Exalux LEDMASTER STUDIO 1 User Manual

LEDMASTER STUDIO 1

1 - GENERAL INFORMATION

This hardware instruction manual contains specifications and important notifica-
tions regarding the safe use of the EXALUX™ LEDMASTER STUDIO 1. Please take the
time to read this manual carefully and thoroughly before installing and operating
the device. We recommend that you keep a copy for future use and transfer it to
the buyer if you resell the device.
EXALUX™ reserves the right to modify and upgrade its range of products, with no
obligation to integrate these changes into products already sold. Therefore, all the
information found in this manual is subject to change without notice.

2 - OVERVIEW

EXALUX™ LEDMASTER STUDIO 1 is a single channel high output constant voltage
LED dimmer. It has been designed to dim up to 360W LED fixtures (depending on
the version), controlled from DMX/RDM console or CRMX transmitter (optional).
This dimmer is integrated in a standard DIN rail enclosure with 5.08mm pluggable
terminal blocks for quick and easy set-up. The LEDMASTER STUDIO 1 is available in
several versions which can be equipped with LumenRadio™ CRMX receiver.
Input
AC
DC

3 - FEATURES

- AC input/output for power supply daisy chain,
- Low side PWM constant voltage output,
- Wired DMX/RDM input/output interface,
- Wireless DMX/RDM integrated receiver (CRMX by LumenRadio™),
- Long range whip, hinged and removable antenna,
- LED indicators, pushbutton, trigger input port,
- DMX address settings, 3x 10 positions rotary switches,
- Custom settings (mode, DMX fail, PWM frequency, dimming curve), 1 x DIP switch,
- Local (manual) dimming control, 16 positions rotary switch,
- Software updates from DMX interface,
- Small form factor, DIN rail, pluggable terminal blocks.
Output
12VDC
30W
24VDC
12VDC
60W
24VDC
7.5Amax/pin
(180W@12V / 360W @24V)
Designation
LM-STUDIO1-AC30-12
LM-STUDIO1-AC30-24
LM-STUDIO1-AC60-12
LM-STUDIO1-AC60-24
LM-STUDIO1-DC360
DMX/RDM Wireless CRMX
-W
-D
(optional)
