A
User Interface
User Interface: : : :
User Interface
User Interface
Switch on / off. For switching off please press button for ca. 5 sec.
Activates the background lighting
To navigate through the different menus please use the keys located on the left and right beside the
display.
Confirm your settings
Confirm your settings and moves to next menu
Back to previous menu
Increase of values
Decrease of values
Activates a certain function (depending on chosen menu)
XYZ
No function
B
Set
Set- - - - up your flow measu
Set
Set
up your flow measur r r r ement in 5 steps
up your flow measu
up your flow measu
1. Choose suited mounting position for your transducers
2. Parameterize your flow transmitter
3. Mounting of ultrasonic transducers on your pipe
4. Set zero point (if possible)
5. Start your flow measurement
Pipe needs to be filled completely for clamp-on measurement
Quickstart
Quickstart
Quickstart
Quickstart
Move cursor in specific direction
ement in 5 steps
ement in 5 steps
ement in 5 steps
