FIGURE 1
Lamp & Optical
System Housing
Name &
Data Plate
Lamp Saddle
Power Switch
AC Power Cord
Clamping Collar,
Height Adjustment
Caster
TROUPERETTE IV
Saddle Clamp
Screw
Friction Washer
Vertical Tilt
Locking Knob
Spot Size
Control Handle
Focus Adjusting
Knob
Lamp Yoke
Inner Tube
Clamping Lug
Clamping Stud
Outer Tube
Stand Leg
