- Page 1 ILCS EDGE System Installation Manual 0900885 Rev: REL (02/06) Page 1 of 12...
-
Page 2: Table Of Contents
T A B L E O F C O N T E N T S System Overview....................4 System Components .................... 4 System Diagram ....................5 Operation......................6 Pre-Installation...................... 6 Air Pump Installation..................... 7 Manifold Installation (optional) ................8 SIB Installation (optional)..................9 Wiring Diagram.................... - Page 3 0900885 Rev: REL (02/06) Page 3 of 12...
-
Page 4: System Overview
S Y S T E M O V E R V I E W The ILCS EDGE (Intelligent Liquid Control System) is an automated chemical control system that accumulates critical usage data of chemicals used for cleaning in food plants. Using the very latest concepts in process control technology, the ILCS provides key benefits: •... -
Page 5: System Diagram
S Y S T E M D I A G R A M 0900885 Rev: REL (02/06) Page 5 of 12... -
Page 6: Operation
P R E - I N S T A L L A T I O N Before the equipment is installed, you should survey the installation site thoroughly. Listed below are some of the factors to consider when picking your location. Work Area —... -
Page 7: Air Pump Installation
A I R P U M P I N S T A L L A T I O N Before installation, choose a mounting location for the chemical pumps that is as close as possible to chemical containers. Be sure to allow enough space between pumps for ease of installation and service. Follow the installation steps below for each chemical pump that will be used. -
Page 8: Manifold Installation (Optional)
M A N I F O L D I N S T A L L A T I O N ( O P T I O N A L ) (1) Determine the vertical mounting configuration desired for the application (top and bottom orientation). This is particularly important for dual manifold applications. -
Page 9: Sib Installation (Optional)
S I B I N S T A L L A T I O N ( O P T I O N A L ) (1) Mount the SIB near the signal source at the CIP (or external pump) controller using suitable hardware. (2) Connect the SIB to the control box using 3 conductor cable (see wiring diagram in this manual). -
Page 10: Wiring Diagram
S Y S T E M W I R I N G D I A G R A M Page 10 of 12 0900885 Rev: REL (02/06) -
Page 11: Label Change Procedure
L A B E L C H A N G E P R O C E D U R E (1) Shut off power to the system. (2) Remove screws that hold the LFP circuit board to the front panel of the control box. (3) Disconnect ribbon cable from the LFP circuit board. -
Page 12: Warranty Information
Warranty does not cover liability resulting from performance of this equipment nor the labor to replace this equipment. Product abuse or misuse voids warranty. A Unit of IDEX Corporation K N I G H T L L C ,...
