2. INTRODUCTION

Premier range of high efficiency industrial fans with improved motor and blade design resulting in higher velocity with up to 30% more area
coverage and reach. Robust unit with heavy-duty gauge steel casing, guard and frame. Handle, wheels and tilt function cradle stand, allow
the control of airflow where it is needed. Carefully balanced and fully guarded blades provide safe operation. Suitable for use in industrial,
commercial, agricultural, automotive and showroom applications. Fitted with fully BS approved plug.

3. SPECIFICATION

Model No.: .......................................HVD24P..................................... HVD30P ........................................................... HVD36P
Fan Diameter: ...................................610mm (24") .............................. 760mm (30") ............................................. 915mm (36")
Speed Settings: ................................2................................................. 2 ................................................................................... 2
Speeds: ............................................1300rpm - 1420rpm ................... 880rpm - 960rpm ............................... 860rpm - 950rpm
Maximum Airflow: .............................266mtr³/min (9420cfm) .............. 288mtr³/min (10175fm) ............363mtr³/min (12855cfm)
Motor Power: ....................................330W ......................................... 315W ....................................................................410W
Supply:..............................................230V .......................................... 230V ......................................................................230V
Current:.............................................1.43A ......................................... 1.37A .....................................................................1.78A
Overall efficiency: .............................31.75% ...................................... 31.4% .................................................................32.15%
Efficiency category: ..........................Static.......................................... Static ..................................................................... Static
Efficiency grade: ...............................36............................................... 36 ............................................................................... 36

4. OPERATION

WARNING! Ensure that you read, understand and apply safety instructions in Section 1 before using fan.

4.1.
Check that the speed control is set to "0" (off) and then plug into the mains power supply and switch the power on.
4.2. The fans feature 2 speeds which are selectable using the switch located at the back of the fan, above the motor on the HVD24P or on
the fan housing (near the handle) on the HVD30P and HVD36P
4.3.
Adjust the direction of the air flow by moving from side to side and tilting the fan up or down as required.
4.4. When you have finished using the fan ensure you turn the speed control switch to "0" (off) and disconnect the fan from the mains.
power.

5. CARE OF FAN

WARNING! Ensure that the fan is disconnected from the mains power supply before attempting any of the following:

5.1. Use a soft, damp cloth to clean the fan.
DO NOT immerse the fan in water and never allow water to drip onto the motor housing. DO NOT use solvents, petroleum, paint
thinner or other chemicals to clean the fan.
5.2. To clean the fan blade, undo the cross headed screws around the circumference, remove the grille and clean the blade with a
slightly damp cloth. Replace the grille as required and refit the cross headed screws.
5.3. Should the motor, switch or the power lead require service or maintenance contact your local service agent.
5.4. When not in use place the fan in its original box or otherwise cover to protect from dust, and store in a safe, dry, childproof
location.

ENVIRONMENT PROTECTION

Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.

WEEE REGULATIONS

Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without
prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500
© Jack Sealey Limited
01284 703534 sales@sealey.co.uk
Original Language Version
www.sealey.co.uk
HVD24P, HVD30P, HVD36P Issue: 1 - 31/01/18
