Bazooka MGA11000H Technical Specifications

SAS_MardiGras_Tab.qxp 12/29/2006 8:35 AM Page 1
Mardi Gras Series Technical Specifications
A A M M P P L L I I F F I I E E R R S S M M G G A A 2 2 6 6 5 5 M M G G A A 4 4 6 6 5 5
S S p p e e c c i i f f i i c c a a t t i i o o n n
Power at 4 ohms (per channel) 65W 2CH 64W 4CH
Power at 2 ohms (per channel) 95Wx2 90Wx4
Power at 4 ohms (mono) 190Wx1 170Wx2
Power at 1 ohms
THD @ rated power 0.30% 0.30%
Frequency Response (+- 3dB) 25Hz-22KHz 25Hz-22KHz
Signal to Noise ratio >90dB >90dB >90dB
Crossover HP/FULL/LP HP/FULL/LP
High Pass crossover frequency range 50Hz-250Hz 50Hz-250Hz
Low Pass crossover frequency range 50Hz-250Hz 50Hz-250Hz
Bass Boost @ 45Hz 0/6/12dB 0/6/12dB
MAX power rating 300 watts 600 watts
Operating voltage range 10.5VDC-15.0VDC 10.5VDC-15.0VDC
F F e e a a t t u u r r e e
Aluminum extruded heat sink Yes Yes
Illuminated Logo Yes Yes
Upgradeable to Bazooka ® C.H.I.L. system Yes Yes
Amplifier fusing Yes Yes
Protection - short, thermal, overload Yes Yes
Line Output Yes No
Remote Bass Control (Option) No No
Fan Cooling Yes Yes
WOOFERS M M G G W W 1 1 0 0 1 1 4 4 M M G G W W 1 1 2 2 1 1 4 4
S S p p e e c c i i f f i i c c a a t t i i o o n n
RMS Power 300 watts 300 watts
Peak Power 450 watts 450 watts
Voice Coil 2" 2"
Efficiency/Sensitivity 87dB 89dB
Magnet Weight 40oz 40oz
Minimum Enclosure Volume .3 cu ft .5 cu ft
Recommended Enclosure Volume .5 cu ft .75 cu ft
Vented Enclosure Volume 1.0 cu ft 1.25 cu ft
Impedance 4 ohm 4 ohm
F F e e a a t t u u r r e e
Custom powder coated steel basket Yes Yes
Oversized motor structure Yes Yes
Quad layered oversized foam surround Yes Yes
Poly infused paper cone Yes Yes
Kapton VC former Yes Yes
Flat progressive spider Yes Yes
Side and rear vented motor w/optional liquid cooling Yes Yes
Extended pole piece with bumped backplate Yes Yes
Spring loaded nickel plated speaker terminals Yes Yes
Decorative plastic magnet cover Yes Yes
Upgradeable to Bazooka C.H.I.L. system Yes Yes
**See website and/or product manual for enclosure design reccomendations.
***Due to the exceedingly high slew rate and damping factor ( Slew rate 40 V/uS and Damping factor > 1500 @ 4
ohm)on these unregulated power supply amplifiers, Bazooka reccomends high quality wiring and stiffening capacitors
to maintain 13 Volts or higher at the inputs of these amplifiers.
Bazooka
1-800-THE-TUBE • www.bazooka.com
, SAS, BAZOOKA, BASS TUBES, and LISTEN TO YOUR EARS are registered trademarks of Southern Audio Services, Inc. BAZOOKA subwoofer speaker systems exclusively
incorporate the revolutionary BASS TUBES patented subwoofer enclosure design available only from SAS. PAT. NO. 4,567,959 • PAT. NO. 5,097,513.
M M G G A A 1 1 3 3 0 0 0 0 M M G G A A 1 1 5 5 0 0 0 0 M M G G A A 4 4 1 1 5 5 0 0 M M G G A A 1 1 1 1 0 0 0 0 0 0 H H M M G G A A 1 1 1 1 5 5 0 0 0 0 H H
250Wx1CH 320Wx1 100Wx4 534Wx1 810Wx1
375Wx1 500WX1 150Wx4 1008Wx1 1550x1
270Wx4
NA 780Wx1 1222Wx1
0.30% 0.30% 0.30% 0.30% 0.30%
25Hz-130 Hz 25Hz-130Hz 10-20K +/- 0.5dB 12Hz-200Hz 25Hz-250KHz
>90dB >90dB >100dB >71dB >72dB
LP/FLAT LP/FLAT HP/FULL/LP LP LP
55-550hZ 30Hz-250Hz 30Hz-250Hz
50Hz-250Hz 50Hz-250Hz 55-550hZ 30Hz-250Hz 30Hz-250Hz
0/6/12dB 0/6/12dB 0-16dB 0-15dB 0-15dB
500 watts 750 watts 1000 watts 1500 watts 2000 watts
10.5VDC-15.0VDC 10.5VDC-15.0VDC 10.5VDC-15.0VDC 10.5VDC-15.0VDC 10.5VDC-15.0VDC
Yes Yes Yes Yes Yes
Yes Yes Yes Yes Yes
Yes Yes Yes Yes Yes
Yes Yes Yes Yes No
Yes Yes Yes Yes Yes
Yes Yes Yes Yes Yes
Yes Yes Yes Yes Yes
Yes Yes Yes Yes Yes
M M G G W W 1 1 5 5 1 1 4 4 M M G G W W 1 1 0 0 2 2 4 4 P P T T M M G G W W 1 1 2 2 2 2 4 4 P P T T
500 watts 350 watts 450 watts
700 watts 700 watts 900 watts
2.5" 2" 2"
89dB 85.4dB 87.1dB
48oz 37oz 50oz
1.3 cu ft ** **
1.7 cu ft ** **
1.5 cu f ** **
4 ohm dual 4 ohm dual 4 ohm
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
