AIR CONDITIONER (MULTI TYPE)
Installation Manual
Outdoor Unit
Model name:
<Heat Pump Model>
MMY-MUP0801HT8P-E
MMY-MUP1001HT8P-E
MMY-MUP1201HT8P-E
MMY-MUP1401HT8P-E
MMY-MUP1601HT8P-E
MMY-MUP0801HT8JP-E MMY-MUP1801HT8JP-E
MMY-MUP1001HT8JP-E MMY-MUP2001HT8JP-E
MMY-MUP1201HT8JP-E MMY-MUP2201HT8JP-E
MMY-MUP1401HT8JP-E MMY-MUP2401HT8JP-E
MMY-MUP1601HT8JP-E
MMY-MUP1801HT8P-E
MMY-MUP2001HT8P-E
MMY-MUP2201HT8P-E
MMY-MUP2401HT8P-E
R410A
For commercial use
English
