mycom UD Series Instruction Manual page 121

Micro-switch（For signals at slide valve full
load (100 %) position）
Micro-switch （Slide valve partial load position
signal, for 50 % load）
Micro-switch（Slide valve partial load position
signal, for special specifications）
Micro-switch Cam（For 0-100 % operation）
Micro-switch Cam（For 0-50 % or 50-100 %
operation）
Micro-switch Cam（For special operation）
Figure 5-29 Development View of the Unloader Indicator(125 type)
UD-series Screw Compressor
Chapter 5 Maintenance and Inspection
1
1
1
5-66
(1)
(1)
2
1 1
1
5.5 Reassembly
