
