Projection Distance & Screen Size
Projected Image
Determine the distance between the projector and the wall or screen according to the desired screen size.
Relative Distance (D)
Screen Dimensions (SD)
60"
80"
100"
120"
Note: The dimensions in the table above are for reference only, they are approximate and may slightly differ from the actual values.
SD
Relative Height (H)
146.1 cm 9.6 cm
194.8 cm 9.6 cm
243.5 cm 9.6 cm
292.3 cm 9.6 cm
Projection screen
Screen Dimensions (SD):
The diagonal size of the projection screen (in inches).
Relative Distance (D):
The distance between the projector and the wall or screen (in cm).
Relative Height (H):
The distance from the bottom of the projector to the
bottom edge of the projected image (in cm).
D
H
