Dimmer switch
Art.no 36-2809
Please read the entire instruction manual before using the product and save it for future reference.
We reserve the right for any errors in text or images and any necessary changes made to technical data.
If you have any questions concerning technical problems please contact our Customer Services.
Safety
•
Contact a qualified electrician for
maintenance and installation.
•
Always disconnect the mains supply
before beginning any maintenance.
Installation
1.
Check the rated voltage and power for
the light fixture being connected.
Make sure that it is suitable for the dimmer.
2.
Disconnect the power.
3.
Follow the wiring diagram for dimmer and
light fixture connections.
4.
Mount the dimmer into the patress.
5.
Connect the power.
Light bulb
Dimmer
GREAT BRITAIN • CUSTOMER SERVICE contact number 08545 300 9799
e-mail customerservice@clasohlson.co.uk internet www.clasohlson.com/uk
Model EFM700DB
Operating instructions
A short press on the dimmer knob turns the light
on and off. Turn clockwise to increase brightness.
Replacing the fuse
1.
Remove the dimmer knob.
2.
Pluck out the fuse mount.
3.
Replace the fuse (T1.25AH250VAC).
4.
Refit the fuse mount and dimmer knob.
Specifications
Operating voltage
230 V, 50 Hz
Min 50 W
Mains supply
Max 300 W
Variable load
Incandescent (230 V)
Halogen (230 V)
Two-way switch with Light bulb
Dimmer
Two-way
switch
