CMA100F, CMA102F, CMA200F, CMA204F, CMA205U,
CMA210W, GMC80FA, GMC81UA, and GMC82FA Wall
IMPORTANT: Read entire instruction sheet before
assembling or installing mantel kit.
The CMA100 Series mantels are only approved for
use with CGCF, CGFP26E, VMH, and FMH series mod-
els. Do not use mantel with any other product.
The CMA200 and GMC80 Series mantels are approved
for use with any DESA Heating Products compact
fireplace system. Do not use mantel with any other
product.
This mantel kit contains the following:
Description
• Mantel pieces (unassembled)
• Hardware kit
• Black trim kit
The hardware items needed from hardware kit*:
• 16 - 1
⁄
" wood screws
1
4
• 2 - 3" wood screws
• 8 - #8 x 3/4" particle board screws
• 2 - Brackets
*Extra Hardware may be included.
Tools required:
• #2 Phillips power screw driver
• Slotted screw driver
Mantel Kits
ASSEMBLY INSTRUCTIONS
Part No.
113166-17
GAB6094
• 2 - Trim Plate
• 4 - Set Screws
• 2 - Trim Shim
www.desatech.com
If any of these pieces are missing or damaged, contact the dealer
where you purchased this mantel or DESA Heating Products at
1-866-672-6040 for referral information.
WARNING: Follow guidelines of paint or finish
manufacturer. Use care when finishing or painting
an unfinished mantel. Do not finish or paint mantel
pieces near running heater or open flame. These
vapors are generally highly flammable.
IMPORTANT: If you are staining an unfinished mantel, remove
any sawdust, dirt or oils. This will prevent blemishes from appear-
ing under the stain. Stain mantel before assembling according to
manufacturerʼs instructions. Apply sanding sealer.
IMPORTANT: If you are painting an unfinished mantel, assemble
the mantel before painting. Follow directions listed on the paint for
wood products. Apply base coat and top coat following directions
listed on product.
Note: Gather all mantel pieces together before assembling mantel.
WARNING: Only use 1
semble header and top. Damage to the mantel will
result if the longer screws provided are used for this
purpose.
1
/
" wood screws to as-
4
