axing SPU 48-01 Operation Instructions page 3

Safety advice:
4
Installation and repairs to the equipment may only be carried out by
technicians observing the current VDE guidelines. No liability will be
assumed in the case of faulty installation and commissioning.
4
To prevent damage to your equipment and to avoid possible peripheral
damages, the devices foreseen for wall mounting may only be installed
on a flat surface.
4
Choose the location of installation or mounting such that children may
not play unsupervised near the equipment and its connections. The
location of installation or mounting must allow a safe installation of all
cables connected. The mains cable as well as feeder lines may not be
damaged or clamped by objects of any kind.
4
If possible - please install the Multiswitch underneath the roof or at any
dry location. If installed open-air, make sure to use watertight
connectors!
State of the art 2016-08-18 Technical changes, design modifications,
errors and misprints are subject to change without prior notice
Technical Data:
SPU 48-01
Frequency range SAT 950...2200 MHz
Inputs 4
Outputs 8
Gain typ. 3 dB
Current consumption 70 mA
Switching criteria 14 V, 18 V, 22 kHz
Connectors
Dim. appr. 230 × 145 × 85 mm
Your device is marked with the WEEE symbol (Waste Electronics
and Electrical Equipment). This means that the electrical and
electronic components must not be disposed of as residual waste.
Used electrical and electronic components must be disposed of
WEEE Nr.
separately.
DE14023300
Manufacturer EWR contact adress
AXING AG Bechler GmbH
Gewerbehaus Moskau Am Rebberg 44
8262 Ramsen 78239 Rielasingen
SPU 84-01
8
SPU 84-01 | 48-01
4
basic-line
100 mA
Multiswitches
14 V, 18 V, 22 kHz
DiSEqC 2.0
F
Operation Instructions
