AOC SPX432 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

User Manual
SPX432
SPX502
SPX552
SPX652
SPX752
SPX862
Please read this manual before use and retain it for future reference.
www.aoc.com
©2021 AOC. All Rights Reserved.

Advertisement

Table of Contents
loading

Related Manuals for AOC SPX432

Summary of Contents for AOC SPX432

  • Page 1 User Manual SPX432 SPX502 SPX552 SPX652 SPX752 SPX862 Please read this manual before use and retain it for future reference. www.aoc.com ©2021 AOC. All Rights Reserved.
  • Page 2 Safety Instructions TO PREVENT DAMAGE WHICH MAY RESULT IN FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE Warnings and Precautions THIS APPLIANCE TO RAIN OR KNOW THESE SAFETY SYMBOLS MOISTURE. The Socket-outlet should be installed near the apparatus and be easily accessible.
  • Page 3 before re-attaching the power cable 10. Do not defeat the safety purpose of for normal operation. the polarized or grounding-type plug. A polarized plug has two blades with • To avoid the risk of shock or one wider than the other. A grounding permanent damage to the set do type plug has two blades and a third not expose the display to rain or...
  • Page 4 17. An all-pole MAINS SWITCH is a protective earthing used as the disconnect device, connection. the location on the apparatus and WARNING the function of the switch shall be described, and the switch shall Never place a Display in an unstable remain readily operable location.
  • Page 5 CAUTION: Excessive sound pressure from earphones and headphones can cause hearing loss. Adjustment of the equalizer to maximum increases the earphone and headphone output voltage and the sound pressure level. Therefore, to protect your hearing, adjust the equalizer to an appropriate level.

  • Page 6: Table Of Contents

    4.2. PDF Reader Play ....13 4.3. U disk Files Playback and Copy Instructions ....15 4.4. AOC Cloud CMS Software Introduction ......16 4.5. StoreVue Signage (Only available in Taiwan) .... 18 4.6. Operation on the OSD menu 19 Compatibility of the USB device ..

  • Page 7: Unpacking And Installation

    • HDMI cable The supplied power cord varies depending on destination. • Wall Mount kit • AOC Sticker HDMI Cable Wall Mount kit Sticker Power Cord * Items may differ in different locations * Display design and accessories may differ from the images shown.

  • Page 8: Mounting On A Wall

    Product warranty does not cover damage caused by improper installation. 4. SPX432, SPX502, SPX552: For the wall-mounting kit, use M6 mounting screws (having a length 10 mm longer than the thickness of the mounting bracket) and tighten them securely.
  • Page 9 1.4.2. VESA Grid 200(H) x 200(V) mm SPX432 400(H) x 400(V) mm SPX502 3. Install the bracket rail into the back of the display, select suitable screws from...
  • Page 10 Ventilation Requirements for enclosure locating To allow heat to disperse, leave space between surrounding objects as shown in the diagram below. 100 mm 100 mm 100 mm 100 mm...

  • Page 11: Parts And Functions

    Parts and Functions 2.1. Control Panel [ ] button [ ] button • Press and hold for 5 seconds to • Home Menu (Android Launcher: power off. Go to left Icon. • Press to enter DC off state. • Root Menu: Go to Audio VolumeMenu •...

  • Page 12: Input/Output Terminals

    2.2. Input/Output Terminals MICRO SD USB2.0 500mA USB3.0 900mA RS232 (RJ45) HDMI2 IN HDMI1 IN AUDIO OUT AUDIO IN AC IN MICRO SD card AC power input from the wall outlet. Connect to a MICRO SD card. MAIN POWER SWITCH Switch the main power on/off.

  • Page 13: Remote Control

    [ ] POWER button Reserved. Turn OFF the display until power is off. [Source] Button Choose input source. [CMS] button Go to AOC CMS app. [USB] button Go to USB source. [HDMI/PC] button Go to HDMI1 source. ] Time button Go to Time Setup SCH APP.
  • Page 14 2.3.2. Inserting the batteries in the remote control The remote control is powered by two 1.5V AAA batteries. To install or replace the batteries: 1. Press and then slide the cover to open 2. Insert the batteries with the correct polarity (+) and (–).

  • Page 15: Connecting External Equipment

    Connecting External Equipment 3.1. Connecting External Equipment (DVD/VCR/VCD) 3.1.1. Using HDMI video input DVD / VCR / VCD HDMI out RS232 (RJ45) AUDIO IN HDMI2 IN HDMI1 IN [HDMI IN] 3.1.2. Using network interface AUDIO OUT INTERNET...

  • Page 16: Connecting A Pc

    3.2. Connecting a PC 3.2.1. Using HDMI input RS232 (RJ45) AUDIO OUT AUDIO IN HDMI2 IN HDMI1 IN HDMI out [HDMI IN] RS232 (RJ45) HDMI2 IN HDMI1 IN AUDIO OUT AUDIO IN DVI OUT AUDIO OUT [HDMI IN] [AUDIO IN] 3.3.

  • Page 17: Operation

    Operation 4. If you select the empty playlist, the application will guide you to choose media sources. 4.1. Media Player All media files should be located in the Instructions root directory. For example: - Video at /root/movies/ 1. The front page of the media player, - Photos /root/pictures/ this page contains three items: “Play”, - Music /root/music/...
  • Page 18 7. After you start editing the playlist, you will 10. Choose the desired file and press the see the following screen. play button, you can directly play media Source - storage device files. files. Playlist - playlist files. 7-1 in a scroll bar can help you to perform the following items：...

  • Page 19: Pdf Reader Play

    4.2. PDF Reader Play 1. Home page of Pdf app, this page has three items: “Play”, “Compose” and “Settings”. Play : Select playlist to play. Compose: Edit playlist. Settings: Set play properties 5. You could edit or delete a non-empty playlist, just choose the desired playlist with pencil icon.
  • Page 20 8. If you choose “Sort” in the slidebar, you can change the order of files one by one. 9. Select “Settings” on home page, this page has two parts, “Repeat Mode” and “Effect Duration”. Repeat Mode : play mode. Effect Duration : photo effect duration.

  • Page 21: U Disk Files Playback And Copy Instructions

    4.3. U disk Files Playback 7. After selecting the directory to copy to, press the [ ] left / right buttons and Copy Instructions on the remote control to select Paste or Cancel, as shown below. 1. U disk can only have one partition. The format must be FAT32 and the capacity can not exceed 32G.

  • Page 22: Aoc Cloud Cms Software Introduction

    2. Figure 1 is the main interface of the software: used to play the content of the cloud editing program. Display the main status: Current Network, Connect Status, Authorise Status etc. Use AOC CMS to dispatch the programs to clients, the terminal needs to connect to the internet by LAN or WIFI.
  • Page 23 Fig 1 Fig 2 Fig 3 Fig 4 Note: Option 1. Press the remote control [ ] OPTIONS button to enter the Figure 2. 2. This function cannot be used together with the U Player auto play function. Because the two function usage scenarios are different, there will be a conflict when use at the same time.

  • Page 24: Storevue Signage (Only Available In Taiwan)

    4.5. StoreVue Signage (Only available in Taiwan) 4.5.1. Run Application Turn on TV by remote control. =>Click Apps: StoreVue Signage Info: • APP Version > StoreVue Signage App Version • Launch > StoreVue Signage App launch time • Client > StoreVue Signage Client ID •...

  • Page 25: Operation On The Osd Menu

    4.6. Operation on the OSD menu 4.6.1. Boot up and enter into Home 4. In Connection type, select Static IP. Move the remote control rightward to select Settings 5. Input IP, netmask, gateway and DNS (domain name server) manually. 4.6.2. Click the OK button to enter Settings (or simply press the Menu button on the remote control on any...
  • Page 26 4.6.4. Wireless Network (WIFI/ 4.6.5. Wireless Hotspot WLAN) 1. Turn on the Hotspot, and the WiFi network 1. Turn on the wireless network switch. will be automatically shut down. 2. Select a WiFi SSID, and input the 2. Modify hotspot name. password.
  • Page 27 4.6.7. Desktop • Press the “+“ symbol below to import a wallpaper from an external device. 1. Home screen (AOC Cloud CMS and • Keep pressing the Back buttons to exit Default Home are interchangeable). from the Settings menu. The wallpaper will be automatically updated on Home.
  • Page 28 4.6.8. Device Management 5. Quick boot When the device is powered on, after 1. Key Lock (default password is 0000, super PD is shut down via the remote control, password is 6098, super password is for the last signal will be directly displayed logging in and changing password if you upon re-boot.
  • Page 29 8. Power-on signal source c. If this option is set at On, no matter The user may select which signal the whether the USB disk has any multimedia device may jump to for playback each file, as long as Android Launcher is set as time the device is powered off and then the home screen, the system will switch powered on.
  • Page 30 11. OPS Setting B. Quick boot in Device Management is turned on. C. OPS Status in Sleep Mode is turned 4. Screensaver Auto: When the signal source switches to OPS, OPS is started. Always On: Once the device is powered on, OPS is started.
  • Page 31 4.6.12. Language 4.6.10. Regular Boot 4.6.13. Date & Time Invoke the Schedule APP NTP Server: The user may manually input the local NTP server website for quicker network time synchronization. For details on use of Schedule APP, refer to a separate PDF file. 4.6.11.
  • Page 32 4.6.14. System Update The Online Update function is turned on by default. In case of any OTA push, the system will prompt the user whether or not to allow system update. 4.6.15. Factory Reset 4.6.16. About The memory comes in 3GB or 2GB, depending on the specific device.

  • Page 33: Compatibility Of The Usb Device

    Compatibility of the USB device Format of the USB multi-media coder-decoder Video decoding Video Type coder- Container Decoding Coding Channel Remarks decoder Supported size in a range from 48x48 pixels to 1920X1080 pixels File format: Max. frame rate:30fps MPEG1/2 MPEG1/2 Max.
  • Page 34 Supported picture size: frame 48x48 pixels to 1920x1080 pixels File format: Max. frame rate:30fps VC-1 Max. bit rate: 45Mbps Audio coder-decoder: MP2, MP3, AAC, WMA Audio decoding Audio coder- Type Container Decoding Coding Channel Remarks decoder Bit rate: MPEG1/2/2.5 8Kbps~320Kbps, MPEG Decode: MP1, Audio...
  • Page 35 Picture decoding Type Picture coder- Picture Decoding Coding Channel Remarks decoder Decode: Resolution ratio 48X48 to 8176X8176 (1) Row-by-row scanning is not JFIF file format File format: supported. JPEG 1.02 JPG, JPEG (2) Software supports SRGB JPEG. (3) Software supports Adobe RGB JPEG.

  • Page 36: Input Mode

    Input mode HDMI computer mode Available resolution ratio Standard Refresh rate Pixel rate Aspect ratio Horizontal Perpendicular resolution ratio pixel line 60 Hz 25.175 MHz 75 Hz 31.5 MHz WVGA 70 Hz 28.32 MHz SVGA 60 Hz 40 MHz SVGA 75 Hz 57.28 MHz 1024...
  • Page 37 HDMI video mode Available resolution ratio Standard resolution Refresh rate Pixel rate Aspect ratio Horizontal Perpendicular ratio pixel line 3840 x 2160 P 60 Hz 3840 2160 60 Hz 594 MHz 16:9 3840 x 2160 P 50 Hz 3840 2160 50 Hz 594 MHz 16:9...

  • Page 38: Cleaning And Troubleshooting

    Cleaning and Troubleshooting 7.1. Cleaning Caution When Using the Display • Do not bring your hands, face or objects close to the ventilation holes of the display. The top of the display is usually very hot due to the high temperature of exhaust air being released through the ventilation holes.

  • Page 39: Troubleshooting

    7.2. Troubleshooting Symptom Possible Cause Remedy No picture is displayed 1. The power cord is 1. Plug in the power cord. disconnected. 2. Make sure that the power switch is 2. The main power switched on. switch on the back 3.
  • Page 40 After-Images can still be A still picture is displayed Do not allow a still image to be seen on the display after for an over extended displayed for an extended period of the display is powered period of time time as this can cause a permanent off.

  • Page 41: Technical Specifications

    Technical Specifications Display: SPX432 Item Specifications Screen Size (Active Area) 43 inches/1080mm Aspect Ratio 16:9 Number of pixels 3840 (H) x 2160 (V) Pixel pitch 0.2451 (H) x 0.2451 (V) [mm] Displayable colors 8bits+1.07G colors Brightness (typical) 500 cd/m Contrast ratio (typical)
  • Page 42 Display: SPX502 Item Specifications Screen Size (Active Area) 49.5 inches/1257mm Aspect Ratio 16:9 Number of pixels 3840 (H) x 2160 (V) Pixel pitch 0.2854 (H) x 0.2854 (V) [mm] Displayable colors 8bits+1.07G colors Brightness (typical) 500 cd/m Contrast ratio (typical) 5000:1 Viewing angle (H/V) 178 degrees...
  • Page 43 Display: SPX552 Item Specifications Screen Size (Active Area) 54.6 inches/1388mm Aspect Ratio 16:9 Number of pixels 3840 (H) x 2160 (V) Pixel pitch 0.315 (H) x 0.3151 (V) [mm] Displayable colors 8bits+1.07G colors Brightness (typical) 500 cd/m Contrast ratio (typical) 1200:1 Viewing angle (H/V) 178 degrees...
  • Page 44 Display: SPX652 Item Specifications Screen Size (Active Area) 64.5 inches/1639mm Aspect Ratio 16:9 Number of pixels 3840 (H) x 2160 (V) Pixel pitch 0.372 (H) x 0.372 (V) [mm] Displayable colors 8bits+1.07G colors Brightness (typical) 500 cd/m Contrast ratio (typical) 1200:1 Viewing angle (H/V) 178 degrees...
  • Page 45 Display: SPX752 Item Specifications Screen Size (Active Area) 74.5 inches/1893mm Aspect Ratio 16:9 Number of pixels 3840 (H) x 2160 (V) Pixel pitch 0.4296 (H) x 0.4296 (V) [mm] Displayable colors 8bits+1.07G colors Brightness (typical) 500 cd/m Contrast ratio (typical) 1200:1 Viewing angle (H/V) 178 degrees...
  • Page 46 Display: SPX862 Item Specifications Screen Size (Active Area) 85.6 inches/2174mm Aspect Ratio 16:9 Number of pixels 3840 (H) x 2160 (V) Pixel pitch 0.4935 (H) x 0.4935 (V) [mm] Displayable colors 8bits+1.07G colors Brightness (typical) 500 cd/m Contrast ratio (typical) 1200:1 Viewing angle (H/V) 178 degrees...
  • Page 47 2021 © All rights reserved. Specifications are subject to change without notice.
