CO/Tech 50053 User Manual

Wireless Magnetic Contact Switch
Art.no 36-6048 Model 50053
Please read the entire instruction manual before using the product
and then save it for future reference. We reserve the right for
any errors in text or images and any necessary changes made
to technical data. In the event of technical problems or other
queries, please contact our Customer Services.
Installation
Note: The magnetic switch is primarily intended for controlling
lights but can also be used for other purposes. This instruction
manual describes the use of the magnetic switch when
connected in a light circuit.
1. Activate the battery by 2. Check that the timer
pulling the plastic tab out setting on the back of
of the battery holder. the magnetic switch is set
to zero (0).
3. Place the magnetic switch
and the receiver within 1 m
of each other.
4. Place the surface
of the magnet and
the magnetic switch
together.
5. Set your receiver to learning mode (refer to the instruction
manual of your receiver).
6. Separate the magnet and the magnetic switch
(more than 10 mm).
7. The devices will now be paired together.
GREAT BRITAIN • CUSTOMER SERVICE tel. 020 8247 9300 e-mail customerservice@clasohlson.co.uk internet www.clasohlson.co.uk
8. Set the activation time of the paired receiver by turning
the setting knob on the back of the magnetic switch.
- 0: If, for example a door is opened, the connected
light is switched on immediately. When the door
is closed, the connected light is switched off
immediately. No delay.
- 2 m: If, for example a door is opened, the light is
switched on and stays on for 2 minutes regardless of
whether the door remains open or is closed again.
- 4 m: If, for example a door is opened, the light is
switched on and stays on for 4 minutes regardless of
whether the door remains open or is closed again.
9. Attach the magnetic
switch to the frame
of the door or
window in question.
Use an appropriate
fastening method for
the surface in question.
10. Attach the magnet
to the door leaf
or the window sash no further than 10 mm from
the magnetic switch. Note: The magnetic switch and
the magnet must be in line with each other. Use the line
and the arrows on the units as a guide.
Unpairing the magnetic switch from the receiver
1. Set your receiver to learning mode (refer to
the instruction manual of your receiver).
2. Hold in the button on the magnetic
switch until the LED indicator on the front
of the magnetic switch goes out.
The magnetic switch is now no longer
paired with the receiver.

Changing the battery

Pull the battery holder straight down out of
the magnetic switch. Observe the markings on
the battery holder to ensure the correct polarity.
The positive terminal of the battery (+) should
be upwards, facing you.

Troubleshooting guide

The wireless • Is the magnetic switch paired with
magnetic switch the receiver as described above?
is not working. Try pairing them again.
• Check the battery in the magnetic
switch.
• Is the magnetic switch too far away
from the receiver (25 m)?
• Check that the light is properly
connected to the receiver and that
it is switched on and not faulty.
• Try plugging the light into another
electrical outlet to make sure that
it works.
Responsible disposal
This symbol indicates that this product
should not be disposed of with general
household waste. This applies throughout
the entire EU. In order to prevent any harm to
the environment or health hazards caused by
incorrect waste disposal, the product must
be handed in for recycling so that the material
can be disposed of in a responsible manner.
When recycling your product, take it to your local collection
facility or contact the place of purchase. They will ensure
that the product is disposed of in an environmentally sound
manner.

Specifications

433.92 MHz
Frequency
Max range 25 m
Activation time 0–20 min
Battery 1 × CR2032
