Torque Tester
OPERATION MANUAL
BEFORE STARTING
1. Study this instruction before use.
2. Please wear gloves and goggles when working.
3. Always check for loose wires and cables on and around tester before beginning operation.
4. Keep tester and charger away from water, always store in a dry place and safe environment.
5. Over torque will cause tool damage and personal injury.
6. Never use additional accessories with this tester that were not included and are not from this manufacturer,
doing so could result in damage to the tester.
7. Always operate tester in a clean and organized work place.
8. This tester should always be kept clean, dry, and free from oil and grease.
9. This tester should be recalibrated a period of 1 years, or 5,000 cycles, whichever occurs first.
To contact with local vendor, an authorized repair center for supporting.
10. Always unplug tester before inspecting, cleaning, or performing maintenance on the tester.
WARNING
1 Years
5000 Times
- 1 -
Models covered
MTS-3002
RSR-Series
Advertisement
Related Manuals for Matatakitoyo Torque Tools MTS-3002
Summary of Contents for Matatakitoyo Torque Tools MTS-3002
- Page 1 Models covered Torque Tester MTS-3002 OPERATION MANUAL RSR-Series BEFORE STARTING 1. Study this instruction before use. 2. Please wear gloves and goggles when working. 3. Always check for loose wires and cables on and around tester before beginning operation. 4. Keep tester and charger away from water, always store in a dry place and safe environment.
- Page 2 ■ Temp. Range-Operating : +5℃ to +40℃ ■ Temp. Range-Storage : -20℃ to +70℃ ■ Directions : C.W., C.C.W. ■ Calibration : According to BS7882 method RSR TORQUE TRANSDUCER SPECIFICATION 6 Pins Connector (To MTS-3002) Drive End 3/4” 1” 1-1/2”...
- Page 3 MTS-3002 PARTS MTS-3002 Torque Display DC Adapter Sensor Cable RS-232 Cable DVD DISC MTS-3002 TECHNICAL SPECIFICATION ■ Display : 5 Digits, 7 segment LED (update rate of 5 per second) ■ Temp. Range-Operating : +5℃ to +40℃ ■ Temp. Range-Storage : -20℃ to +70℃...
- Page 4 TRACK MODE 100 Nm Torsion Time AUTO RESET MODE Each test require release torque from 0 Example for click type torque wrench with a single measurement 100 Nm Torsion Delay time Reset 2 Seconds 1 st peak value (Peak hold) HOLD MODE Each test require release torque from 0 Example for click type torque wrench with a single measurement...
