Gaskets Used - mycom UD Series Instruction Manual

7.7

Gaskets Used

P/N Location
6 Suction Cover
12 Bearing Head
Bearing Cover
17
(D: Sideways discharge)
Bearing Cover
17
(G: Downward discharge)
23 Balance Piston Cover
52 Seal Cover
93 Suction Flange
96 Discharge Flange
216 Lubricating Oil inlet Flange
219 Oil Injection Flange
236 Discharge Flange Spacer
252 Economizer Flange
255 Liquid injection Flange
Lubricating Oil (for F Rotor side
602
Bearing) inlet Flange
UD-series Screw Compressor
Figure 7-9
Gaskets Used
Table 7-19 Gasket Size
160
H 354
W 460
H 345
W 460
H 338
W 397
H 332.5
W 388
H 270
W 283
Φ
140
173
Φ
(125A)
143
Φ
(100A)
Φ ―
Φ ―
110
Φ
(100CD)
51
Φ
(25A)
44
Φ
(20A)
―
Φ
7-39
Chapter 7 Related Documents
（㎜）
200 250
420 525
560 700
420 525
560 700
414 505
591 709
380 463
480 580
333 340
350 420
170 200
198 325
(150A) (250A)
173 198
(125A) (150A)
44 51
(20A) (25A)
― ―
146 176
(125CD) (150CD)
59 83
(32A) (50A)
51 59
(25A) (32A)
― ―
7.7 Gaskets Used
320
660
880
660
880
641
887
―
―
517
532
250
421
(350A)
250
(200A)
67
(40A)
51
(25A)
233
(200CD)
118
(80A)
83
(50A)
44
(20A)
