- Page 1 Value & Technology NK1 Series PLC Manual NK1-B4AD2DA-2 Function Board [1st Edition] KOYO ELECTRONICS (WUXI) CO., LTD.
-
Page 2: Table Of Contents
Contents Chapter 1 Preface ...................... 1 Chapter 2 NK1-B4AD2DA-2 Specifications ............. 2 2.1 Introduction ...................... 2 2.2 General Specifications .................. 2 2.3 Input Specifications ..................3 2.4 Output Specifications ..................3 2.5 Wiring ......................... 3 2.5.1 Wiring Guidelines .................. 3 2.5.2 Wiring Diagram .................. -
Page 3: Chapter 1 Preface
Thank you for purchasing our company's NK1 series PLC products! This document is technical information about optional function boards NK1-B4AD2DA-2 used with NK1 series PLC. It mainly introduces the hardware specifications, hardware performance, software settings, external wiring of this function board. When using this... -
Page 4: Nk1-B4Ad2Da-2 Specifications
NK1-B4AD2DA-2 Specifications 2.1 Introduction NK1-B4AD2DA-2 is an analog voltage input /output optional function board for NK1 series PLC. The voltage range is 0-10V. The function board has 12-bit resolution. It has non- isolated 4 analog input channels and 2 analog output channels. -
Page 5: Input Specifications
2.3 Input Specifications Number of Input Channels 4 Range 0-10V Resolution 12 bit Input Impedance 1MΩ ±5% PLC Update Rate 4 input channels per scan Conversion Method Successive approximation Isolation Type None Maximum Error ±0.3% of full scale 2.4 Output Specifications Number of Output Channels 2 Range 0-10V... -
Page 6: Wiring Diagram
Analog Output R37425 Note： After the optional function board is installed on the NK1 series PLC, the registers listed in the table above are provided for the exclusive use of the optional function board. Please do not use these registers for other purposes in the user... -
Page 7: Analog Input Registers
The range of conversion data is 0 ~ 0x0FFF. Note: Please do not apply voltage signals other than 0-10V to the input terminal of this function board, otherwise the option function board and NK1 series PLC main unit may be damaged. -
Page 8: Module Resolution
2.6.3 Module Resolution Analog value （10V） （7.5V） （5V） （2.5V） （0V） 3FF（H） 7FF（H） BFF（H） FFF（H） Digital value （0） （1023） （2047） （3071） （4095）... - Page 9 Koyo ELECTRONICS （WUXI） CO., LTD. Add：21st Floor, Building 1, No.599, Jianzhuxi Road Binhu District, Wuxi, Jiangsu, P.R. China Pc：214072 Tel：0510-85167888 0510-85161393 ： http: //www.koyoele.com.cn KEW-M2523A-2 2020 年 1 月...
