Cadillac XT5 Owner Manual (GMNA-Localizing-MidEast-14590488) - 2021 -

CRC - 7/15/20

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Keys, Doors, and Windows . . . . . . . . . . 6

Seats and Restraints . . . . . . . . . . . . . . . 36

Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Instruments and Controls . . . . . . . . . . 90

Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

Infotainment System . . . . . . . . . . . . . 136

Climate Controls . . . . . . . . . . . . . . . . . . 188

Driving and Operating . . . . . . . . . . . . 196

Vehicle Care . . . . . . . . . . . . . . . . . . . . . . . 275

Service and Maintenance . . . . . . . . . 341

Technical Data . . . . . . . . . . . . . . . . . . . . 353

Customer Information . . . . . . . . . . . . 358

OnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 362

Index . . . . . . . . . . . . . . . . . . . . . . . . 368

Litho in U.S.A.

Part No. 84649902

The names, logos, emblems, slogans,

vehicle model names, and vehicle

body designs appearing in this manual

including, but not limited to, GM, the

GM logo, CADILLAC, the CADILLAC

Emblem, and XT5 are trademarks and/

or service marks of General Motors

LLC, its subsidiaries, affiliates,

or licensors.

This manual describes features that

may or may not be on the vehicle

because of optional equipment that

was not purchased on the vehicle,

model variants, country specifications,

features/applications that may not be

available in your region, or changes

subsequent to the printing of this

owner s manual.

Refer to the purchase documentation

relating to your specific vehicle to

confirm the features.

Keep this manual in the vehicle for

quick reference.

Danger, Warning, and

Caution

Warning messages found on vehicle

labels and in this manual describe

hazards and what to do to avoid or

reduce them.

Danger

Danger indicates a hazard with a

high level of risk which will result

in serious injury or death.

Warning

Warning indicates a hazard that

could result in injury or death.
