4.1

TERMINAL STRIP ASSIGNMENTS

Description
Output signal, mA, flow rate (A)
Output signal, mA, temperature (B)
To block the regulation
Power 20 mA to sensor (2-wire)
Temperature signal input: Pt 100 Ω sensor at 0 °C, (3-wire)
Connection with extension unit (blind version)
Relay S4 / Pulse output 1 pulse/m³
Threshold 2 (N.O. contact) / Sampler control
Threshold S1 (N.O. contact) / Measurement of flow rate or temperature
Threshold S3 (N.O. contact) / Flow rate or temperature measurement
Available for assignment to external sensor: becomes a N.C. contact
Main power supply
Level transmitter (2 or 4 wire)
Distance max.
Required cable
22, Rue de la Voie des Bans · Z.I. de la gare · 95100 ARGENTEUIL
Tel +33 (0)1 30 25 83 20
Fax +33 (0)1 34 10 16 05
External sensor:
- Inductive sensor (194 831)
- Potential free switch
Connections to extension unit
Main unit
500 m
Network cable or shielded 4-wire cable ( ≥ 0.25 mm² )
INTERNATIONAL
Web www.bamo.eu
E-mail export@bamo.fr
Terminal
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
Extension unit
Flow calculator
BAMOPHAR 759
21-12-2018
Connection
+ mA
- mA
- mA
+ mA
+ 24 V
0V
0V
+ 24 V
+
+
-
Shielding
Y
Z
B
A
S4
S2
S1
S3
PE = Earth (equipotential)
N = Neutral
L = Live
NC
- mA
+ mA
DEB
759-03
M-759.03-EN-AB
