- Page 1 FC730-4K User Manual FC730-4K User Manual Model : FC730-4K...
-
Page 2: Table Of Contents
FC730-4K USER MANUAL CONTENTS 1. Note ................................4 2. Control ................................4 2.1 RS232 Interface ..................................4 2.2 VISCA Network ..................................5 3. GUI Settings ..............................6 3.1 Menu ....................................... 6 3.2 Exposure ....................................7 3.3 Color ......................................8 3.4 Image ...................................... 9 3.5 P/T/Z ...................................... - Page 3 FC730-4K USER MANUAL 5.3 Troubleshooting ................................... 24 5.3.1 Image ....................................24 5.3.2 Control ....................................24 www.fs.com...
-
Page 4: Note
FC730-4K USER MANUAL 1. Note Electric Safety Installation and operation must accord with electric safety standard. Use Caution to Transport Avoid stress, vibration or soakage in transport, storage and installation. Polarity of Power Supply The power supply of this product is +12V, the max electrical current is 2A. Polarity of the power supply plug drawing shows as below. -
Page 5: Visca Network
FC730-4K USER MANUAL The correspondence between the camera and Windows DB-9 pin: Camera Windows DB-9 1.DTR 1.CD 2.DSR 2.RXD 3.TXD 3.TXD 4.GND 4.DTR 5.RXD 5.GND 6.GND 6.DSR 7.IR OUT 7.RTS 8.NC 8.CTS 9.RI The correspondence between the camera and the Mini DIN pin:... -
Page 6: Gui Settings
FC730-4K USER MANUAL Check digit: None RS485 Communication Control Control camera via RS485, half duplex mode: Baud rate: 2400/4800/9600/38400; Starting position: 1 bit Data bit: 8 bits Stop bit: 1 bit Check digit: None After power on, the camera goes to the upper right limit and then back to the middle position. The zoom lens is pulled to the farthest position, auto focus, and the aperture is adjusted to the default value. -
Page 7: Exposure
FC730-4K USER MANUAL 3.2 Exposure Move the main menu cursor to [EXPOSURE], and press [HOME] key enter the exposure page, as shown in the following figure. EXPOSURE Mode Auto ExpCompMode ExpComp Backlight Gain Limit Anti-Flicker 50Hz Meter Average Select Item... -
Page 8: Color
FC730-4K USER MANUAL 3.3 Color Move the main menu cursor to [COLOR], and press [HOME] key enter the color page, as shown in the following figure. COLOR WB Mode Auto AWB TYPE Norm RG Tuning BG Tuning Saturation 100% AWB Sens... -
Page 9: Image
FC730-4K USER MANUAL 3.4 Image Move the main menu cursor to [IMAGE], and press [HOME] key enter the image page, as shown in the following figure. IMAGE Luminance Contrast Sharpness Auto Flip-H Flip-V B&W-Mode Gamma Style Default Select Item Change Value [Menu] Back Luminance: Brightness adjustment, optional items: 0 ~ 14. -
Page 10: P/T/Z
FC730-4K USER MANUAL 3.5 P/T/Z Move the main menu cursor to [P/T/Z], and press [HOME] key enter the P/T/Z page, as shown in the following figure. P/T/Z SpeedByZoom AF-Zone Front AF-Sense High L/R Set Display Info Image Freeze Digital Zoom... -
Page 11: Setup
FC730-4K USER MANUAL 3.7 Setup Move the main menu cursor to [SETUP], and press [HOME] key enter the setup page, as shown in the following figure. SETUP Language DVI Mode Auto Scan Shoot SDI-3G Mode LEVEL-A Auto Inversion Trace Mode... -
Page 12: Communication Setup
FC730-4K USER MANUAL 3.8 Communication Setup Move the main menu cursor to [COMMUNICATION SETUP], and press [HOME] key enter the communication setup page, as shown in the following figure. COMMUNICATION SETUP Protocol VISCA V_Address V_AddrFix Net Mode Serial Baudrate 9600... -
Page 13: Equipment Installation
FC730-4K USER MANUAL 4.2 Equipment Installation 1.Connect video conference camera to your internet or to your PC via network cable. 2.Turn on DC 12V power. 3.If the network connection is normal, the connection light (green) at the network interface will light up within 5 seconds, and the data indicator (orange) will flash, indicating that the physical connection of the camera has been completed. - Page 14 FC730-4K USER MANUAL Method 1: Login the web page, select “Network > Lan Settings”, change IP address, subnet mask and gateway. Click “Apply” and restart the camera. Method 2: Open “upgrade_En.exe”, change IP and click “Set”. After modified, the video conference camera will be restart.
-
Page 15: Visit/Access Camera
FC730-4K USER MANUAL 4.4.2 Visit/Access Camera Input http://192.168.100.88 to IE (better with IE web browser, others will cause little latency), a login window pop up, input username: admin, password: admin, shown as below: After login, shown as below: If user first time use this camera by internet (only for new user), must install a player software (VLC). Please go to VLC website http://www.videolan.org/vlc/#download and Install the 32-bit VLC (player software). -
Page 16: Dynamic Dns Visit Camera
FC730-4K USER MANUAL 4.5.2 Dynamic DNS Visit Camera Set domain name to camera, setup the parameter, then dynamic DNS can access camera. Access link: http://hostname: port number. For example, setup host computer name: youdomain.f3322.org, the camera port number is 89, the access link should be http://youdomain.3322.org:89. -
Page 17: Homepage Introduction
FC730-4K USER MANUAL 4.6.1 Homepage Introduction Menu All pages include two menu bars: Real time monitoring: displaying video image Parameter setup: with function buttons. A. Video Viewing Window Video viewing window must be same as video resolution, the bigger the resolution is, the bigger the playing area is. - Page 18 FC730-4K USER MANUAL Method 1: Type a number into the Preset box. Preset: Optional items: 0 ~ 254. Method 2: Type the name into the Presets Information. Click “Set” button, when PTZ turn to other position, click “Call” button or click “No. ” of the Presets Information, PTZ will turn back to preset position.
-
Page 19: Video Settings
FC730-4K USER MANUAL 4.6.2 Video Settings Video Format Support 50Hz (PAL) and 60Hz (NTSC), and Dial Priority three formats. Encode Level Support baseline, mainprofile, highprofile and svc-t four levels. Encode Protocol Support H.264, H.265 and MJPEG three protocols. Resolution First stream support 3840x2160, 1920x1080, 1280x720, 1024x576, 960x540, 640x480, 640x360. Second stream support 1920x1080, 1280x720, 1024x576, 720x576 (50Hz support), 720x480 (60Hz support), 720x408, 640x360, 480x270, 320x240, 320x180;... -
Page 20: Image Settings
FC730-4K USER MANUAL Constant Bit Rate: Video coder will be coding according to preset speed. Variable Bit Rate: Video coder will adjust the speed based on preset speed to gain the best image quality. Fluctuate Level Restrain the fluctuation magnitude of variable rate, grade 1 ~ 6. -
Page 21: Audio Settings
FC730-4K USER MANUAL 4.6.4 Audio Settings Audio Switch Enable or disable audio switch. Audio Type Optional items: G711A, AAC. Sample Rate Optional items: 44.1K, 48K. Bit Rate Optional items: 96K, 128K, 256K. Input Type Optional items: Line in. Input Vol L The volume of the left channel. -
Page 22: Network Settings
FC730-4K USER MANUAL 4.6.6 Network Settings Lan Settings Default the IP address is 192.168.100.88, the MAC address cannot be modified. Port Settings A. HTTP Port IP address identifies the network device, the device can run multiple web applications, each network program using network port to transmit data, so data transmission to be carried out between the port and port. -
Page 23: Device Information
FC730-4K USER MANUAL Turn On/Off multicast. Setting the multicast address (default value is 224.1.2.3) and port (default value is 6688, then 6688 is the multicast port of the first stream; 6690 is the multicast port of the second stream). SDK Settings Turn On/Off active connection. -
Page 24: Maintenance And Troubleshooting
FC730-4K USER MANUAL 5.Maintenance and Troubleshooting 5.1 Camera Maintains If camera will not be used for a long time, please turn off power switch, disconnect AC power cord of AC adaptor to the outlet. Please use soft cloth or tissue to clean the camera cover. - Page 25 FC730-4K USER MANUAL 3.Check whether the address of remote control can match the camera. Serial port cannot control 1.Check whether the camera protocol, address and baud rate such is the same. 2.Check whether the control line is connected well. www.fs.com...
- Page 26 Singapore Australia The information in this document is subject to change without notice. FS has made all efforts to ensure the accuracy of the content, but all information in this document does not constitute any kind of warranty. Copyright © 2009-2021 FS.COM AII Rights Reserved.
