Sealey HVD42B Instructions

thank you for purchasing a sealey product. manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
refer to indoor use
instructions only
1. safety
1.1. electrical safety
Warning! it is the responsibility of the owner and the operator to read, understand and comply with the following:
‰
You must check all electrical products, before use, to ensure that they are safe. You must inspect power cables, plugs, sockets and
any other connectors for wear or damage. You must ensure that the risk of electric shock is minimised by the installation of appropriate
safety devices. A residual current circuit Breaker (rccB) should be incorporated in the main distribution board. We also recommend
that a residual current device (rcd) is used. it is particularly important to use an rcd with portable products that are plugged into a
supply which is not protected by an rccB. if in any doubt consult a qualified electrician. You may obtain a residual current device by
contacting your sealey stockist.
You must also read and understand the following instructions concerning electrical safety.
the electricity at Work Act 1989 requires all portable electrical appliances, if used on
9
business premises, to be tested by a qualified electrician, using a Portable Appliance tester
(PAt), at least once a year.
the Health & safety at Work Act 1974 makes owners of electrical appliances responsible
for the safe condition of those appliances and the safety of the appliance operators. if in
any doubt about electrical safety, contact a qualified electrician.
ensure that the insulation on all cables and on the appliance is safe before connecting it
9
to the power supply.
ensure that cables are always protected against short circuit and overload.
9
regularly inspect power supply cables and plugs for wear or damage and check all
9
connections to ensure that none is loose.
ensure that the voltage marked on the appliance matches the power supply
9
to be used and that the plug is fitted with the correct fuse - see fuse rating at right.
do not pull or carry the appliance by the power cable.
8
do not pull the plug from the socket by the cable.
8
do not use worn or damaged cables, plugs or connectors. immediately have any faulty item repaired or replaced by a qualified
8
electrician. When an AstA/Bs approved uK 3 pin plug is damaged, cut the cable just above the plug and dispose of the plug safely.
fit a new plug according to the following instructions (uK only).
a) connect the Green/YelloW earth wire to the earth terminal 'e'.
b) connect the BroWn live wire to the live terminal 'l'.
c) connect the Blue neutral wire to the neutral terminal 'n'.
d) After wiring, check that there are no bare wires, that all wires have been correctly connected, that the cable outer insulation extends
beyond the cable restraint and that the restraint is tight.
double insulated products, which are always marked with this symbol
to rewire, connect the wires as indicated above - do not connect either wire to the earth terminal.
Products which require more than 13 amps are supplied without a plug. in this case you must contact a qualified electrician to ensure
that a suitably rated supply is available. We recommend that you discuss the installation of an industrial round pin plug and socket
with your electrician.
if an extension reel is used it should be fully unwound before connection. A reel with an rcd fitted is preferred since any appliance
9
plugged into it will be protected. the cable core section is important and should be at least 1.5mm², but to be absolutely sure that
the capacity of the reel is suitable for this product and for others which may be used in the other output sockets, we recommend the
use of 2.5mm² section cable. if extension reel is to be used outdoors, ensure it is marked for outdoor use.
1.2. general safety
disconnect the fan from the mains power when not in use and before servicing or performing any maintenance.
9
use the fan in dry areas only. do not use in wet or areas with high condensation such as showers, pools etc.
9
Warning! if a fan falls into water or other liquid, immediately switch off and disconnect from the mains power supply. do not touch the
‰
fan until the mains power supply has been disconnected.
Always disconnect the fan from the power supply when moving it from one location to another and ensure fan is stood on a level
9
surface.
the fan air flow is powerful. Before use ensure that there is nothing nearby that will be damaged or displaced by the stream of air.
9
Keep the fan clean and maintained in good condition. for motor service contact an authorised service agent.
9
© Jack sealey limited
instructions for
industrial high velocity drum fan 42"
belt drive 230v
hvd42b
model no:
Original Language Version
, are fitted with live (brown) and neutral (blue) wires only.
HVd42B | issue 4 18/01/17
recommended
fuse rating 5 amP
