- Page 1 USER’S MANUAL rel. 1.0 audison.com...
-
Page 2: Table Of Contents
9. INSTALLATION EXAMPLES: ......................53 9.1 3 WAY ACTIVE FRONT + REAR + SUB WITH AP F1D ............54 9.2 FRONT + REAR + SUB WITH AP F1D ..................56 9.3 FRONT+REAR+ SUB WITH AUDISON BIT PROCESSOR............. 58 10. TECHNICAL SPECIFICATIONS ....................... 59... -
Page 3: Precautions
7. PRE IN: Low level monophonic analog input. Use an RCA connector to connect to an audio source or to an amplifier from the “Prima AP F8.9 bit / AP 8.9 bit / AP 4.9 bit” line featuring this connection. The signal to be applied must have a level between 0.6 and 6 V RMS. The input sensitivity of the AP F1D is controlled by the “SENSITIVITY” 3-position switch: 0.6V-2V-6V. 8. SPEAKER OUT: power terminal + and - of the monophonic output. The available power at the output is 500 W x 1 @ 4 ohm, 800 W x 1 @ 2 ohm and 1000 W x 1 @ 1 ohm. 9. FUSE: to replace the fuse, remove it from its holder located near the power supply terminal block and replace it with another fuse of equal value. 10. INSTALLATION: All components must be solidly fixed to the vehicle structure. Do the same when installing any additional custom structures you may have built. Make sure that your installation is solid and safe. A component coming loose while driving may cause serious damage to the passengers, as well as to other vehicles. When the installation is complete, check the system wiring and verify all connections were performed correctly. 11. For a correct use of the AP F1D, it is essential to consult this manual in its entirety. 12. Warranty Certificate: please check out the Audison website for further information. SAFE SOUND USE COMMON SENSE AND PRACTICE SAFE SOUND. PLEASE REMEMBER THAT LONG EXPOSURE TO EXCESSIVELY HIGH SOUND PRESSURE LEVELS MAY DAMAGE YOUR HEARING. SAFETY MUST BE AT THE FOREFRONT WHILE DRIVING. Information on electrical and electronic equipment waste (for those European countries which organize the separate collection of waste) Products which are marked with a wheeled bin with an X through it can not be disposed of together with ordinary domestic waste. These electrical and electronic products must be recycled in proper facilities, capable of managing the disposal of these products and components. In order to know where and how to deliver these products to the nearest recycling/disposal site please contact your local municipal office. Recycling and disposing of waste in a proper way contributes to the protection of the environment and to prevent harmful effects on health. - Page 4 USER’S MAUAL AP F1D Audison Warranty The Audison products are warranted, under normal functioning conditions, for the period of time as set by the laws in force, against defects concerning materials or their manufacturing. The warranty is valid from the date of purchase, certified by receipt. The warranty is not valid if: • the product is damaged by incidents, installations and/or improper use, or by any other causes not depending on materials or manufacturing defects; • the product is modified or tampered with by unauthorised people; • its serial number has been altered or cancelled. While the product is under warranty, defective parts will be repaired or replaced at the manufacturer’s discretion. The defective product, along with notification about it, must be returned to the dealer from which it was purchased together with the warranty certificate duly filled in. If the product is no longer under warranty, it will be repaired at the current costs. Elettromedia s.r.l. does not undertake any liability for damages due to transportation. Elettromedia s.r.l. does not take any responsibility for: costs or loss of profit due to the impossibility to use the product, other accidental or consequential costs, expenses or damages suffered by the customer. Warranty according to laws in force. For more information visit the Audison website.
-
Page 5: Packaging Contents
USER’S MAUAL AP F1D PACKAGING CONTENT - AP F1D amplifier - Multipolar cable, Inputs/Rem: - Multipolar cable Speakers out: - NR. 2 - 30A replacement fuse: - 2.5 mm hex key: - NR. 4 - 4.2 x 50 mm (0.16” x 2”) self-tapping, cross head mounting screws: - User’s Manual... -
Page 6: Installation And Sizes
USER’S MAUAL AP F1D INSTALLATION AND SIZE External Size 238 mm / 9.37 in POWER - 12V SPEAKER SPK IN + REM IN SENSITIVITY SPK IN - MUTE PRE IN SPK-IN MODE FUSE 2x30A AP F1D How to mount Mounting Size AP F1D 216 mm / 8.5 in. -
Page 7: Cable Size Calculation Tables
USER’S MAUAL AP F1D CABLE SIZE CALCULATION TABLES Connection length FRONT VIEW Blue/White MUTE Blue REM IN Cable Length (m) Orange/Black SPK IN- Orange SPK IN+ CONNECTION CABLE FRONT VIEW Input cable 200 mm / 7.87 in. 10 mm / 0.39 in. Blue REM IN Orange... -
Page 8: Power Supply And Remote Connection / Fuse Replacement
USER’S MAUAL AP F1D POWER SUPPLY AND REMOTE CONNECTION / FUSE REPLACEMENT HEX KEY 2,5 mm / 0.1 in. POWER - 12V SPEAKER SPK IN + REM IN SENSITIVITY SPK IN - MUTE PRE IN SPK-IN MODE 2 x 30A 15 mm / 0.6 in. 8 AWG Max FUSE 2x30A BLADE... -
Page 9: Pre In / Speaker In
USER’S MAUAL AP F1D PRE IN / SPEAKER IN AP F1D with REM IN AP F1D POWER - 12V SPEAKER SPK IN + REM IN SENSITIVITY SPK IN - MUTE PRE IN SPK-IN MODE FUSE 2x30A REM IN PRE IN APL2 - LINK CABLE REM OUT SOURCE... - Page 10 USER’S MAUAL AP F1D AP F1D + AP8.9 bit / 4.9 bit PRE OUT AP F1D POWER - 12V SPEAKER SPK IN + REM IN SENSITIVITY SPK IN - MUTE PRE IN SPK-IN MODE FUSE 2x30A AP8.9 bit / AP4.9 bit SUB PRE OUT AP F1D + HEAD UNIT PRE OUT AP F1D POWER - 12V...
- Page 11 USER’S MAUAL AP F1D AP F1D + AUDISON PROCESSOR PRE OUT AP F1D POWER - 12V SPEAKER SPK IN + REM IN SENSITIVITY SPK IN - MUTE PRE IN SPK-IN MODE FUSE 2x30A SUB OUT AD Link AC Link 12 V...
-
Page 12: Control Panel
USER’S MAUAL AP F1D CONTROL PANEL POWER ON LED BLUE 70 °C Flash - LED RED < 2 Ohm CHECK Flash - LED RED AP F1D > 16 Volt CHECK Flash - LED RED LED RED HI LEVEL INPUT PRE INPUT SENSITIVITY SENSITIVITY INPUT SENSITIVITY HI: 2 V RMS... -
Page 13: Installation Examples
USER’S MAUAL AP F1D INSTALLATION EXAMPLES AP F1D AP F1D with 1 SUBWOOFER POWER - 12V SPEAKER SPK IN + REM IN SENSITIVITY SPK IN - MUTE PRE IN SPK-IN MODE FUSE 2x30A from source / amplifier / processor SUBWOOFER 1 Ω min. AP F1D AP F1D with 2 SUBWOOFER POWER - 12V SPEAKER SPK IN +... -
Page 14: Way Active Front + Rear + Sub With Ap F1D
USER’S MAUAL AP F1D 3 WAY ACTIVE FRONT + REAR + SUB WITH AP F1D LEFT RIGHT FRONT FRONT LEFT RIGHT FRONT FRONT LEFT RIGHT FRONT FRONT REAR REAR LEFT RIGHT SUBWOOFER POWER - 12V PRESETS UPGRADE OPTICAL IN OFF ON AP F8.9 bit SPEAKER IN FUSE 2x30A... - Page 15 USER’S MAUAL AP F1D OUTPUT CONFIGURATION: AP TYPE OUTPUT TYPE CUT FILTER FILTER TYPE CUT FREQUENCY TIME ALIGNMENT POWER 4Ω POWER 2Ω OUT 1 FRONT TW LEFT HI PASS Linkwitz 3000 Hz @12 dB 82,2 cm 85 W 130 W OUT 2 FRONT TW RIGHT HI PASS...
-
Page 16: Front + Rear + Sub With Ap F1D
USER’S MAUAL AP F1D FRONT + REAR + SUB WITH AP F1D LEFT RIGHT FRONT FRONT LEFT RIGHT FRONT FRONT REAR REAR LEFT RIGHT SUBWOOFER POWER - 12V PRESETS UPGRADE OPTICAL IN OFF ON SPEAKER IN FUSE 2x30A CTRL SPEAKER OUT SUB OUT PRE IN POWER - 12V... - Page 17 USER’S MAUAL AP F1D OUTPUT CONFIGURATION: AP TYPE OUTPUT TYPE CUT FILTER FILTER TYPE CUT FREQUENCY TIME ALIGNMENT POWER 4Ω POWER 2Ω OUT 1 FRONT TW LEFT HI PASS Linkwitz 3000 Hz @12 dB 82,2 cm 85 W 130 W OUT 2 FRONT TW RIGHT HI PASS...
-
Page 18: Front+Rear+ Sub With Audison Bit Processor
USER’S MAUAL AP F1D FRONT+REAR+ SUB WITH AUDISON BIT PROCESSOR SENSITIVITY FRONT FRONT LEFT RIGHT AP F1D AP F1D REAR REAR LEFT RIGHT SUBWOOFER AP F1D AP F1D AP F1D AD Link AC Link 12 V PHONE INPUTS MUTE IN... -
Page 19: Technical Specifications
USER’S MAUAL AP F1D TECHNICAL SPECIFICATION POWER SUPPLY Power supply voltage / fuse: 11 ÷ 15 VDC / 2 x 30A Operating power supply voltage 6.5 ÷ 17 VDC Idling current: 1.3 A Idling current when off 0.05 mA Consumption @ 14.4 VDC, 1Ω, Max Musical Power: 50 A Remote IN 6.5 ÷ 15 VDC (1 mA) ART - Automatic Remote Turn on/off from OUTPUT BTL speakers (Selectable) 2 ÷... - Page 20 PART OF ELETTROMEDIA 62018 Potenza Picena (MC) Italy T +39 0733 870 870 - F +39 0733 870 880 www.elettromedia.it...
