VoIP SIP / PoE interface for traditional Doorphones
TECHNICAL – INSTALLATION MANUAL
Recommendations
1.
Use only original spare parts and consumables supplied by Tema Telecomunicazioni Srl for this equipment. The company shall not be
held responsible for any damage caused by the use of materials that they have not supplied.
2.
The device has been carefully manufactured and tested. In any case, the product is not recommended for use in situations in which
incorrect operating may result in damage to persons and/or property.
3.
We recommend that you carefully read all this manual before starting to use the device.
4.
Do not expose the device to sunlight and protect it from sources of heat, dust, humidity and chemical agents.
5.
This manual is the property of Tema Telecomunicazioni Srl and any duplication and reproduction, even partial, as well as storage on
any type of media is forbidden without written permission from Tema Telecomunicazioni Srl.
Revision
Date
0
20/03/20
MAS-AA15-REV00EN
TEMA TELECOMUNICAZIONI S.r.l.
Telecommunications - Electronics
AA-15IP
PRELIMINARY DOCUMENTATION
HW Version 1.0 - SW Version 1.10
Revision reason
First release
Prepared
DP, FL
Checked/Approved
DP, FL
Page 1 of 32
Advertisement
Table of Contents
Related Manuals for tema AA-15IP
Summary of Contents for tema AA-15IP
- Page 1 Do not expose the device to sunlight and protect it from sources of heat, dust, humidity and chemical agents. This manual is the property of Tema Telecomunicazioni Srl and any duplication and reproduction, even partial, as well as storage on any type of media is forbidden without written permission from Tema Telecomunicazioni Srl.
- Page 2 TEMA TELECOMUNICAZIONI SRL DICHIARAZIONE DI CONFORMITÀ CE DECLARATION OF CONFORMITY CE We, TEMA TELECOMUNICAZIONI SRL Via C. Girardengo, 1/4 - 20161 MILANO declare under our sole responsibility that the product: Modulo Intercom Audio e Video VoIP SIP / PoE product name...
- Page 3 It is expressly not recommended maintenance inside the device which must be carried out by Tema Telecomunicazioni, the removal of the closures will invalidate the warranty and makes accessible internal parts with risk of electric shock.
-
Page 4: Table Of Contents
VoIP Doorphone Interface AA-15IP TEMA TELECOMUNICAZIONI SRL INDEX PAGE PRESENTATION ............................5 TYPICAL OPERATING DIAGRAM ......................6 PACKING LIST ............................6 GENERAL FEATURES ..........................7 TECHNICAL FEATURES ........................... 7 INSTALLATION ............................8 6.1. CONNECTION ..............................8 PROGRAMMING ............................11 7.1. P ................ -
Page 5: Presentation
1. PRESENTATION The AA-15IP device allows to interface any traditional doorphone (4 or 5 wires) to an IP-PBX in order to manage the doorphone from any internal extension or, in the absence of an IP-PBX, it can also work with a common SIP phone in P2P (Peer-to-Peer) mode. -
Page 6: Typical Operating Diagram
Both relays can be activated not only following the call from the doorphone but also by calling AA-15IP to the assigned number/IP address, wait for the answer and activate them with codes from the telephone keypad. -
Page 7: General Features
VoIP Doorphone Interface AA-15IP TEMA TELECOMUNICAZIONI SRL 4. GENERAL FEATURES • Sending a telephone call upon detection of an intercom call • Programming via Web interface with password protection • Day/Night/Interval manual or automatic mode for different call destination numbers •... -
Page 8: Installation
VoIP Doorphone Interface AA-15IP TEMA TELECOMUNICAZIONI SRL 6. INSTALLATION 6.1. CONNECTION The connection of the device must only be carried out by qualified technical personnel. Signaling LED RX volume adjustment YELLOW: active communication REDs: relay 1 and 2 Alarm contact input... - Page 9 VoIP Doorphone Interface AA-15IP TEMA TELECOMUNICAZIONI SRL Removable screw terminal blocks 1-2 Input P1 Terminal for detecting the alarm contact (1 = contact, 2 = GND) 3-4 Relay R2 Auxiliary relay, range 30V-1Amp, normally open contact C, A Terminal for powering the system, irrelevant polarity...
- Page 10 AA-15 is connected with a UTP cable from the RJ45 "TAP" socket on the terminals of the indoor station (in parallel with the wires already connected to the intercom system). The signals for the AA-15IP interface are taken from the group of 6 terminals. Terminal 4-7 carries the first relay inside AA-15 which activates the lock following a code dialed on the internal telephone keypad.
-
Page 11: Programming
Open the Windows Control Panel and set the field "View by": "Category" "Large Icons" or "Small Icons". Choose "Network and Sharing Center" as shown in the first figure, detect your LAN connection, choosing the one referring to the network card that you are using to connect with AA-15IP. MAS-AA15-REV00EN... - Page 12 PC to its original state if necessary. Once the IP address of your PC is successfully configured, it is possible to reach the Web interface to configure AA-15IP at the address 192.168.0.10 . MAS-AA15-REV00EN...
-
Page 13: Access To Programming
VoIP Doorphone Interface AA-15IP TEMA TELECOMUNICAZIONI SRL 7.2. Access to programming To program the device, it is sufficient to use a standard browser such as Explorer, Firefox, Chrome or others. The default address of the device is 192.168.0.10 with a mask of 255.255.255.0, and the user/password with which to connect are master/master. -
Page 14: Network Parameters
Test address (ping): if inserted, this address is used by the system to verify the correct operation of the network connection. • Device description: text that will appear on the search mask of the supervision Tema Adam software (for this device it is not necessary). MAS-AA15-REV00EN... -
Page 15: Sip Parameters
VoIP Doorphone Interface AA-15IP TEMA TELECOMUNICAZIONI SRL 7.4. SIP Parameters Once the network parameters have been set correctly, you must configure the connection with the VoIP SIP PBX: • SIP server address: specify the IP address of the SIP PBX to which AA-15 should connect. -
Page 16: Parametri Generali
VoIP Doorphone Interface AA-15IP TEMA TELECOMUNICAZIONI SRL 7.5. Parametri generali In this section it is possible to set parameters for general use, such as call duration, audio volume, and so on: • Connection time: once in connection with the extension, the call is torn down anyway after the set time. -
Page 17: Set Of The Operating Mode Day/Night/Interval, Keyboard
VoIP Doorphone Interface AA-15IP TEMA TELECOMUNICAZIONI SRL 7.6. Set of the operating mode Day/Night/Interval, Keyboard In the operating mode, it is possible to set the mode to DAY/NIGHT/INTERVAL, either manually or automatically following time slots per week. This page is also configured to change the codes to the remote phone and coordinates the installation (they are used to manage the twilight mode of relay 2, see par. -
Page 18: Day/Night/Interval Description
VoIP Doorphone Interface AA-15IP TEMA TELECOMUNICAZIONI SRL 7.7. Day/Night/Interval description In each of the three possible modes of operation, at the press of a button the system makes a call to a number (or two numbers if the second number is also programmed) for a parmeterizabile number of times. It is also possible to specify an additional final number, called "supervisor", to be contacted at the end of the previous attempts. -
Page 19: Relay And Alarm Settings
VoIP Doorphone Interface AA-15IP TEMA TELECOMUNICAZIONI SRL 7.9. Relay and alarm settings On this page it is possible to choose the operating mode of the two internal device relays and the operating mode for external inputs: • Mode: sets the function to be associated to the relay. It is possible to choose between: Electric lock: is activated only upon receiving the activation code. -
Page 20: Acquisition Of Input Alarm Contacts
VoIP Doorphone Interface AA-15IP TEMA TELECOMUNICAZIONI SRL Normally it is possible to reach AA-15 from any extension of the PBX to issue DTMF commands, simply by dialing the number of the internal extension to which AA-15 is connected. 7.10. Acquisition of input alarm contacts The following screenshot shows the configuration parameters of the alarm event following the closure of an external contact. -
Page 21: Call Buttons
VoIP Doorphone Interface AA-15IP TEMA TELECOMUNICAZIONI SRL 7.11. Call buttons In the configuration of AA-15 only key 1 is to be filled in to send the call to an operator, the possibility of key 2 will be used in the future. -
Page 22: Maintenance
Firmware version: displays the currently installed version of the program. It is possible to upload a different version (possibly provided by the technical support of TEMA) using the Browse / Update. Once you've uploaded the new version, the device must be restarted. -
Page 23: Login Credentials
VoIP Doorphone Interface AA-15IP TEMA TELECOMUNICAZIONI SRL 8.2. Login credentials By default, the user name and password for access to the configuration are master/master (lowercase). It is not possible to have more than one user (there are not hierarchical levels of programming), but it is possible to change the login credentials: The password should be introduced twice for confirmation. -
Page 24: Appendixes
DTMF tones or tones, noise reduction, etc. For optimal use please refer to the product manual. NOTE: TEMA provides you with its own internal recording studio for the creation of professional prompts with multilingual speakers from texts on customer specifications. -
Page 25: Cabling Of Autp Rj45 Network Cable According To The Standard Eia568B
VoIP Doorphone Interface AA-15IP TEMA TELECOMUNICAZIONI SRL 9.2. Cabling of a UTP RJ45 network cable according to the standard EIA568B Signal Connector 1 Connector 2 White/Orange White/Orange Orange Orange White/Green Bianco/Green PoE- Blue Blue PoE- White/Blue White/Blue Green Green PoE+... -
Page 26: Connection With Urmet Intercom
VoIP Doorphone Interface AA-15IP TEMA TELECOMUNICAZIONI SRL 9.3. Connection with URMET intercom POWER SUPPLY AMPLIFIED DOOR STATION DOOR OPENER IP PBX SIP SERVER IP-SIP Phone 8 7 6 5 4 3 2 1 Alarm 12Vdc contact input 200mA Output 12Vdc/Vac... -
Page 27: Connection With Urmet Mod. 1130 Intercom
VoIP Doorphone Interface AA-15IP TEMA TELECOMUNICAZIONI SRL 9.4. Connection with URMET mod. 1130 intercom TO SUBSEQUENT INTERCOMS INTERCOMS PUSH-BUTTON PANEL AND EXTERNAL UNIT 8 7 6 5 4 3 2 1 LOCK OPENING ELECTRIC LOCK UTP cable from TAP MAINS ~... -
Page 28: Connection With Bpt Intercom
VoIP Doorphone Interface AA-15IP TEMA TELECOMUNICAZIONI SRL 9.5. Connection with BPT intercom POWER SUPPLY AMPLIFIED DOOR STATION DOOR OPENER DOORBELL BUTTON UTP cable from TAP MAS-AA15-REV00EN Page 28 of 32... -
Page 29: Connection With Terraneo Intercom
VoIP Doorphone Interface AA-15IP TEMA TELECOMUNICAZIONI SRL 9.6. Connection with TERRANEO intercom POWER SUPPLY AMPLIFIED DOOR STATION DOOR OPENER UTP cable from TAP MAS-AA15-REV00EN Page 29 of 32... -
Page 30: Connection With Farfisa Intercom
VoIP Doorphone Interface AA-15IP TEMA TELECOMUNICAZIONI SRL 9.7. Connection with FARFISA intercom 9.8. Connection with COMELIT intercom MAS-AA15-REV00EN Page 30 of 32... -
Page 31: Faq Frequently Asked Questions
"parallel" way on the necessary signals. When a visitor presses the button, AA-15IP generates a SIP call to an internal number, communicating the visitor with the answering operator, who has the possibility of operating the relay for opening with a code from the telephone of the gate. - Page 32 VoIP Doorphone Interface AA-15IP TEMA TELECOMUNICAZIONI SRL NOTES MAS-AA15-REV00EN Page 32 of 32...
