- Page 1 INSTALLATION INSTRUCTIONS USER GUIDE VOGUE Ceramic Cooktop 600mm 320156 To prevent the risk of accidents or damage to the appliance, it is essential to read these instructions before it is installed and used for the first time...
-
Page 2: Table Of Contents
Content 1…………………………………..…………………Safety instructions 2…………………………………..…………………Installation 3…………………………………..…………………Description of the Ceramic hob surface layout 4…………………………………..…………………Using the ceramic hob 5…………………………………..…………………Hob guidelines 6…………………………………..…………………Maintenance and cleaning 7…………………………………..…………………Environmental note Safety instructions his User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. - Page 3 MPORTANT: The adjacent furniture or housing and all materials used in the installation must be able to Caution! withstand a minimum temperature of o not use the ceramic hob until you 95°C above the ambient temperature have read this instruction manual. of the room it is located in, whilst in The ceramic hob is intended for use.
-
Page 4: Installation
and then cover flame e.g. with a lid cooking process has to be or a fire blanket. supervised continuously. ARNING: Danger of fire: do not ARNING: Unattended cooking store items on the cooking surfaces. on a hob with fat or oil can be dangerous and may result in a fire. - Page 5 WARNING: THIS APPLIANCE MUST BE EARTHED. If you have to change the oven power cord, the earthing (yellow/green) conductor must always be 10 mm longer than the line conductors. Care must be taken to ensure that the temperature of the mains supply cable does not exceed 50°C.
- Page 6 Installing the hob WARNING Risk of cutting. Be careful of cutting edges. End parts in foamed plastic - be careful. During transportation these could cause slight injury or cuts. Remove the material and envelope of documents from the packaging. Before proceeding with installation read the work instructions carefully. Step.1 Put a towel or cloth on the work surface.Place the hob face down on the protected surface.
- Page 7 IMPORTANT: You must observe the ventilation requirements shown in the drawing opposite. IMPORTANT: There are ventilation holes around the outside of the hob. YOU MUST ensure that these holes are not blocked by the work top, when you put the hob into position (see drawing opposite).
- Page 8 wires for each domino hob with 4D models Adaptive voltage range and wires The wiring diagram model 220-240 1N～ 380-420 2N～ 50- KADO K 1/5 50-60Hz 60Hz H05VV-F 4G2.5 H05GG-F 4G2.5 KADO XT AHW-4D-60-2 H05VV-F 3G2.5 H07RN-F 4G2.5 The cable connections must be in accordance with the diagram located on the bottom of the hob.
- Page 9 The “green-yellow” earth wire must be connected to the terminal marked . It must be about 10 mm longer than the live and neutral wires. The “blue” neutral wire must be connected to the terminal marked with letter (N) - the live wire(L1) must be connected to the terminal marked with letter (L1) (220-240V 1N～).
-
Page 10: Description Of The Ceramic Hob Surface Layout
Description of the Ceramic hob surface layout 4 zone ceramic hob schematic diagram Surface layout table Model Furnace Furnace Furnace Furnace Total power plate 1 plate 2 plate 3 plate 4 （kW） power（ power（ power（kW power（ kW） kW） kW） ） AHW-4D-60-2 Note：1.2 kW hyperspeed zones (diameter 165 mm)；... -
Page 11: Using The Ceramic Hob
Using the ceramic hob Before first use IMPORTANT: You should clean the ceramic hob surface (see “Maintenance and cleaning” section). You should switch on one cooking zone at a time, for 5 minutes at the maximum setting. This will help to eliminate any new smell that exists and evaporate any humidity that has formed on the heating elements during transit. - Page 12 Under standby mode, if some hob tops still exist residual heat, display will show “H”. If needing to switch off one of the cooking zones, you can select that zone first, then press the minus button until “0” power level to switch off that zone, and will not affect the heating of the other cooking zones.
- Page 13 Upon completion of power level adjustment, the decimal point of digital tube will stop flashing and normally display the power level within 10 seconds of no operation. When switching any of the cooking zone power level to 0, it will stop the power output of that cooking zone.
- Page 14 When the safety lock has been switched on, it will disable any of the other buttons on the control panel, apart from the ON/OFF button. Note: To avoid misoperation,if activate the safety lock by pressing the safety lock button,and the safety lock is not cancelled before the controller is switched off, the safety lock function will continue to be effective when the controller is switched on again.
- Page 15 Press any of the cooking zone select button,the digital tube will show the timer value of that burner. When not selecting any burner,the digital tube will show the minimum timer value of all burners, that is associated with the cooking zone of the cookingzone indicator lamp.
-
Page 16: Hob Guidelines
Caution! Ensure the heating plate is clean-a soiled zone does not transfer all of the heat. Protect the plate against corrosion. Switch off the plate against corrosion. Do not leave pans with prepared dishes based on fats and oils unattended on the switched-on plate;... -
Page 17: Maintenance And Cleaning
Maintenance and cleaning Cleaning operations must only be carried out when the hob is cool. The appliance should be disconnected from your mains supply before commencing any cleaning process. Cleaning the ceramic hob top Any residues that are left on the hob top surface from cleaning agents will damage it. -
Page 18: Environmental Note
IMPORTANT: If your appliance appears not to be operating correctly, Please contact with dealer. DO NOT ATTEMPT TO REPAIR THE APPLIANCE YOURSELF. Please note that if an engineer is asked to attend whilst the product is under guarantee and finds that the problem is not the result of an appliance fault, then you may be liable for the cost of the call out charge.
