Sealey HVD24 Quick Start Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions and properly maintained,
give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS AND
CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY
CAUSE DAMAGE AND/OR PERSONAL INJURY, AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR
FUTURE USE.
1. SAFETY INSTRUCTIONS
1.1. ELECTRICAL SAFETY
FWARNING! It is the responsibility of the owner and the operator to read, understand and comply with the following:
You must check all electrical products, before use, to ensure that they are safe. You must inspect power cables, plugs, sockets and any other
connectors for wear or damage. You must ensure that the risk of electric shock is minimised by the installation of appropriate safety devices.
A Residual Current Circuit Breaker (RCCB) should be incorporated in the main distribution board. We also recommend that a Residual Current
Device (RCD) is used. It is particularly important to use an RCD with portable products that are plugged into a supply which is not protected
by an RCCB. If in any doubt consult a qualified electrician. You may obtain a Residual Current Device by contacting your Sealey dealer.
You must also read and understand the following instructions concerning electrical safety.
1.1.1. The Electricity at Work Act 1989 requires all portable electrical appliances, if used on business premises, to be tested by a qualified
electrician, using a Portable Appliance Tester (PAT), at least once a year.
F   WARNING! The switch on this fan has components fitted to protect it against a possible
voltage surge. When carrying out regular appliance checks, a voltage no higher than 250V
p
should be applied for the purposes of insulation testing.
1.1.2. The Health & Safety at Work Act 1974 makes owners of electrical appliances responsible
for the safe condition of those appliances and the safety of the appliance operators. If in
any doubt about electrical safety, contact a qualified electrician.
1.1.3. Ensure that the insulation on all cables and on the appliance is safe before connecting it
to the power supply. See 1.1.1. and 1.1.2. and use a Portable Appliance Tester.
1.1.4. Ensure that cables are always protected against short circuit and overload.
1.1.5. Regularly inspect power supply cables and plugs for wear or damage and check all
connections to ensure that none are loose.
1.1.6. Important: Ensure that the voltage marked on the appliance matches the power supply
to be used and that the plug is fitted with the correct fuse - see fuse rating at right.
1.1.7. DO NOT pull or carry the appliance by the power cable.
1.1.8. DO NOT pull the plug from the socket by the cable.
1.1.9. DO NOT use worn or damaged cables, plugs or connectors. Immediately have any faulty item
repaired or replaced by a qualified electrician. When an ASTA/BS approved UK 3 pin plug is damaged, cut the cable just above the
plug and dispose of the plug safely.
Fit a new plug according to the following instructions (UK only).
a) Connect the GREEN/YELLOW earth wire to the earth terminal ‘E’.
b) Connect the BROWN live wire to the live terminal ‘L’.
c) Connect the BLUE neutral wire to the neutral terminal ‘N’.
d) After wiring, check that there are no bare wires, that all wires have been correctly connected, that the cable outer insulation
extends beyond the cable restraint and that the restraint is tight.
Double insulated products, which are always marked with this symbol
To rewire, connect the wires as indicated above - DO NOT connect either wire to the earth terminal.
1.1.10. Products which require more than 13 amps are supplied without a plug. In this case you must contact a qualified electrician to ensure that a
suitably rated supply is available. We recommend that you discuss the installation of an industrial round pin plug and socket with your electrician.
1.1.11. If an extension reel is used it should be fully unwound before connection. A reel with an RCD fitted is preferred since any appliance
plugged into it will be protected. The cable core section is important and should be at least 1.5mm
capacity of the reel is suitable for this product and for others which may be used in the other output sockets, we recommend the use of
2.5mm section cable. If extension reel is to be used outdoors, ensure it is marked for outdoor use.
2
1.2 GENERAL SAFETY
F WARNING! If a fan falls into water or other liquid, immediately switch off and disconnect from the
mains power supply. Do not touch the fan until the mains power supply has been disconnected.
p
% DO NOT stand the fan on it’s electrical power cable.
% DO NOT insert any objects through the fan guard.
% DO NOT cover the fan when in use.
% DO NOT immerse the fan in water or any other liquid.
% DO NOT allow children to operate the fan.
% DO NOT stand the fan where it may be knocked over or off a surface, or where the lead may
cause a person to trip.
% DO NOT use the fan outdoors.
% DO NOT use an extension cord unless it has been approved by an electrical authority.
% DO NOT modify speed control or attempt to fit any additional external speed control device to the fan.
% DO NOT operate the fan where there are harmful, explosive or flammable gases, fumes or
hazardous substances.
! When not in use place the fan in its original box or cover the fan to protect from dust, and store in
a safe, dry, childproof location.
! Use recommended parts only (non genuine parts may be dangerous, and will invalidate your warranty).
! Always disconnect the fan from the power supply when moving it from one location to another and ensure the fan is stood on a level surface.
! The fan air flow is powerful. Before using ensure there are no materials or items that may be erroneously moved by the stream of air.
! Keep the fan clean and maintained in good condition. For electrical components or motor service contact an authorised service agent.
! Disconnect the fan from the mains power when not in use, and before servicing or performing any maintenance.
! Use the fan in dry areas only. Do not use in wet or areas with high condensation such as showers, pools etc.
