ABB OTA125 Installation Instruction page 3

11
!
Ø5...10 mm
Handles lockable in OFF-position. Handles
lockable in ON-position are available on
request.
13
Pay special attention!
*OTA/OKA 600 OZXB4 mountable under
connection bars only for clearance to
enclosure cover.
Standard M12 hex bolt must be used when
mounting terminal under connection bar.
!
2
2
3
12
OTA/OKA125-160
OTA/OKA200-400
OTA/OKA600
List of OZXB connection terminal types
compatible with OTA/OKA types.
14
OTA/OKA 125-400 OZXB_ mountable on top
of connection bars with provided lock bolts.
OZXB-types that fit
OZXB2L OZXB8 OZXB9
OZXB9
OZXB4*
