- Page 2 Dear customer, Congratulations on your purchase of a Bazooka CS high-performance amplifier. At Bazooka, we are fanatics about accurate music reproduction. Your selection of our products for your sound system indicates that quality sound is also important to you too. At SAS, we take great pride in manufacturing revolutionary audio products, and through the years of engineering expertise, hand craftsmanship and critical testing procedures, we have created the CS high-performance series of amplifiers.
- Page 3 Be sure to fuse the power wire within 12” of the car's battery. This will protect the car's battery in case of a short circuit between the power amplifier and battery. THIS IS A MUST, the amplifier's built-in fuse will only protect the power amplifier not the car's battery! To ensure maximum power transfer and secure safe connections, it is recommended to use high grade barrier spades (for connection at amplifier) and terminal rings...
- Page 4 This circuit protects the output of the amplifier against DC voltage. If for some reason DC voltage is detected at the output stage, the amplifier will shut down protecting the speakers from direct current. The circuit protects the amplifier from damage due to a short found in the speakers or wiring.
- Page 5 For added low frequency performance the amplifiers are equipped with a variable 0~12 dB bass boost @ 45Hz. One set of full range line outputs have been provided for convenient connection to additional amplifiers in the system. This protects the amplifier against short circuits and excessive current. Automatically turns amplifier on when connected to the head unit's remote output.
- Page 6 Before you start the installation, it will be necessary to find a mounting location for the amplifier. Find a location in which the amplifier will receive adequate ventilation in order to dissipate the heat it develops during operation. Two popular mounting locations are in the trunk or under the seat.
- Page 7 TURN-ON OUTPUT TURN-ON OUTPUT 94.7 94.7 CSA50.2 CSA150.1 & CSA300.1 POWER CONNECTIONS RADIO'S REMOTE RADIO'S REMOTE TURN-ON OUTPUT TURN-ON OUTPUT 94.7 94.7 CSA50.4 & CSA200.3 POWER CONNECTIONS POWER FUSE +12V POWER FUSE +12V SPEAKER BRIDGED IN-LINE POWER FUSE IN-LINE POWER FUSE MOUNTED WITHIN 12"...
- Page 8 At times, the amplifier will need to draw large levels of current that cannot be provided by any circuit in the car's fuse box. We recommended using an 4 to 8 gauge power wire for your connections depending on the amplifier and length of the wire.
-
Page 9: Signal Connections
CSA150.1 & CSA300.1 SIGNAL CONNECTIONS PROTECT FILTER HIGH POWER FLAT CSA50.2 SIGNAL CONNECTIONS INPUT FILTER LEVEL HIGH INPUT LEVEL LEVEL FRONT REAR FLAT OUTPUT INPUT REMOTE FILTER HIGH FLAT CSA50.4 & CSA200.3 SIGNAL CONNECTIONS POWER LEVEL X-OVER 40Hz 130Hz... - Page 10 (+) of the speaker, and the same for negative (-). CSA50.2 SPEAKER CONNECTIONS 4 Ohm Speakers 4 Ohm Speakers (2 Ohm Minimum) (2 Ohm Minimum) CSA50.4 SPEAKER CONNECTIONS POWER FUSE +12V 4 Ohm Speakers 4 Ohm Speakers (2 Ohm Minimum)
- Page 11 CSA200.3 SPEAKER CONNECTIONS CSA150.1 & CSA300.1 SPEAKER CONNECTIONS POWER FUSE +12V BRIDGED 4 Ohm Speaker 4 Ohm Speaker 4 Ohm Speaker 4 Ohm Speaker (2 Ohm Minimum) (2 Ohm Minimum) (2 Ohm Minimum) (2 Ohm Minimum) +12V FUSE SPEAKER 4 Ohm Speaker 4 Ohm Speaker (2 Ohm Minimum) (2 Ohm Minimum)
- Page 12 In the bridged mode, the amplifier must see a 4 Ohm load or higher. Any lower than 4 Ohms will cause the amplifier to overheat and possibly cause SPEAKER POWER BRIDGED CSA50.2 BRIDGED SPEAKER CONNECTIONS CSA50.4 BRIDGED SPEAKER CONNECTIONS POWER FUSE +12V 4 Ohm Speaker 4 Ohm Speaker POWER...
- Page 13 4 Ohm connections. If you wish to use multiple speakers to achieve a lower impedance and higher power, it is strongly recommended that you seek professional advice from your BAZOOKA retailer before attempting to make these connections.
- Page 14 Before connecting the remote, it will be necessary to find a mounting location that will be easy to access for adjustment. Once you select your mounting location, you will need to run the control wire from the remote to the amplifier. possibility of induced noise from the car's electrical system (i.e.
- Page 15 (Please note: If you intend to use the CSA50.2 in the Tri-mode configuration, it is necessary to set the crossover control to the “FLAT” setting in order to receive full range output) The “CS” amplifiers are equipped with a built-in crossover network allowing you to select the crossover type (i.e.
- Page 16 We have put together this trouble-shooting guide if you experience problems after installing the amplifier. Please keep in mind that the majority of problems incurred are caused by improper installation and not the equipment itself. In addition, there are many components in the system that could cause various signal problems such as inducted electrical noise and engine noise.
- Page 17 Max Power Output Power @ 14.4 VDC : 4 ohm 2 ohm Bridged 4ohm Frequency Response + - 1dB S/N Ratio (A-weight) THD with 80k filter Low Input Level Battery Voltage Range Crossover S/W for 1+2 channel Crossover Frequency Crossover Slope Unbalanced Input (RCA Jack) Amplifier Fuse &...
- Page 18 SAS’ option: SAS limits its obligation under any implied warranties under state laws to a period not to exceed the limited warranty period. SAS and its authorized BAZOOKA® dealers specifically disclaim liability for any incidental or consequential damages. Some states do not allow limitations on how long an implied warranty lasts, and some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusions may not apply to you.
-
Page 19: How To Obtain Warranty Services
How to obtain warranty services: 1. You are responsible for delivery of the product to an authorized BAZOOKA® dealer or contact SAS at 1-800-THE TUBE for a Return Authorization number. The Return Authorization number must be clearly written on the outside of the box. Freight must be prepaid to SAS. - Page 20 www.extremeconcepts.com CSA MANUAL REV 1.29.04...
