Aqua Select
FOR USE WITH:
Aqua Select ® Everest
BRIDGE SYSTEM
(832421B)
CARTONS REQUIRED
(2) 832402B — Aqua Select ® Everest Step
(1) 832405B — Aqua Select ® Crossover and Enclosure
(1) 832406 — Aqua Select ® Gate
This gate is the final component of the Aqua Select ® Everest Bridge System and the Aqua Select ® Everest Entry
System. Prior to installing the gate, please follow the instructions included in the other cartons first.
If you are adding this component after completing the full Aqua Select® Everest step
NOTE
assembly (832402B), you will need to remove the outside handrails to install the gate.
MODEL
TOOLS REQUIRED
• Phillips head screwdriver
• Drill with 1/16" drill bit
Gate System
®
832406
FOR USE WITH:
Aqua Select
GATED ENTRY WITH
IN POOL LADDER
(832406EV)
CARTONS REQUIRED
(
1) 832402B — Aqua Select
(1) 832405P — Aqua Select
(1) 832406 — Aqua Select
(1) 832406SC — Aqua Select
®
Everest
®
Everest Step
®
Pickets
Gate
®
®
Heavy Duty In-Pool Ladder
7939
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Aqua Select 832406
Summary of Contents for Aqua Select 832406
- Page 1 • Drill with 1/16” drill bit This gate is the final component of the Aqua Select ® Everest Bridge System and the Aqua Select ® Everest Entry System. Prior to installing the gate, please follow the instructions included in the other cartons first.
- Page 2 AQUA SELECT ® GATE SYSTEM PARTS PART # MODEL # DESCRIPTION AC HINGEPT Hinge Post AC GATE Gate AC LATCHPT Latch Post AC HINGEMT Mounting Post AC PADLOCK Padlock AC 79073 Optional Gate Closer AC GATELATH Gate Latch...
- Page 3 IMPORTANT SAFETY INSTRUCTIONS PLEASE READ PRIOR TO ASSEMBLY/USE The Ladder must be installed based on Manufacturer’s Instructions • One person on the Ladder/Stair at a time • This Ladder is designed and manufactured for a specific Pool Wall Height and/or Deck of the Pool •...
- Page 4 STEP 2 • The hinge mounting posts (AC HINGEMT) should be installed onto the short handrail posts on the second step of the outside stair- case. • Attach one hinge mounting post to each of the short handrail posts with the long skinny side facing down towards the step.
- Page 5 STEP 4 • Slide latch mounting post (AC LATCHPT) onto hinge mounting post (AC HINGEMT) on left side of step. NOTE: It may be necessary to spread the back of the latch mounting post open to install. Picture here shows view from BEHIND step, the NOTE latch mounting post should face the same way as the hinge post.
- Page 6 STEP 6 - OPTIONAL GATE CLOSER — AC 79073 • The optional gate closer is designed to assist the gravity close feature of your Bridge Entry System. • The gate closer is to be installed on the hinge post in the space provided. Mount the closer onto the hinged post on the •...
- Page 7 HOW TO SET TENSION Turn the center hole away from the • door with the steel bar supplied. Screw the arm into the hole • nearest the gate. • Remove the steel bar and allow arm to close. • To increase or decrease the tension, repeat the above steps one hole at a time until the desired tension is found.
- Page 8 • The use of a step mat is STRONGLY RECOMMENDED with any pool step. Step mats prevent your pool liner from being damaged by slight movements of your pool step. USE MODEL 832213 Aqua Select ® 36” x 48” STEP MAT HOW TO INSTALL YOUR STEP MAT Remove step mat from packaging Place step mat onto the bottom of the pool with the smooth side facing down towards the liner Place fully assembled step on top of the step mat.
