Summary of Contents for The Splash Lab TSL.670
- Page 1 TSL.670 Click Clack Waste...
- Page 2 Safety and Warnings Box Contents Technical Data Before You Install How to Install Commissioning The Complete System Maintenance Cleaning Troubleshooting Warranty Spare Parts / Accessories Contact Details TSL.670 MANUAL...
- Page 3 (see back page for more details). Ensure plumbing is installed correctly before activating water supply. All plumbing is to be installed in accordance with applicable codes and regulations. For more information contact: Tel: +44 (0)161 482 7000 Email: technical@thesplashlab.com TSL.670 MANUAL...
-
Page 4: Box Contents
Main body White flat foam washer Clear silicone washer Flat metal washer Fixing nut with screws TSL.670 MANUAL... -
Page 5: Technical Data
Overview The TSL.670 is a steel “click-clack” waste with a slotted overflow and a (1 ¼”) thread connection. Codes Finishes Light Reflectance Value (LRV) TSL.670CS Brushed Stainless Steel TSL.670CP Brushed Copper TSL.670BK Brushed Black TSL.670BR Brushed Brass TSL.670BZ... -
Page 6: Before You Install
Caution The TSL.670 parts must be put together correctly before installation. All parts must be installed correctly before powering up the system. Ensure that connection is to 1 ¼” standard waste pipe. Ensure that the thread on the basin waste fitting is clear for trap to be screwed tight and connection sealed. -
Page 7: How To Install
Once all nuts are tightened, open the Fit waste trap to waste grate, following the water inlet and allow water to drain. trap installation guide. WARNING: Ensure all connections are fully tightened to ensure full seal of the waste trap. TSL.670 MANUAL... -
Page 8: Maintenance
Hairs and other obstructions should be removed from the waste to ensure smooth operation of the sprung cap and that water drains away. The push cap can be unscrewed for access to clear the debris. TSL.670 MANUAL... - Page 9 If further information is required, contact The Splash Lab technical team for more detailed stainless steel care guidelines. TSL.670 MANUAL...
-
Page 10: Warranty
TSL.670: 2 years parts & labour If a defect is found in normal use, The Splash Lab will, at their discretion, repair, provide a replacement part or product, or make appropriate adjustments. Damage caused by accident, misuse, or abuse is not covered by this warranty. Improper care and cleaning will void the warranty. - Page 11 General information info@thesplashlab.com +44 (0) 161 482 7000 Technical support technical@thesplashlab.com For further contact information visit: www.thesplashlab.com TSL.670 MANUAL...
