Summary of Contents for Southwire Screw Jax CJ-01
-
Page 2: Table Of Contents
Warranty………………………………………......………………….7 - 8 SAFETY FIRST Safety is essential in the use and maintenance of Southwire Contractor Equipment. This instruction manual and any markings on the tool provide information for avoiding hazards and unsafe practices related to the use of this tool. Observe all of the safety information provided. - Page 3 WARNING Electrical Shock Hazards • This is not an insulated tool, contact with live circuits could result in severe injury or death. CAUTION Do not add extensions (cheaters) to the handle. Using excessive force may result in injury or damage to the tool. If excessive force is required, check and verify proper set up instructions.
-
Page 4: Important Safety Information
Do not use anything else— substitutes may not support the cable reel or may fall off the reel stand. • Never attach casters or wheels to a Southwire Screw Jax reel stand. • Use only on a hard, flat, level surface. -
Page 5: Description Of Operation
5000 lbs (2273kg). OPERATION 1. Two alike Screw Jax reel stands and one Southwire Axle are required for a complete setup. (The CJ-01 and CJ-02 Screw Jax Reel Stands must be used with only the PJA-01 or PJA-02 Southwire Axles). - Page 6 OPERATION cont. NOTE: The Southwire Screw Jax reel stands may require use of the quick extend feature. Manually lift the tele-scoping square tubing to desired height and use the pin provided by inserting through both sides of the square tubing.
-
Page 7: Maintenance
OPERATION cont. 5. Turn the reel stand handle clockwise to extend one reel stand until the cable reel clears the ground. (Fig. 4) Fig. 4 6. Turn the other reel stand handle until the spindle is level and the cable reel rotates freely. -
Page 8: Specifications
Under Southwire’s Contractor Equipment 5-Year Limited Warranty, Southwire Company, LLC warrants that all Southwire Contractor Equipment will be free from manufacturer defects for a period of five (5) years from the date of the original end user’s purchase. The following products are excluded from this 5-Year Limited Warranty and are subject to separate warranty terms: rope, blades, dies, draw studs, grips, Southwire Contractor Equipment electronic components, and Material Boxes. - Page 9 1. All warranty claims must be approved by Southwire’s Tools & Assembled Products Warranty Department prior to return of product. If Southwire determines that a product is defective, Southwire will, at its option, repair or replace defective products or defective product components, free of charge.
