Systec Controls deltawaveC-F Quick Start Manual

deltawaveC- - - - F F F F 2CH deltawaveC
deltawaveC deltawaveC
A

User Interface

User Interface
User Interface User Interface
deltawaveC-F will be switched on automatically after supply voltage has been plugged on.
Activates / deactivates the background lighting
To navigate through the different menus please use the keys located on the left and right beside the
display.
Confirm your settings
Back to previous menu
Activates a certain function (depending on choosen menu)
XYZ
B
Set Set Set Set- - - - up your flow measu up your flow measur r r r ement in 5 steps up your flow measu up your flow measu
1. Choose suited mounting position for your transducers
2. Parameterize your flow transmitter
3. Mounting of ultrasonic transducers on your pipe
4. Set zero point (if possible)
5. Start your flow measurement
Pipe need to be filled completely for clamp-on measurement
C

Parameterization and mounting

Parameterization and mounting Parameterization and mounting Parameterization and mounting
1. Switch on flow transmitter (automatically when plugging on supply voltage, see below)
2. Choose menu „quick setup"
3. Select measurment channel 1 or 2
4. Select diameter or circumference (depending on what figure you have) of your pipe
5. Put in value for diameter or circumference
6. Put in value for wall thickness of your pipe
7. Select pipe material
8. Select lining (if there is a lining)
9. Select type of ultrasonic transducer
Nr. 1 = XUC-FW-F21 DN10.....DN100
Nr. 2 = XUC-FW-F20 DN10.....DN100 (replaced by ultrasonic transducer model XUC-FW-F20 )
Nr. 3 = XUC-FW-F10 DN32.....DN400
Nr. 4 = XUC-FW-F05 DN200...DN6000
10. Select method of mounting. Standard is V-mounting.
2CH
2CH 2CH
Quickstart Quickstart Quickstart Quickstart
Move cursor in specific direction
Confirm your settings and moves to next menu
Increase of values
ement in 5 steps ement in 5 steps ement in 5 steps
V1.01
Decrease of values
No function
