Installation; Operation; Maintenance - Syntron Material Handling PowerPulse 225490-A Installation Operation & Maintenance

INSTALLATION

Install the control, being careful to maintain its UL TYPE 4X and NEMA 4 rating integrity. Power supply
voltage and frequency requirements are designated on the control nameplate. If remote mounting is necessary, the
control should be installed close to the equipment where it is easily accessible and within sight of the operator.
Installation on a wall in a clean, dry, vibration-free location is recommended. Ambient temperature should not
exceed 105ºF (40ºC).
WARNING: The electrical power supply connection to the control must be made
through a customer-supplied safety disconnect switch, which must be mounted
next to the control. Incorporation of an emergency stop may also be required, per
local codes.
When making electrical connections, it is important to follow the wiring diagram supplied with the control.
CAUTION" Nonmetallic enclosure does not provide grounding between conduit connections. Use
grounding bushings and jumper wires.
WARNING: The control must be properly grounded and verified at installation.
Enclosure integrity should be maintained at all times. Ensure any enclosure connectors used will maintain the UL
or IEC rating of the supplied unit. Install enclosure lid gasket to maintain integrity rating.

OPERATION

WARNING: The control must be kept closed and secured while in operation.
After the control has been installed and all strain relief connections have been properly completed, the control is
ready for operation. To energize the equipment, place the switch in the ON position. The potentiometer is used
to control the vibration of the equipment. Turning the knob clockwise will increase the amplitude of vibration,
and counterclockwise will decrease the amplitude of vibration.

MAINTENANCE

WARNING: Disconnect the power supply at the safety switch before performing
any maintenance.
The only maintenance required is that the controller be kept reasonably clean.
WARNING:
compressed air is recommended for cleaning.
Do not use a damp cloth or water for cleaning. Clean, dry
2
