- Page 1 Log Skidding Winch Models: FX8000 & FX12000 Operator’s Manual and Parts List...
-
Page 2: Table Of Contents
Table of Contents Important References Contents Warranty Features Cautions PTO shaft Before Operationg Operating Tips Clutch Adjustment Roller Chain Adjustment Winching Schematic & Parts Front Assembly Front Assembly Parts Back Assembly Back Assembly Prats Cable Drum Assembly Cable Drum Assembly Prats Important Information for your Records... -
Page 3: Warranty
WARRANTY This product is warranted to be free of defects in materials and work- manship under normal use and service, for a period of one year from the date of purchase, when operated and maintained in accordance with the Operating and Maintenance Instructions supplied with this unit. This warranty does not cover misuse or negligence. -
Page 4: Features
FX Series Winch Features • Five year parts warranty on clutch. • Lower snatch block is open on one side to allow cable to be removed or installed on snatch block. • Lower snatch block is adjustable in height. • Drawbar is standard—to allow towing of a small wagon or trailer behind winch. - Page 5 • Do not operate winch until you have read and understood operating instructions in Operators Manual. • Never allow children or anyone incompetent to operate the winch. • Keep hands, feet, clothing, and hair away from moving parts. • Keep children, pets, and bystanders away from area of operation. •...
- Page 6 The winch is designed for 3 point hitch mounting, and is powered by the tractors Power Take Off. NOTE: If the PTO shaft is too long, the winch bearings or the tractor’s transmission may be damaged if winch is lifted and the shaft is under pressure from being too long.
- Page 7 Installing Cable On Drum Feed cable through the eye of cable guide and down into drum. Cable must be routed under roller on drum band coiler. Insert cable into hole in drum and tighten clamp. NOTE! On first use, pull cable out all the way and wind up cable under load. If cable is loosely wound, it may become tangled while pulling out or while winching.
-
Page 8: Pto Shaft
BEFORE OPERATING CHECK: Cable: • Kinks or frays • Proper routing and installation • Check for frays or week spots • Check cable clamps and condition of choker chains and accessories Correct Mounting • Check all pins for correct installation and lynch pins •... - Page 9 Operating Tips: • Cable must be under tension when winding onto drum Failure to do so may result in cable tangling • Don’t use a longer cable than necessary • Winch has peak pulling performance on a nearly empty spool •...
-
Page 10: Roller Chain Adjustment
Roller Chain Adjustment: Loosen bolts A & B. Chain is tightened using an eccentric tightner. Ro- tate “A” until chain is correctly tensioned. Tighten both A & B. Maintenance • Grease all grease fittings every 50 hours of use or twice a year. •... -
Page 11: Winching
Winching Park the tractor and winch on level, stable ground. Set parking brake on tractor, lower 3 pth winch to ground so dozer blade anchors in ground. Before using winch ensure that cable is free of cuts and kinks,(cable may break if cut or damaged). - Page 13 LW1111 RETAINER LW1112 LW1113 NYLON PULLEY LW1114 FORMED BRACKET LW1115 LW1116 TOP PULLEY FRAME LW1117 TOP PULLEY LW1118 BUSHING LW1119 CABLE GUIDE LW1120 LW1121 WASHER LW1122 CABLE GUIDE EYELET LW1123 MAIN WINCH FRAME (FX8000) LW1124 MAIN WINCH FRAME (FX12000) LW1125...
- Page 15 Description Part # 141 NUT 142 PULLEY LW1302 143 SNATCHBLOCK SWIVEL LW1303 144 BOLT 145 NUT 146 LOCK WASHER 147 DRAWBAR LW1307 148 BOLT 149 NUT 150 NUT 151 LOCK WASHER 152 BOLT 153 SNATCHBLOCK BASE LW1308...
-
Page 17: Cable Drum Assembly
LW1203 PLATE LW1205 ENGAGMEMENT PLATE LW1206 BALL LW1207 ENGAGMEMENT PLATE/LEVER LW1208 BOLT LW1209 CABLE CLAMP LW1210 THRUST BEARING LW1211 CABLE DRUM (FX8000) LW1212 CABLE DRUM (FX12000) LW1235 BUSHING LW1213 SHAFT LW1214 CLUTCH PAD LW1215 SPROCKET LW1216 BUSHING LW1217 THRUST BEARING... -
Page 18: Important Information For Your Records
Important Information for your Records Date of Purchase: ______________________________ Selling Dealer: _________________________________ Model Number: ________________________________ Serial Number:_________________________________ Notes:... - Page 20 Manufactured by: EMB MFG INC. 4144 Boomer Line St. Clements, Ontario Canada, N0B 2M0 Tel: 519-699-9283 Fax: 519699-4146...
