AC202
Attention: This modem is shipped temporarily pre-activated for the installer to send up to 50 test commands
before having to send in the activation form.
Determine Installation Type and Options
STEP 1:
Depending upon your requirements, the AC202 module can be installed in a variety of ways.
Type 1 – Standalone GPS Tracking
Type 2 – Solace / Titan Elite Remote Starter
Type 3 – Fortin EVO-ALL (Standalone FW)
Type 4 – Fortin EVO-ONE
Type 5 – ADS AL-CA (Standalone FW)
Complete the wire connections according to the selected Installation Type.
STEP 2:
Please see the following pages for detailed instructions and wiring diagrams.
Position the AC202 Module in an Optimal Location
STEP 3:
Failure to adhere to these suggestions will result in a weak cellular and/or GPS signal and will affect
the performance of the device.
- Secure in upper portion of dash in a hidden location with correct side pointing
skyward .(label will indicate proper orientation)
- Do not cover with metal or position near any source of interference (Vehicle Radio, BCM). Keep a
safe distance of at least 24".
Confirm LED Status
STEP 4:
Yellow: 2 Flashes / Second
Green: 1 Flash / Second
Confirm Vehicle Connectivity and GPS location
STEP 5:
Each AC202 device is shipped pre-activated for the installer to send up to 50 test
commands before having to complete the online activation form. It is HIGHLY recommended that
you follow one of the test procedures below to ensure proper functionality. Alternatively you can
call Certified Tracking Solutions and we will perform the test with you.
Connected / Online
Valid GPS
For Live Tech Support:
Call Certified Tracking Solutions at 1-780-391-3800.
Toll Free 1-855-287-4477(CTS-4GPS)
Monday to Friday 8AM to 5PM MST
AutoConnectGPS.com

QUICK INSTALL GUIDE

Type 6 – ADS iDatastart (Classic, BM&BZ, VWx, HCx)
Type 7 – DEI (DBALL2/3, 4x10 / 5x10)
Type 8 – DEI (REMOTE STARTERS with ESP2)
Type 9 – Mid City (SKSNxxx)
